APC NetShelter Metered Rack PDU

APC NetShelter Metered Rack PDU, 0U, 1PH, 7.4kW 230V 32A, x36 C13 and x6 C19 outlets, IEC 309 2P+E cord (AP8853) - 2 Years Local Warranty

High-Capacity Power Distribution

The APC NetShelter Metered Rack PDU (AP8853) delivers 7.4kW of single-phase power at 230V and 32A through an IEC 309 2P+E cord. With 36 C13 and 6 C19 outlets, it powers a densely populated rack of servers and networking gear from a single, reliable unit, simplifying power distribution across your data center.

Real-Time Metering and Visibility

Built-in metering gives you accurate, real-time visibility into power consumption directly on the unit's digital display. By tracking load at the PDU level, you can balance circuits, avoid overloading, and make smarter decisions about capacity, helping optimize energy usage across critical infrastructure.

Remote Management and Monitoring

The AP8853 supports SNMP, web, and third-party monitoring integration, so you can monitor power usage and conditions from anywhere. Optional temperature and humidity monitoring rounds out a comprehensive view of your rack environment, helping you protect uptime and respond quickly to issues.

Space-Saving 0U Vertical Mount

The 0U form factor mounts vertically along the side of the rack, keeping valuable U space free for active equipment. Included mounting hardware and broad compatibility with NetShelter enclosures make installation quick and clean, integrating easily into existing power distribution setups.

Protection for Critical Equipment

Surge protection helps shield connected devices from damaging transients, while the rugged design ensures dependable operation in demanding data center environments. The result is steady, well-managed power that keeps your critical equipment running reliably.

Technical Specifications

• Type: Rack-mounted Metered Power Distribution Unit (PDU)
• Rack Mountable: Yes, 0U (mounts vertically to the side of a rack)
• Input Voltage: 230V AC
• Input Current: 32A
• Output Voltage: 230V AC
• Outlets: 36 x C13 outlets; 6 x C19 outlets
• Input Connector: IEC 309 2P+E (Ceeform 32A)
• Power Rating: 7.4kW (at 230V)
• Phases: Single-phase (1PH)
• Current Rating: 32A @ 230V
• Total Load Capacity: 7.4kW
• PDU Type: Metered PDU with real-time monitoring
• Monitoring: Provides real-time power usage monitoring with a digital display; allows for SNMP, web, and third-party monitoring integration
• Surge Protection: Yes, provides surge protection for connected devices
• Mounting: 0U design for vertical mounting on the side of a rack; includes all necessary mounting hardware
• Environmental Conditions: Operating Temperature 0°C to 40°C (32°F to 104°F); Humidity 0% to 95% non-condensing
• Certifications: UL; CE; RoHS compliant; cUL
• Dimensions: 0U vertical rack mount (compatible with standard 19-inch racks)
• Weight: Approximately 7.5 kg (16.5 lbs)

Ideal Use Case: Ideal for high-density data center racks that need metered single-phase power distribution with remote monitoring and a large mix of C13 and C19 outlets.

GTIN/UPC: 731304270576
