NETGEAR M4350-24G4XF 24-Port Gigabit PoE+ Fully Managed AV Switch with 4 x 10G SFP+
Email sales@sourceit.com.sg or use Request for Quotation below and our team will confirm the latest price, availability and lead time.
PRODUCT DESCRIPTION
NETGEAR M4350-24G4XF 24-Port Gigabit PoE+ Fully Managed AV Switch with 4 x 10G SFP+ (GSM4328-100NES) - Limited Lifetime Local Warranty
24 PoE+ Ports with a 648W Budget
The M4350-24G4XF delivers 24 Gigabit PoE+ ports at up to 30W each and four 10GBASE-X SFP+ uplinks. Its 880W internal power supply provides 648W of PoE budget out of the box, expandable to 720W with a modular power supply, enough to power every port at full PoE+ for cameras, encoders, decoders, access points and control panels.
Layer 3 and Virtual Chassis
Virtual Chassis stacking provides non-stop forwarding (NSF) and hitless failover, and the Layer 3 feature set covers static, policy-based and dynamic routing. NETGEAR IGMP Plus handles AV-over-IP multicast with little-to-no setup, AVB is included, and jumbo frames up to 12KB are supported.
Redundant Power in a 40cm Chassis
One modular power supply slot adds 1+1 redundancy and/or EPS power sharing. The full-width 1U chassis is only 40cm deep and runs at 33dBA at 25°C in Quiet Mode, suiting AV racks and quiet rooms.
Configured for AV in Minutes
The NETGEAR AV user interface applies certified port profiles for AV protocols, and NETGEAR Engage Controller support speeds up multi-switch AV projects.
Not sure which model fits your project? Email sales@sourceit.com.sg with your requirements and we will confirm it for you.
NETGEAR M4350-24G4XF Datasheet — Technical Specifications
General
| Product Name | NETGEAR M4350-24G4XF 24x 1G PoE+ and 4x SFP+ Fully Managed Switch |
| Part Number | GSM4328-100NES |
| Local Warranty (Singapore) | Limited lifetime, supplied by SourceIT with a GST invoice |
Ports
| Copper ports | 24x 10M/100M/1G RJ45 PoE+ |
| Fibre uplinks | 4x 1G/10G SFP+ (10GBASE-X) |
| Management | Industry-standard CLI, NETGEAR IT web GUI and NETGEAR AV user interface; USB-C console (front), 1G out-of-band Ethernet port (rear), 2x USB-A (rear) |
Performance
| Switching fabric | 128Gbps |
| Throughput | 95.23Mpps |
| Latency | <2.42µs (1G); <0.92µs (10G fibre) |
| Packet buffer | 16Mb |
| Memory | 2GB DDR4 |
| Route table | Static: 256 IPv4 / 64 IPv6; RIP: 512; OSPF: 1,024 |
| MAC address table | 16K |
| ARP / NDP | 4K ARP / 512 NDP |
| VLANs | 4K |
| IGMP multicast groups | Up to 12K |
| CPU | Quad-Core Cortex-A57 ARMv8 1.8GHz 64-bit |
Layer 3 & AV Features
| Routing | Layer 3: static, policy-based and dynamic routing (RIP, OSPF), VRRP; IPv4 and IPv6 |
| Multicast | NETGEAR IGMP Plus |
| AVB | Included |
| Jumbo frames | Up to 12KB |
| Stacking | Virtual Chassis with non-stop forwarding (NSF) and hitless failover |
PoE
| PoE standard | PoE+ (up to 30W per port) on all 24 copper ports |
| PoE budget | 648W base; up to 720W with a modular PSU |
Power
| Internal power supply | 880W fixed (C14) |
| Modular PSU slots | 1 (1+1 redundancy and/or EPS share) |
| Compatible PSUs | APS350Wv1, APS600Wv2, APS920Wv1, APS2000Wv1 |
| Power consumption | 792.1W with PoE; 80W without PoE; 32W standby (per NETGEAR product page) |
Physical & Environmental
| Form factor | Full-width 1U rack mount |
| Dimensions (W x D x H) | 440 x 400 x 43.2mm |
| Weight | 6.41kg (14.13lb) (per NETGEAR product page) |
| Cooling | Front-to-back airflow, 4 fans |
| Acoustics (Quiet Mode) | 33dBA at 25°C (28% fan duty); 52dBA at 45°C (60% fan duty) |
Compatibility & Software Support
Management & AV Software
Configure the switch through the NETGEAR AV user interface (port profiles for AV protocols, colour-matched port LEDs), the main NETGEAR IT web GUI or the industry-standard CLI. NETGEAR states the M4350 works with NETGEAR Engage Controller for centralised AV project management. NETGEAR IGMP Plus provides out-of-the-box multicast for AV over IP.
