HPE ProLiant DL360 Gen11 1U Rack Server
Email sales@sourceit.com.sg or use Request for Quotation below and our team will confirm the latest price, availability and lead time.
PRODUCT DESCRIPTION
HPE ProLiant DL360 Gen11 1U Rack Server (Configure-to-Order) - Local Warranty
Dense 1U, Dual-Socket Intel Xeon Compute
The HPE ProLiant DL360 Gen11 packs two 4th or 5th Gen Intel Xeon Scalable processors (up to 64 cores each, 125 W to 385 W TDP) and 32 DDR5 RDIMM slots for up to 8 TB of HPE Smart Memory at up to 5600 MT/s into a single rack unit.
Flexible Storage and PCIe Gen5 I/O
Drive cages range from 4 x LFF SAS/SATA to 8+2 x SFF U.3 tri-mode (NVMe/SAS/SATA) or 20 x EDSFF E3.S NVMe. Up to three PCIe 5.0 x16 slots and two OCP 3.0 slots, plus NVIDIA A2 and L4 GPU support, suit virtualisation, VDI, databases and edge AI inference.
Secure, Cloud-Managed Infrastructure
HPE iLO 6 with silicon root of trust secures the platform from the firmware up, while HPE Compute Ops Management adds cloud-based fleet monitoring and updates. HPE's standard warranty is 3 years parts, 3 years labour and 3 years onsite next-business-day.
HPE ProLiant DL360 Gen11 Datasheet — Technical Specifications
General
| Product Name | HPE ProLiant DL360 Gen11 Server |
| Form Factor | 1U rack, 2-socket |
| Order Type | Configure-to-Order (CPU, memory, drive cage, controller, NIC, PSU and support term chosen per order) |
| HPE Standard Warranty | 3 years parts, 3 years labour, 3 years onsite, next business day |
| Local Warranty (Singapore) | Supplied by SourceIT with HPE warranty; HPE Care Pack upgrades available at configuration |
Processor & Memory
| Processors | Up to two 4th or 5th Gen Intel Xeon Scalable processors, up to 64 cores, 125 W to 385 W TDP |
| Memory Slots | 32 DIMM slots (16 per processor), HPE DDR5 Smart Memory RDIMM |
| Maximum Memory | 8 TB |
| Memory Speed | Up to 5600 MT/s (processor dependent) |
Storage
| Drive Cage Options | 4 x LFF SAS/SATA; 8 x SFF (expandable to 8+2) U.3 tri-mode NVMe/SAS/SATA; or 20 x EDSFF E3.S 1T PCIe 5.0 NVMe |
| RAID Controllers | HPE MR216i-p / MR216i-o, MR408i-o, MR416i-o / MR416i-p, SR932i-p Gen11; Intel VROC software RAID |
| Boot Device | HPE NS204i-u NVMe Hot Plug Boot Optimized Storage Device |
Expansion & Networking
| PCIe Slots | Up to 3 x PCIe 5.0 x16 (slot 1 full height, slot 2 low profile, optional slot 3) |
| OCP Slots | 2 x OCP 3.0 (x16, PCIe 5.0) |
| Embedded NIC | None on CTO models; networking via OCP 3.0 or PCIe adapters |
| GPU Support | NVIDIA A2 and NVIDIA L4 (single-wide) |
Management & Security
| Management | HPE iLO 6; HPE Compute Ops Management |
| Security | HPE iLO silicon root of trust, secure boot and firmware validation; TPM 2.0 (optional) |
Power & Cooling
| Power Supplies | HPE Flex Slot hot-plug options from 500 W to 2200 W (800 W Flex Slot Platinum standard offering) |
| Fans | 5 standard fans up to 7 high-performance fans |
| Cooling Options | Air cooling; Closed Loop Liquid Cooling and Direct Liquid Cooling options |
How to Configure Your Server — Sizing Checklist
Servers are built to order. Answer the questions below so we can size the right configuration for you.
Step 1: Hardware Requirements
- Which server form factor do you need: tower or rackmount?
- How many CPU cores, how much RAM and how much usable storage capacity do you require?
- How many processors: single-socket (1S), dual-socket (2S) or four-socket (4S)?
