PRODUCT DESCRIPTION
HPE ProLiant DL380a Gen11 2U Rack Server (Configure-to-Order) - Local Warranty
GPU-Optimised 2U for Enterprise AI
The HPE ProLiant DL380a Gen11 is an accelerator-optimised 2U, 2-socket server that takes up to 4 double-wide or 8 single-wide GPUs, such as NVIDIA H100 NVL, L40S or L4, for AI training, fine-tuning, inference and visual computing.
Dual Intel Xeon with DDR5 and PCIe Gen5
Two 4th or 5th Gen Intel Xeon Scalable processors (up to 64 cores each, up to 350 W) pair with 24 DDR5 RDIMM slots for up to 3 TB of memory at up to 5600 MT/s, with up to four PCIe 5.0 x16 slots and two OCP 3.0 slots for high-speed networking.
Secure, Cloud-Managed Infrastructure
HPE iLO 6 with silicon root of trust protects the platform from the firmware up, and HPE Compute Ops Management adds cloud-based monitoring and lifecycle updates. HPE's standard warranty is 3 years parts, 3 years labour and 3 years onsite next-business-day.
HPE ProLiant DL380a Gen11 Datasheet — Technical Specifications
General
| Product Name | HPE ProLiant DL380a Gen11 Server |
| Form Factor | 2U rack, 2-socket (dual-processor configurations only) |
| Order Type | Configure-to-Order (CPU, memory, GPUs, drive cage, controller, NIC, PSU and support term chosen per order) |
| HPE Standard Warranty | 3 years parts, 3 years labour, 3 years onsite, next business day |
| Local Warranty (Singapore) | Supplied by SourceIT with HPE warranty; HPE Care Pack upgrades available at configuration |
| Dimensions (H x W x D) | 8.75 x 44.8 x 81.6 cm |
Processor & Memory
| Processors | Two 4th Gen (up to 56 cores) or 5th Gen (up to 64 cores) Intel Xeon Scalable processors, up to 350 W TDP |
| Memory Slots | 24 DIMM slots (12 per processor), HPE DDR5 Smart Memory RDIMM |
| Maximum Memory | 3 TB (24 x 128 GB RDIMM) |
| Memory Speed | DDR5-4800 or DDR5-5600 MT/s (processor dependent) |
GPU & Accelerators
| GPU Capacity | Up to 4 double-wide or 8 single-wide accelerators |
| Supported GPUs | NVIDIA H100 NVL, NVIDIA H100, NVIDIA L40 / L40S (2 or 4); NVIDIA L4 (8); Intel Data Center GPU Max 1100 (2 or 4) |
Storage
| Drive Cage Options | 8 x SFF U.3 NVMe or 8 x EDSFF NVMe |
| RAID Controllers | HPE MR416i-p / MR416i-o Gen11, HPE SR932i-p Gen11; Intel VROC |
| Boot Device | HPE NS204i-u Gen11 NVMe Hot Plug Boot Optimized Storage Device (2 x 480 GB M.2 NVMe, RAID 1) |
Expansion & Networking
| PCIe Slots | Up to 4 x PCIe 5.0 x16 (primary and secondary risers) |
| OCP Slots | 2 x OCP 3.0 (OCP2 optional) |
| Embedded NIC | None on CTO models; 1 Gb to 100 Gb adapters via OCP 3.0 or PCIe |
Management & Security
| Management | HPE iLO 6; HPE Intelligent Provisioning; Redfish API; HPE Compute Ops Management (3-year subscription included by default) |
| Security | Immutable silicon root of trust, UEFI Secure Boot and Secure Start, TPM 2.0, optional chassis intrusion detection |
Power & Cooling
| Power Supplies | HPE 1600 W Flex Slot Platinum or 1800 W-2200 W Flex Slot Titanium hot-plug (4 PSUs for 4 double-wide GPUs, 2 PSUs for 8 single-wide) |
| Fans | 6 dual-rotor hot-plug fans, N+1 redundant |
How to Configure Your Server — Sizing Checklist
Servers are built to order. Answer the questions below so we can size the right configuration for you.
Step 1: Hardware Requirements
- Which server form factor do you need: tower or rackmount?
