J5Create JCD373 USB-C Multi-Port Hub with Power Delivery
Shipping calculated at checkout.
PRODUCT DESCRIPTION
J5Create JCD373 USB-C Multi-Port Hub with Power Delivery - 2 Years Local Warranty
A compact USB-C mini dock that adds display, data and charging ports to a laptop, small enough to carry between desk and meeting room.
Key Features
- Single USB-C connection adds HDMI output up to 4K at 30 Hz, mirror or extend
- Pass-through charging up to 60W via USB-C Power Delivery 3.0
- Two USB-A 5Gbps ports plus SD and microSD card reader
- 3.5mm audio/mic combo jack
- Plug-and-play, no driver needed
Equipping a team or office? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
j5create JCD373 Datasheet — Technical Specifications
General
| Local Warranty (Singapore) | 2-year limited warranty (j5create), supplied by SourceIT with a GST invoice |
| Brand | j5create |
| Model | JCD373 |
| Product Name | USB-C Multi-Port Hub with Power Delivery |
| EAN | 4712795086027 |
Hardware
| Host connector | 1 x USB-C 3.1 male |
| Ports | 2 x USB Type-A 3.1 Gen 1; 1 x USB-C (PD 3.0 charging); 1 x microSD and SD card reader/writer; 1 x HDMI; 1 x 3.5 mm audio/mic combo jack |
| Video output | 1 x HDMI female |
| Audio | 3.5 mm audio/mic combo jack |
| Power source | Bus-powered or self-powered |
Performance
| Displays supported | 1 |
| Max display resolution | 3840 x 2160 |
| Max refresh rate | 30 Hz |
| Max data transfer rate | 5 Gbps |
| Card reader | SD 3.0 UHS-I, up to 104 MB/s |
Power
| Power delivery | Up to 60W via USB-C (PD 3.0) |
| Input | Up to 20V / up to 3A |
| Output | Up to 20V / up to 3A |
| Power consumption | ≤ 400 mA |
Physical
| Cable length | 150 mm (5.9 in) |
| Colour | White |
| Enclosure | ABS plastic |
| Dimensions (H x W x D) | 122 x 39 x 11 mm (4.8 x 1.53 x 0.43 in) |
| Weight | 51 g (1.8 oz) |
| Operating temperature | -1 to 41°C (30 to 116°F) |
| Storage temperature | -17 to 68°C (0 to 155°F) |
| Humidity | < 85% non-condensing |
Compatibility & System Requirements
System Requirements
- Available USB-C port supporting DisplayPort Alt Mode and USB Power Delivery 2.0 or 3.0
- 4K-capable display needed for 3840 x 2160
- Attach USB-C power adapter to the PD port when using high-powered USB devices, and keep it connected while copying files
- PD 3.0 recommended for maximum performance
Package Contents & j5create USB-C Mini Docks Ordering Information
In the Box
- 1 x JCD373 USB-C Multi-Port Hub with Power Delivery
- 1 x Quick Installation Guide
j5create USB-C Mini Docks at SourceIT
| Model | Product |
| JCH471 | USB-C Multi-Adapter Gigabit Ethernet / USB 3.1 HUB |
| JCD353 | USB-C to 4K HDMI Multi-Port Hub |
| JCD371 | USB-C to HDMI & USB 3.1 2-Port with Power Delivery |
| JCD373 (this listing) | USB-C Multi-Port Hub with Power Delivery |
| JCD373EW | USB-C Multi-Port Hub with Power Delivery |
| JCD376 | USB-C Multiport Adapter with Power Delivery |
| JCD381 | USB-C Dual HDMI Mini Dock |
| JCD383 | USB-C Multi Adapter (9 Functions in 1) |
| JCD384 | USB-C Multi Adapter (10 Functions in 1) |
| JCD392 | 4K60 Elite USB-C 10Gbps Travel Dock |
| JCD396 | USB-C Dual HDMI 4K60 Mini Dock |
| JCD397 | 4K60 Elite USB-C Triple-Monitor 10Gbps Mini Dock |
| JCD398 | USB-C Dual 4K HDMI 10Gbps Mini Dock |
| JCH462 | Wormhole Switch Display Sharing Hub |
Datasheet & Downloads
| j5create product page | JCD373 on j5create.com |
| Quick Install Guide | Quick Install Guide (PDF) |
| Downloads & Drivers page | Downloads & Drivers page |
Need a document sent directly? Email sales@sourceit.com.sg quoting JCD373.
Frequently Asked Questions — j5create JCD373
How many external displays does it support?
1. Actual output depends on your laptop's USB-C / Thunderbolt video support; see the Compatibility section.
How much charging power reaches my laptop?
Up to about 60W, based on j5create’s published output rating, when a suitable USB-C PD power adapter is connected (adapter sold separately unless listed in the box).
What warranty do I get?
2-year limited warranty from j5create, supplied locally in Singapore by SourceIT with a GST invoice.
Can SourceIT quote for bulk or corporate orders?
Yes. Email sales@sourceit.com.sg quoting JCD373 and the quantity for volume pricing and delivery lead time.
