Epson EB-810E Extreme Short Throw 4K Laser Projector
PRODUCT DESCRIPTION
Epson EB-810E Extreme Short Throw 4K Enhancement Laser Projector (V11HA99080) - 3 Years Singapore Local Warranty
A 160-Inch Display From Centimetres off the Wall — 4.5 Times a 75-Inch Panel
Extreme short throw is a step beyond ultra-short throw: with a throw ratio of 0.16 to 0.22, the EB-810E sits just centimetres from the wall and still produces an image up to 160 inches diagonal, which Epson rates at 4.5 times the area of a 75-inch flat panel. For a Singapore classroom, hybrid meeting room or retail space, that means an enormous, glare-free display without surrendering any floor depth and without a single person in the room standing in the beam. Epson's Setting Assistant app shortens commissioning considerably.
5,000 Lumens of 1080p With 4K Enhancement for Detail at Scale
Epson specifies 5,000 lumens of colour and white brightness, dropping to 3,500 lumens in Extended mode, with a dynamic contrast ratio of over 5,000,000:1. The image is 1080p with Epson's 4K Enhancement pixel-shifting technology, which sharpens perceived detail at the very large image sizes this projector is built for — important when a 160-inch display would otherwise show every soft edge. Frame interpolation, noise reduction and the image preset modes round out the processing for both presentation material and video.
Native 16:9 Plus 16:10, 21:9 and 16:6 for Hybrid Meeting Layouts
The projector is natively 16:9 but also supports 16:10, 21:9 and 16:6 display ratios with built-in split-screen and multi-device casting. In a hybrid meeting room that means a video call on one part of the wall and shared content on the other, sized properly rather than letterboxed. Eight colour modes are available including Presentation, Cinema, Natural, Blackboard, DICOM SIM, Multi-Projection and Face Brightness — the last of which is aimed squarely at keeping remote participants' faces well lit and readable.
HDBaseT, HDMI Out and 20,000 Hours of Laser for Permanent Installation
Two HDCP 2.3 HDMI inputs, an HDBaseT input and an HDMI output let the projector sit at the end of a long structured cable run and still pass video onward to a second display. Wired LAN, RS-232C and built-in wireless LAN cover control and casting. The laser diode light source is rated at 20,000 hours in Normal mode and 30,000 hours in Extended mode, with a 20,000-hour air filter cycle, so a permanently mounted unit needs minimal attention across its service life.
Epson EB-810E Datasheet — Technical Specifications
General
| Product | Epson EB-810E Extreme Short Throw 4K Enhancement Laser Projector |
| Part Number (SKU) | V11HA99080 |
| GTIN | 8715946705148 |
| Projector Type | Extreme short throw laser projector |
| Projection Technology | 3LCD, RGB liquid crystal shutter projection system |
| Interactivity | Not an interactive model — no pen or finger touch |
| Local Warranty (Singapore) | Supplied by SourceIT with GST invoice |
Projection & Optics
| Resolution | 1080p with 4K Enhancement |
| Native Aspect Ratio | 16:9; also supports 16:10, 21:9 and 16:6 |
| White Light Output (Normal / Extended) | 5,000 lm / 3,500 lm |
| Colour Light Output | 5,000 lm |
| Contrast Ratio | Over 5,000,000:1 |
| Maximum Image Size | Up to 160 inches |
| Screen Size (Zoom Wide) | 80" – 160" [27.8 – 57.8 cm] @ 16:9; 74" – 148" @ 16:10; 76" – 151" @ 21:9; 75" – 148" @ 16:6; 66" – 130" @ 4:3 |
| Screen Size (Zoom Tele) | 60" – 118" [28.2 – 57.5 cm] @ 16:9 |
| Lens Type | Manual focus |
| Throw Ratio | 0.16 – 0.22 (wide to tele) |
| F-Number / Focal Length | 1.8 / 2.3 mm |
| Digital Zoom Ratio | 1 – 1.35 |
| Quick Corner | Yes |
| Image Adjustment | 4K Enhancement, image preset mode, noise reduction, frame interpolation |
| Colour Modes | Dynamic, Presentation, Cinema, Natural, Blackboard, DICOM SIM, Multi-Projection, Face Brightness |
Light Source
| Type | Laser diode |
| Light Source Life (Normal / Extended) | 20,000 / 30,000 hours |
| Start-Up Period | Less than 6 seconds (Epson logo); warm-up period less than 30 seconds; quick start-up less than 12 seconds to display |
| Cool Down Period | Instant Off |
Connectivity
| Digital Input | HDMI x 2 (HDCP 2.3); HDBaseT x 1 (HDCP 2.3) |
