Samsung Flip 2 Connectivity Tray for WM55B/WM65B
PRODUCT DESCRIPTION
Samsung Flip 2 Connectivity Tray for WM55B/WM65B (CY-TF65BBCXXS) - Local Warranty
USB-C at the Front of the Board, Where Guests Can Reach It
The CY-TF65BBC adds USB-C to the front face of a WM55B or WM65B, and that single port is what most visitors now expect: one cable from a modern laptop for video and data. Alongside it sit an HDMI input, two USB-A ports, a USB-B port and a USB-B touch out. For a boardroom or a client meeting suite where people arrive with whatever machine they own, having those connections at waist height on the front of the board removes the awkward minute at the start of every meeting when someone is feeling around behind the display.
Touch Out So Visitors Drive Their Laptop From the Glass
The USB-B touch out sends touch input from the board back to a connected laptop, so a consultant presenting from their own machine can annotate, scroll and click on the screen instead of returning to the table. In training rooms, design studios and classrooms that turns a passive projection into a working session, and it is the port most buyers forget to specify until the first workshop. Combined with the HDMI input for older machines, the tray covers both current and legacy laptops without an adapter drawer.
Mount It or Remove It Whenever the Room Changes
Samsung designs the tray so it can be removed or mounted at any time, which suits an estate where boards move between rooms or between a stand and a wall mount. It measures 269.8 x 111.3 x 56.9 mm and weighs 0.5 kg in a grey-white finish that matches the Interactive Pro family, and it ships with an installation guide and screws. One part number covers both the 55-inch WM55B and the 65-inch WM65B, so a mixed estate keeps a single spare on the shelf.
Samsung CY-TF65BBC Datasheet — Technical Specifications
General
| Product | Samsung Connectivity Tray for Flip WM55B / WM65B |
| Part Number (SKU) | CY-TF65BBCXXS |
| Product Type | Front-facing connectivity tray for an interactive display |
| Operating Time | Powered by the display — no separate supply |
| Platform | None — the display supplies the platform |
| Local Warranty (Singapore) | Supplied by SourceIT with GST invoice |
Compatibility
| Compatible Displays | Samsung WM55B (55") and WM65B (65") only |
| Attachment | Can be removed or mounted at any time |
| HDMI | 1 |
| USB-C | 1 |
| USB-A | 2 |
| USB-B | 1 |
| USB-B Touch Out | 1 |
Physical
| Dimensions (set) | 269.8 x 111.3 x 56.9 mm (W x H x D) |
| Dimensions (package) | 294 x 136 x 69 mm (W x H x D) |
| Weight (set) | 0.5 kg |
| Weight (package) | 0.7 kg |
| Colour | Grey white |
Installation
The tray attaches to the front of the WM55B or WM65B and is supplied with an installation guide and screws. There is no wall work and no separate power supply — it draws from the display. Samsung specifies that it can be removed or mounted at any time, so it can follow a board that moves between rooms, or between a stand and a wall mount, without a rebuild. Allow for the 56.9 mm it projects from the face of the display if the board sits inside a tight joinery recess.
What it pairs with
This tray fits the Samsung Flip Pro 55" (LH55WMBWBGCXXS) and the Samsung WM65B Flip Pro 65". It does not fit the earlier WM55R or WM65R boards — those take the CY-TF65BRC tray instead.
Specifications are taken from Samsung's published product data for this model. Where Samsung does not publish a figure for this exact model it has been left out rather than estimated.
Package Contents & Samsung Flip Accessory Range
In the box
- Installation Guide
- Screws
Package contents follow Samsung's product data for this model; items not listed by Samsung are not claimed here.
Samsung Flip accessory range
| Model | Size | Fits |
| STN-WM55R | 55" | Flip 2 WM55R — mobile stand |
| WMN-WM65R | 65" | Flip 2 WM65R — fixed wall mount |
| CY-TF65BRC | 55" / 65" | Flip 2 WM55R and WM65R — connectivity tray |
| CY-TF65BBC (this listing) | 55" / 65" | Flip WM55B and WM65B — connectivity tray |
Datasheet & Downloads
Samsung does not publish a dedicated Singapore product page for the CY-TF65BBCXXS, so the link above is to Samsung's product page for the same tray. SourceIT can email the current accessory data sheet revision with a quotation, and can quote the board and the tray together as one package.
Frequently Asked Questions — Samsung CY-TF65BBC
Which displays does this tray fit?
Samsung states it is compatible only with the WM55B and WM65B. It does not fit the earlier WM55R or WM65R boards, which take the CY-TF65BRC tray. Check the model on the back of the board before ordering.
What ports does it add?
One HDMI, one USB-C, two USB-A, one USB-B and one USB-B touch out, all on the front of the display within easy reach.
Can a guest present over a single USB-C cable?
USB-C is provided on the tray, which is the port most current laptops use for a one-cable connection. HDMI is there as well for machines without USB-C, so you do not need a drawer of adapters in the room.
What does the touch out port do?
The USB-B touch out sends touch input from the board's glass back to a connected laptop, so a presenter can annotate and click on the screen while driving their own machine.
Does it need its own power supply?
No. The tray draws power from the display, so there is no extra plug and no extra cable to route into the room.
Can I take it off again later?
Yes. Samsung specifies that the tray can be removed or mounted at any time, so it can move with a board that is transferred between rooms or between a stand and a wall mount.
How far does it project from the board?
The tray is 56.9 mm deep, so allow for that if the display sits inside a tight joinery recess or a shallow wall niche.
What warranty and invoicing do I get?
Every CY-TF65BBC sold by SourceIT comes with local Singapore warranty and a GST invoice on every unit, which is what your finance and procurement teams need for claims and for local service.