- How many CPU cores, how much RAM and how much usable storage capacity do you require?
- How many processors: single-socket (1S), dual-socket (2S) or four-socket (4S)?
- Which RAID configuration do you need? Any specific HDD or SSD type, such as 7.2K or 10K rpm drives?
- Which network interface is required: 1GbE Base-T, SFP+ or Fibre Channel?
- How many years of maintenance support do you need? (Minimum 3 years)
Step 2: Deployment & Services
- How many server units are required?
- Will you run virtual machine workloads? Do you need a VMware licence, or Windows Server with Hyper-V?
- How do you store data today? Do you have existing NAS or SAN storage?
- How do you back up today? Would you like a backup proposal, such as an IDPA 8TB appliance?
- Do you require burn-in test services?
- Do you need hard disk retention services?
Operating Systems, Management & Workloads
Operating Systems & Hypervisors
Microsoft Windows Server, VMware ESXi, Red Hat Enterprise Linux, SUSE Linux Enterprise Server and Ubuntu. Check HPE's Servers Support & Certification Matrices for the exact versions certified on your chosen processor.
Management Tools
HPE iLO 6 provides out-of-band remote console, monitoring and alerting. HPE Compute Ops Management adds cloud-based firmware compliance, monitoring and lifecycle management across a fleet of ProLiant servers.
Typical Workloads
AI inference and fine-tuning, computer vision, generative AI, VDI with GPU acceleration, rendering and other GPU-accelerated data-centre workloads.
Package Contents & HPE ProLiant Gen11 Ordering Information
What Is Supplied
The DL380a Gen11 is built to order: chassis with the processors, memory, GPUs, drive cage, storage controller, network adapters and power supplies specified on your quotation, plus rail kit and power cords where ordered.
HPE ProLiant Gen11
| Model | Key feature |
| ProLiant MicroServer Gen11 | Ultra-compact, 1-socket Intel Xeon E-2400 |
| ProLiant ML30 Gen11 | Tower, 1-socket Intel Xeon E-2400 |
| ProLiant ML110 Gen11 | Tower, 1-socket Intel Xeon Scalable |
| ProLiant ML350 Gen11 | Tower, 2-socket Intel Xeon Scalable |
| ProLiant DL20 Gen11 | 1U, 1-socket Intel Xeon E-2400 |
| ProLiant DL145 Gen11 | Edge, 1-socket AMD EPYC 8004 |
| ProLiant DL320 Gen11 | 1U, 1-socket Intel Xeon Scalable |
| ProLiant DL325 Gen11 | 1U, 1-socket AMD EPYC |
| ProLiant DL345 Gen11 | 2U, 1-socket AMD EPYC |
| ProLiant DL360 Gen11 | 1U, 2-socket Intel Xeon Scalable |
| ProLiant DL365 Gen11 | 1U, 2-socket AMD EPYC |
| ProLiant DL380a Gen11 (this listing) | 2U, 2-socket Intel Xeon, GPU-optimised |
| ProLiant DL385 Gen11 | 2U, 2-socket AMD EPYC |
Datasheet & Downloads
| HPE QuickSpecs | HPE ProLiant DL380a Gen11 QuickSpecs |
| HPE product page | HPE ProLiant DL380a Gen11 on hpe.com |
| HPE store page | HPE ProLiant DL380a Gen11 on buy.hpe.com |
Frequently Asked Questions — HPE ProLiant DL380a Gen11
Is this a fixed configuration?
No. The DL380a Gen11 is configure-to-order. Processors, memory, GPUs, drives, network adapters, power supplies and the HPE support term are specified to your workload; use the sizing checklist above to brief us.
How many GPUs does it take?
Up to 4 double-wide GPUs (such as NVIDIA H100 NVL or L40S) or 8 single-wide GPUs (such as NVIDIA L4) in 2U.
Can it run with one processor?
No. The DL380a Gen11 supports dual-processor configurations only.
How much memory can it take?
24 DDR5 RDIMM slots for up to 3 TB, at up to 5600 MT/s with 5th Gen Xeon processors.
What warranty does it carry?
HPE's standard warranty is 3 years parts, 3 years labour and 3 years onsite next-business-day. Faster response and longer terms are available as HPE Care Pack upgrades.