| Digital Video Output | HDMI x 1 (HDCP 2.3) |
| Control I/O | RS-232C x 1 (D-Sub 9-pin) |
| USB | Type A x 2 (port 1 for PC Free, firmware update, copy OSD settings and the ELPAP11 module; port 2 for PC Free, firmware update, copy OSD settings or 5 V / 2 A power supply); Type B x 1 (firmware update, copy OSD settings) |
| Wired Network | Wired LAN x 1 (RJ45) |
| Wireless Network | Wireless LAN in-built, with optional module supported via USB Type A port 1 |
| Wireless Standards | IEEE 802.11a/b/g/n/ac; infrastructure and Access Point (Wi-Fi Direct); Screen Mirroring |
Audio & Features
| Internal Speakers | 8 W x 8 W stereo |
| Direct Power On / Off | Yes |
| Collaboration | Built-in split screen and multi-device casting support |
| Installation Aid | Epson Setting Assistant app |
Physical & Environmental
| Weight | Approx. 12.5 kg |
| Dimensions Excluding Feet (D x W x H) | 341 x 695 x 145 mm |
| Air Filter | Electrostatic filter; maintenance cycle 20,000 hours (Normal) |
| Fan Noise (Normal / Eco) | 35 dB / 26 dB |
| Operating Temperature | Low altitude (0 – 2,286 m): 0 – 40 °C; high altitude (over 2,286 m): 0 – 35 °C; 20% – 80% humidity, no condensation |
| Operating Altitude | Up to 3,048 m with High Altitude Mode |
Power
| Power Consumption (Laser Diode On, Normal / Quiet or Extended) | 380 W / 286 W |
| Power Supply Voltage | 100 – 240 V AC ±10%, 50/60 Hz |
Specifications are taken from Epson's published product data for this model. Where Epson does not publish a figure for this exact model it has been left out rather than estimated.
Compatibility & Installation
Mounting and placement
The EB-810E measures 341 x 695 x 145 mm excluding feet and weighs approximately 12.5 kg, so it needs a properly specified wall mount and structural fixing — this is a fixed installation product. With a throw ratio of 0.16 to 0.22 it sits just centimetres from the wall, which makes the flatness and finish of the projection surface critical: a coated projection wall or a rigid matte board will look far better than a fabric screen, and gloss surfaces will hot-spot badly at this angle of incidence. With the optional wall mount, an existing whiteboard can be converted into a display surface.
Commissioning with the Setting Assistant app
Epson's Setting Assistant app guides alignment and geometry setup, which materially shortens installation at this throw ratio where small mounting errors produce visible keystone and focus differences across the image. Quick Corner is available for final geometry correction once the projector is physically positioned.
What it connects to
Two HDCP 2.3 HDMI inputs cover a room PC and a visiting laptop or video bar, while the HDBaseT input lets a source rack sit a long structured-cable run away — the normal arrangement in a permanent meeting room or retail installation. The HDMI output passes video onward to a second display or a confidence monitor. Two USB Type A ports handle PC Free playback, firmware updates and the wireless module, with the second port also able to supply 5 V / 2 A to a streaming stick. RS-232C is available for control systems.
Network, wireless and collaboration
Wired LAN over RJ45 supports centralised monitoring and control. Wireless LAN is in-built, with an optional module also supported through USB Type A port 1, and the projector supports IEEE 802.11a/b/g/n/ac in both infrastructure and Wi-Fi Direct modes along with Screen Mirroring. Built-in split screen and multi-device casting let more than one participant contribute to the display, which is the point of the 21:9 and 16:6 ratios in a hybrid meeting room.
Related models on our store
The companion extreme short throw model is the Epson EB-815E. For ultra-short throw signage at 5,000 lumens, see the Epson EB-800F and Epson EB-805F. For classroom ultra-short throw, see the Epson EB-770F.
Package Contents & Epson Extreme Short Throw Range
In the box
- Epson EB-810E extreme short throw laser projector
- Power cable
- Remote control with batteries
- Printed documentation
Package contents follow Epson's product data for this model; items not listed by Epson are not claimed here. The wall mount is an optional accessory and is not included.
