J5Create JCD353 USB-C to 4K HDMI Multi-Port Hub
Shipping calculated at checkout.
PRODUCT DESCRIPTION
J5Create JCD353 USB-C to 4K HDMI Multi-Port Hub - 2 Years Local Warranty
A compact USB-C mini dock that adds display, data and charging ports to a laptop, small enough to carry between desk and meeting room.
Key Features
- 6-in-1 hub with HDMI 4K output (mirror or extend)
- Two 5Gbps USB-A ports plus SD/microSD 3.0 UHS-I reader (up to 104 MB/s)
- USB-C PD pass-through charging up to 100W
- Bus-powered, plug-and-play aluminium design
Equipping a team or office? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
j5create JCD353 Datasheet — Technical Specifications
General
| Local Warranty (Singapore) | 2-year limited warranty (j5create), supplied by SourceIT with a GST invoice |
| Brand | j5create |
| Model | JCD353 |
| Product Name | USB-C to 4K HDMI Multi-Port Hub |
| EAN | 4712795086485 |
Video Output
| HDMI | 1x HDMI female, 4K |
| Max Resolution | 3840 x 2160 @ 30Hz |
| Max Refresh Rate | 1920 x 1080 @ 60Hz |
| Displays Supported | 1 |
| Display Modes | Mirror or extend |
| Audio Channel | 2.1 via HDMI |
Ports
| Host Connector | 1x USB-C male |
| USB-A | 2x USB Type-A 3.2 Gen 1 (5Gbps) |
| Card Reader | 1x SD/microSD 3.0 UHS-I (up to 104 MB/s) |
| USB-C PD | 1x USB-C Power Delivery, up to 100W |
| Max Data Transfer Rate | 5 Gbps |
Power
| Power Source | Bus-powered |
| Power Delivery | Up to 100W via USB-C (requires USB-C power adapter) |
| Power Consumption | ≤ 500 mA |
Compatibility
| Host | USB-C devices supporting DisplayPort Alt Mode, incl. tablets and phones |
| Backward Compatibility | USB 3.0 |
| External Storage | Up to 2 TB |
| Driver | Plug-and-play, no installation required |
Physical
| Dimensions | 112.20 x 29.80 x 10.41 mm (4.42 x 1.17 x 0.41 in) |
| Weight | 48 g (1.69 oz) |
| Cable Length | 170 mm (6.69 in) per spec table |
| Colour | Space Gray |
| Enclosure | Aluminium, ABS plastic |
| Operating Temperature | -1 to 41°C |
| Storage Temperature | -17 to 68°C (0 to 155°F) |
| Operating / Storage Humidity | < 85% non-condensing |
Compatibility & System Requirements
System Requirements
- Available DisplayPort Alt Mode over USB-C port
- Available USB Power Delivery over USB-C to support upstream charging
- 4K-capable display required for 3840x2160
Compatibility
| Host | USB-C devices supporting DisplayPort Alt Mode, incl. tablets and phones |
| Backward Compatibility | USB 3.0 |
| External Storage | Up to 2 TB |
| Driver | Plug-and-play, no installation required |
Package Contents & j5create USB-C Mini Docks Ordering Information
In the Box
- 1x JCD353 USB-C to 4K HDMI Multi-Port Hub
- 1x Quick Installation Guide (QIG)
j5create USB-C Mini Docks at SourceIT
| Model | Product |
| JCH471 | USB-C Multi-Adapter Gigabit Ethernet / USB 3.1 HUB |
| JCD353 (this listing) | USB-C to 4K HDMI Multi-Port Hub |
| JCD371 | USB-C to HDMI & USB 3.1 2-Port with Power Delivery |
| JCD373 | USB-C Multi-Port Hub with Power Delivery |
| JCD373EW | USB-C Multi-Port Hub with Power Delivery |
| JCD376 | USB-C Multiport Adapter with Power Delivery |
| JCD381 | USB-C Dual HDMI Mini Dock |
| JCD383 | USB-C Multi Adapter (9 Functions in 1) |
| JCD384 | USB-C Multi Adapter (10 Functions in 1) |
| JCD392 | 4K60 Elite USB-C 10Gbps Travel Dock |
| JCD396 | USB-C Dual HDMI 4K60 Mini Dock |
| JCD397 | 4K60 Elite USB-C Triple-Monitor 10Gbps Mini Dock |
| JCD398 | USB-C Dual 4K HDMI 10Gbps Mini Dock |
| JCH462 | Wormhole Switch Display Sharing Hub |
Datasheet & Downloads
| j5create product page | JCD353 on j5create.com |
| Quick Install Guide (PDF) | Quick Install Guide (PDF) (PDF) |
| Downloads & Drivers (general) | Downloads & Drivers (general) |
Need a document sent directly? Email sales@sourceit.com.sg quoting JCD353.
Frequently Asked Questions — j5create JCD353
Does it need a driver?
Plug-and-play, no installation required
How many external displays does it support?
1. Actual output depends on your laptop's USB-C / Thunderbolt video support; see the Compatibility section.
What warranty do I get?
2-year limited warranty from j5create, supplied locally in Singapore by SourceIT with a GST invoice.
Can SourceIT quote for bulk or corporate orders?
Yes. Email sales@sourceit.com.sg quoting JCD353 and the quantity for volume pricing and delivery lead time.
