J5Create JCD384 USB-C Multi Adapter (10 Functions in 1)
PRODUCT DESCRIPTION
J5Create JCD384 USB-C Multi Adapter (10 Functions in 1) - 2 Years Local Warranty
A compact USB-C mini dock that adds display, data and charging ports to a laptop, small enough to carry between desk and meeting room.
Key Features
- One display via 4K HDMI (30 Hz) or VGA (1080p 60 Hz)
- Gigabit Ethernet plus three USB-A 5Gbps ports, one with BC 1.2 fast charging
- SD and microSD card reader
- USB-C PD 3.0 pass-through charging up to 60W
- Aluminium enclosure in silver
Equipping a team or office? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
j5create JCD384 Datasheet — Technical Specifications
General
| Local Warranty (Singapore) | 2-year limited warranty (j5create), supplied by SourceIT with a GST invoice |
| Brand | j5create |
| Model | JCD384 |
| Product Name | USB-C Multi Adapter (10 Functions in 1) |
| EAN | 4712795081954 |
Hardware
| Host connector | 1 x USB-C male |
| Ports | 1 x USB-C 3.0 (power delivery and data); 2 x USB-A 3.1 Gen 1; 1 x USB-A 3.1 Gen 1 with BC 1.2; 1 x SD/microSD slot; 1 x 4K HDMI; 1 x VGA; 1 x RJ45 Gigabit Ethernet |
| Video output | 1 x HDMI female; 1 x VGA female |
| Network interface | RJ45 Gigabit Ethernet (10/100/1000 Mbps) |
| Audio | 2.1 channel via HDMI |
| Power source | Bus-powered or self-powered |
Performance
| Displays supported | 1 (HDMI or VGA) |
| Max resolution | HDMI 3840 x 2160 @ 30 Hz; VGA 1920 x 1080 @ 60 Hz |
| Max data transfer rate | 5 Gbps |
Power
| Power delivery | Up to 60W via USB-C (PD 3.0, backward compatible with PD 2.0) |
| Input | Up to 20V / up to 5A |
| Output | Up to 20V / up to 4.25A |
Physical
| Cable length | 137 mm (5.4 in) |
| Colour | Silver |
| Enclosure | Aluminium |
| Dimensions (H x W x D) | 120 x 50 x 16.5 mm (4.72 x 1.97 x 0.65 in) |
| Weight | 88 g (3.1 oz) |
| Operating temperature | 0 to 48°C (32 to 118°F) |
| Storage temperature | -10 to 65°C (14 to 149°F) |
| Humidity | < 85% non-condensing |
Compatibility & System Requirements
System Requirements
- Available USB-C port supporting DisplayPort Alt Mode and USB Power Delivery 2.0 or 3.0
Package Contents & j5create USB-C Mini Docks Ordering Information
In the Box
- 1 x JCD384 USB-C 10-in-1 Multi Adapter
- 1 x Quick Installation Guide
j5create USB-C Mini Docks at SourceIT
| Model | Product |
| JCH471 | USB-C Multi-Adapter Gigabit Ethernet / USB 3.1 HUB |
| JCD353 | USB-C to 4K HDMI Multi-Port Hub |
| JCD371 | USB-C to HDMI & USB 3.1 2-Port with Power Delivery |
| JCD373 | USB-C Multi-Port Hub with Power Delivery |
| JCD373EW | USB-C Multi-Port Hub with Power Delivery |
| JCD376 | USB-C Multiport Adapter with Power Delivery |
| JCD381 | USB-C Dual HDMI Mini Dock |
| JCD383 | USB-C Multi Adapter (9 Functions in 1) |
| JCD384 (this listing) | USB-C Multi Adapter (10 Functions in 1) |
| JCD392 | 4K60 Elite USB-C 10Gbps Travel Dock |
| JCD396 | USB-C Dual HDMI 4K60 Mini Dock |
| JCD397 | 4K60 Elite USB-C Triple-Monitor 10Gbps Mini Dock |
| JCD398 | USB-C Dual 4K HDMI 10Gbps Mini Dock |
| JCH462 | Wormhole Switch Display Sharing Hub |
Datasheet & Downloads
| j5create product page | JCD384 on j5create.com |
| Quick Install Guide (JCD383/JCD384) | Quick Install Guide (JCD383/JCD384) (PDF) |
| Downloads & Drivers page | Downloads & Drivers page |
Need a document sent directly? Email sales@sourceit.com.sg quoting JCD384.
Frequently Asked Questions — j5create JCD384
How many external displays does it support?
1 (HDMI or VGA). Actual output depends on your laptop's USB-C / Thunderbolt video support; see the Compatibility section.
How much charging power reaches my laptop?
Up to about 85W, based on j5create’s published output rating, when a suitable USB-C PD power adapter is connected (adapter sold separately unless listed in the box).
What warranty do I get?
2-year limited warranty from j5create, supplied locally in Singapore by SourceIT with a GST invoice.
Can SourceIT quote for bulk or corporate orders?
Yes. Email sales@sourceit.com.sg quoting JCD384 and the quantity for volume pricing and delivery lead time.