Epson 7xx and 8xx ultra-short and extreme short throw laser range
| Model | Resolution, brightness and interactivity |
| EB-725W | WXGA, 4,000 lm — not interactive |
| EB-725Wi | WXGA, 4,000 lm — pen interactive, finger touch optional |
| EB-735F | Full HD, 3,600 lm — not interactive |
| EB-760W | WXGA, 4,100 lm — not interactive, up to 150" |
| EB-760Wi | WXGA, 4,100 lm — interactive up to 100", Finger Touch Unit supported |
| EB-770F | Full HD, 4,100 lm — not interactive, up to 150" |
| EB-770Fi | Full HD, 4,100 lm — interactive up to 100", Finger Touch Unit supported |
| EB-800F | Full HD, 5,000 lm — ultra-short throw signage, HDBaseT, up to 130" |
| EB-805F | Full HD, 5,000 lm — ultra-short throw signage, HDBaseT, up to 130" |
| EB-810E (this listing) | 1080p with 4K Enhancement, 5,000 lm — extreme short throw, up to 160" |
| EB-815E | 1080p with 4K Enhancement, 5,000 lm — extreme short throw, up to 160" |
Datasheet & Downloads
- Epson Singapore — EB-810E Extreme Short Throw 4K Enhancement Laser Projector product page and full specifications
- Epson Singapore — EB-810E support, drivers and manuals
SourceIT can email the current data sheet revision on request together with a quotation.
Frequently Asked Questions — Epson EB-810E
What is the difference between the EB-810E and the EB-815E?
We checked this against Epson Singapore's own published data rather than assuming, and the honest answer is that Epson publishes an identical specification set for both models: same 5,000 lumens, same 1080p with 4K Enhancement, same over 5,000,000:1 contrast, same 0.16 – 0.22 throw ratio and 160-inch maximum image, same two HDMI inputs plus HDBaseT and HDMI output, same in-built and optional wireless LAN arrangement, same 12.5 kg body and same 341 x 695 x 145 mm dimensions. They are supplied under different part numbers — V11HA99080 for the EB-810E and V11HA99180 for the EB-815E. If your specification, tender or site standard names one part number, tell us which and we will quote exactly that.
Is this a native 4K projector?
No, and it is important to be clear about this. Epson describes it as 1080p with 4K Enhancement — a pixel-shifting technology that increases perceived detail beyond native Full HD. It is not a native 4K panel. At the very large image sizes this projector is designed for, 4K Enhancement makes a visible difference to sharpness, but it should not be specified as native 4K in a tender response.
What does "extreme short throw" actually buy me over ultra-short throw?
Distance and size. The throw ratio is 0.16 to 0.22, compared with roughly 0.27 to 0.37 on Epson's ultra-short throw models, so the projector sits closer to the wall and still reaches 160 inches instead of 130 or 150. In a room where every centimetre of floor depth is contested, or where the mount has to be tight to the wall above a whiteboard, that difference is the reason to choose this model.
Is it interactive?
No. The EB-810E is a display projector with no pens and no touch unit. If you need writing and annotation on the projected image, look at the interactive EB-770Fi or EB-760Wi instead.
Why does it support 21:9 and 16:6 as well as 16:9?
Because hybrid meetings need two things on the wall at once. An ultra-wide ratio with split screen lets a video call sit beside shared content at a sensible size rather than one shrinking the other. The Face Brightness colour mode is aimed at the same use case, keeping remote participants' faces well lit rather than silhouetted.
Does it have built-in Wi-Fi?
Yes. Epson's specification for this model lists wireless LAN as in-built, with an optional module also supported through USB Type A port 1. It covers IEEE 802.11a/b/g/n/ac in both infrastructure and Wi-Fi Direct modes and supports Screen Mirroring. Wired LAN over RJ45 is also provided for centralised monitoring and control.
How much does it weigh and what mount does it need?
Approximately 12.5 kg, with a body of 341 x 695 x 145 mm excluding feet. That requires a properly specified wall mount fixed into structure, not plasterboard alone. Factor commissioning time in as well: at a 0.16 throw ratio, small mounting errors show up clearly, which is why Epson provides the Setting Assistant app to guide alignment.
What warranty and paperwork comes with it?
Every unit sold by SourceIT carries local Singapore warranty and is invoiced with a GST invoice. Support and warranty claims are handled locally rather than through an overseas grey-market channel.