- Which RAID configuration do you need? Any specific HDD or SSD type, such as 7.2K or 10K rpm drives?
- Which network interface is required: 1GbE Base-T, SFP+ or Fibre Channel?
- How many years of maintenance support do you need? (Minimum 3 years)
Step 2: Deployment & Services
- How many server units are required?
- Will you run virtual machine workloads? Do you need a VMware licence, or Windows Server with Hyper-V?
- How do you store data today? Do you have existing NAS or SAN storage?
- How do you back up today? Would you like a backup proposal, such as an IDPA 8TB appliance?
- Do you require burn-in test services?
- Do you need hard disk retention services?
Operating Systems, Management & Workloads
Operating Systems & Hypervisors
Microsoft Windows Server, VMware ESXi, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Ubuntu, Oracle Linux and SAP Linux. Check HPE's OS support matrix for the exact versions certified on your chosen processor.
Management Tools
HPE iLO 6 provides out-of-band remote console, monitoring and alerting. HPE Compute Ops Management adds cloud-based firmware compliance, monitoring and lifecycle management across a fleet of ProLiant servers.
Typical Workloads
Virtualisation and containers, VDI, transactional databases, web and application serving, and space-constrained edge or branch deployments where 1U density matters.
Package Contents & HPE ProLiant Gen11 Ordering Information
What Is Supplied
The DL360 Gen11 is built to order: chassis with the processors, memory, drive cage, storage controller, network adapters and power supplies specified on your quotation, plus rail kit, bezel and power cords where ordered.
HPE ProLiant Gen11
| Model | Key feature |
| ProLiant MicroServer Gen11 | Ultra-compact, 1-socket Intel Xeon E-2400 |
| ProLiant ML30 Gen11 | Tower, 1-socket Intel Xeon E-2400 |
| ProLiant ML110 Gen11 | Tower, 1-socket Intel Xeon Scalable |
| ProLiant ML350 Gen11 | Tower, 2-socket Intel Xeon Scalable |
| ProLiant DL20 Gen11 | 1U, 1-socket Intel Xeon E-2400 |
| ProLiant DL145 Gen11 | Edge, 1-socket AMD EPYC 8004 |
| ProLiant DL320 Gen11 | 1U, 1-socket Intel Xeon Scalable |
| ProLiant DL325 Gen11 | 1U, 1-socket AMD EPYC |
| ProLiant DL345 Gen11 | 2U, 1-socket AMD EPYC |
| ProLiant DL360 Gen11 (this listing) | 1U, 2-socket Intel Xeon Scalable |
| ProLiant DL365 Gen11 | 1U, 2-socket AMD EPYC |
| ProLiant DL380a Gen11 | 2U, 2-socket Intel Xeon, GPU-optimised |
| ProLiant DL385 Gen11 | 2U, 2-socket AMD EPYC |
Datasheet & Downloads
| HPE QuickSpecs | HPE ProLiant DL360 Gen11 QuickSpecs |
| HPE data sheet | HPE ProLiant DL360 Gen11 Data Sheet (PDF) |
| User guide | HPE ProLiant DL360 Gen11 User Guide on HPE Support |
| HPE product page | HPE ProLiant DL360 Gen11 on hpe.com |
Frequently Asked Questions — HPE ProLiant DL360 Gen11
Is this a fixed configuration?
No. The DL360 Gen11 is configure-to-order. Processors, memory, drive cage, RAID controller, network adapters, power supplies and the HPE support term are specified to your workload; use the sizing checklist above to brief us.
How much memory can it take?
32 DDR5 RDIMM slots for up to 8 TB of HPE Smart Memory, at up to 5600 MT/s with 5th Gen Xeon processors.
How many drives fit in 1U?
Up to 10 SFF drives (8+2 U.3 tri-mode) or 20 EDSFF E3.S NVMe drives, or 4 LFF drives for high-capacity SAS/SATA.
What warranty does it carry?
HPE's standard warranty is 3 years parts, 3 years labour and 3 years onsite next-business-day. Faster response and longer terms are available as HPE Care Pack upgrades.
DL360 or DL380?
Choose the 1U DL360 Gen11 for compute density. Choose a 2U model such as the DL380a Gen11 when you need more drive bays, more PCIe slots or double-wide GPUs.