Modular Power Supplies
NETGEAR lists these power supplies as compatible with this model: APS350Wv1 (APS350W-100NES), APS600Wv2 (APS600W-200NES), APS920Wv1 (APS920W-100NES), APS2000Wv1 (APS2000W-100NES).
Package Contents & M4350 Series Ordering Information
In the Box
1x M4350-24G4XF switch, 1x power cord, 1x USB Type-C console cable, rack-mounting standard bracket set, set of longer brackets for recessed mounting, 4x rubber footpads for tabletop installation, installation guide.
NETGEAR M4350 Series
| Model | Ports |
| M4350-8M2V (MSM4310-100NES) | 8x 2.5G PoE++, 2x 25G SFP28 |
| M4350-16M4V (MSM4320-100NES) | 16x 2.5G PoE++ (incl. 8x Neutrik etherCON), 4x 25G SFP28 |
| M4350-24M4X4V (MSM4332-100NES) | 24x 2.5G PoE++, 4x 10G PoE++, 4x 25G SFP28 |
| M4350-44M4X4V (MSM4352-100NES) | 44x 2.5G PoE++, 4x 10G PoE++, 4x 25G SFP28 |
| M4350-24F4X (MSM4328F-100NES) | 24x 1G/2.5G SFP, 4x 10G |
| M4350-24G4XF (GSM4328-100NES) (this listing) | 24x 1G PoE+, 4x 10G SFP+ |
| M4350-48G4XF (GSM4352-100NES) | 48x 1G PoE+, 4x 10G SFP+ |
| M4350-8X8F (XSM4316-100NES) | 8x 10G, 8x 10G SFP+ |
| M4350-12X12F (XSM4324-100NES) | 12x 10G, 12x 10G SFP+ |
| M4350-24X4V (XSM4328CV-100NES) | 24x 10G PoE+, 4x 25G SFP28 |
| M4350-24F4V (XSM4328FV-100NES) | 24x 10G SFP+, 4x 25G SFP28 |
| M4350-36X4V (XSM4340CV-100NES) | 36x 10G PoE++, 4x 25G SFP28 |
| M4350-32F8V (XSM4340FV-100NES) | 32x 10G SFP+, 8x 25G SFP28 |
| M4350-24X8F8V (XSM4340V-100NES) | 24x 10G PoE++, 8x 10G SFP+, 8x 25G SFP28 |
| M4350-40X4C (XSM4344C-100NES) | 40x 10G PoE++, 4x 100G QSFP28 |
| M4350-40F4C (XSM4344FC-100NES) | 40x 10G SFP+, 4x 100G QSFP28 |
| M4350-16V4C (VSM4320C-100NES) | 16x 25G SFP28, 4x 100G QSFP28 |
| M4350-16C (CSM4316-100NES) | 16x 100G QSFP28 |
Datasheet & Downloads
| Datasheet | NETGEAR M4350 Series Datasheet (PDF) |
| Hardware Installation Guide | M4350 Series Hardware Installation Guide (PDF) |
| User Manual | M4350 Series User Manual (PDF) |
| NETGEAR product page | M4350-24G4XF (GSM4328) on netgear.com |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting GSM4328-100NES.
Frequently Asked Questions — NETGEAR M4350-24G4XF
How much PoE power does the M4350-24G4XF provide?
648W from the internal 880W power supply, expandable to 720W with a compatible modular power supply, with up to 30W (PoE+) per port.
What uplinks does it have?
Four SFP+ ports supporting 1G and 10G (10GBASE-X).
Can it route between VLANs?
Yes. It is a Layer 3 switch with static, policy-based and dynamic routing (RIP, OSPF), plus VRRP.
Is it suitable for AV over IP?
Yes. NETGEAR IGMP Plus, AVB support, the AV user interface and 12KB jumbo frames are included, and it works with NETGEAR Engage Controller.
What warranty do I get?
Limited lifetime local warranty in Singapore, supplied by SourceIT with a GST invoice.
