Dell UltraSharp 30 U3023E 30" WQXGA USB-C Hub Monitor
PRODUCT DESCRIPTION
Dell UltraSharp 30 USB-C Hub Monitor U3023E (210-BEBI) - 3 Years Local Warranty
30-inch 16:10 WQXGA workspace
A 30-inch IPS panel at 2560 x 1600 gives you extra vertical room over 16:9 screens, with 178° viewing angles and a 3H anti-glare coating.
Colour you can rely on
Covers 100% sRGB and 95% DCI-P3 with 1.07 billion colours, and is factory calibrated to Delta E < 2.
One-cable USB-C hub
USB-C with DisplayPort 1.4 Alt Mode and 90 W Power Delivery, plus RJ45 Ethernet and a USB 3.2 Gen 2 hub with four USB-A ports and a 15 W USB-C port.
Equipping a team or office? Email sales@sourceit.com.sg for volume pricing, delivery lead time and availability of current Dell successors.
Dell U3023E Datasheet — Technical Specifications
Display
| Screen size | 30" (viewable 30") |
| Panel type | IPS, LED-backlit LCD / TFT active matrix |
| Aspect ratio | 16:10 |
| Native resolution | WQXGA 2560 x 1600 at 60 Hz |
| Pixel pitch | 0.2505 mm |
| Pixels per inch | 101.4 PPI |
| Brightness | 400 cd/m² |
| Contrast ratio | 1000:1 (typical) / 1000:1 (dynamic) |
| Colour support | 1.07 billion colours |
| Colour gamut | 100% sRGB, 95% DCI-P3 |
| Factory calibration | Delta E < 2 |
| Response time | 8 ms grey-to-grey (Normal); 5 ms grey-to-grey (Fast) |
| Viewing angle | 178° horizontal / 178° vertical |
| Screen coating | Anti-glare, 3H hard coating |
| Built-in speakers | No |
Connectivity
| HDMI | 1 x HDMI (HDCP 1.4) |
| DisplayPort in | 1 x DisplayPort 1.4 |
| DisplayPort out | 1 x DisplayPort output |
| USB-C upstream (video + power) | 1 x USB-C, DisplayPort 1.4 Alt Mode with Power Delivery up to 90 W (HDCP 2.2) |
| USB-C upstream (data) | 1 x USB-C 3.2 Gen 2 upstream |
| USB-C downstream | 1 x USB-C 3.2 Gen 2 (power up to 15 W) |
| USB-A downstream | 3 x USB 3.2 Gen 2 |
| USB-A downstream with charging | 1 x USB 3.2 Gen 2 with Battery Charging 1.2 |
| Ethernet | 1 x RJ45 LAN |
| Audio | 1 x audio line-out (3.5 mm mini-jack) |
| USB Power Delivery | 90 W |
Ergonomics
| Adjustments | Height, tilt, swivel, pivot (rotation) |
| Height adjustment | 150 mm |
| Tilt | -5° / +21° |
| Swivel | -30° / +30° |
| VESA mount | 100 x 100 mm |
| Security | Security lock slot (cable lock sold separately) |
Power
| Input voltage | AC 100-240 V (50/60 Hz) |
| Power consumption (on mode) | 26.6 W |
| Energy consumption SDR (on mode) | 26.6 kWh/1000h |
| Power consumption (max) | 210 W |
| Standby | 0.3 W |
| Off mode | 0.2 W |
| Energy class | F |
| On/off switch | Yes |
Physical
| Dimensions with stand (lowest position, W x D x H) | 65.59 x 23.0 x 47.27 cm |
| Dimensions without stand (W x D x H) | 65.59 x 5.3 x 41.86 cm |
| Weight with stand | 11.13 kg |
| Weight without stand | 6.48 kg |
| Shipping weight | 15.05 kg |
| Operating temperature | 0 °C to 40 °C |
| Operating humidity | 10% to 80% (non-condensing) |
Certifications
| Environmental | EPEAT Gold, ENERGY STAR certified |
| Compliance | RoHS, BFR-free, PVC-free, halogen-free |
| Materials | Mercury-free, arsenic-free glass |
Warranty
| Local Warranty (Singapore) | Dell Singapore: 3-Year Advanced Exchange Service and Premium Panel Exchange; supplied by SourceIT with a GST invoice |
Compatibility & Software Support
PC connection
Connect desktops and laptops via HDMI, DisplayPort 1.4 or USB-C (DP 1.4 Alt Mode). A DisplayPort output port is also provided.
USB-C laptops
A single USB-C cable carries video, USB data and up to 90 W of charging power to a compatible laptop, with network access through the monitor's RJ45 port.
Mounting
The stand adjusts for height (150 mm), tilt, swivel and pivot, and the panel supports 100 x 100 mm VESA mounting.
Package Contents & Dell UltraSharp Monitors Ordering Information
In the Box
Monitor with 1 x power cable, 1 x DisplayPort cable (DP to DP, 1.8 m), 1 x SuperSpeed USB cable (Type-A to Type-C) and 1 x USB Type-C cable (C to C, 1 m), as listed by Dell.
Dell UltraSharp Monitors
| Model | Key feature |
| U2421E | 24.1" WUXGA 16:10, USB-C 90 W, RJ45 |
| U2422H | 24" FHD IPS, USB hub |
| U2422HE | 24" FHD IPS, USB-C 90 W, RJ45 |
| U2424H | 24" FHD 120 Hz, USB hub |
| U2424HE | 24" FHD 120 Hz, USB-C 90 W, RJ45 |
| U2520D | 25" QHD IPS, USB-C 90 W |
| U2722D | 27" QHD IPS, USB hub |
| U2722DE | 27" QHD IPS, USB-C 90 W, RJ45 |
| U2723QE | 27" 4K IPS Black, USB-C 90 W, RJ45 |
| U2724D | 27" QHD IPS Black 120 Hz |
| U2724DE | 27" QHD 120 Hz, Thunderbolt 4 90 W |
| U2725QE | 27" 4K 120 Hz, Thunderbolt 4 |
| U3023E (this listing) | 30" WQXGA 16:10, USB-C 90 W, RJ45 |
| U3223QE | 31.5" 4K IPS Black, USB-C 90 W, RJ45 |
| U3224KB | 32" 6K, Thunderbolt 4, webcam |
| U3225QE | 32" 4K 120 Hz, Thunderbolt 4 |
| U3226Q | 32" 4K QD-OLED |
Datasheet & Downloads
| User guide | Dell U3023E Monitor User's Guide (PDF) |
| Dell Singapore | U3023E on dell.com/en-sg |
| Manuals & drivers | U3023E on Dell Support (Singapore) |
| Warranty | Dell Monitor Service & Warranty brochure (PDF) |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting U3023E.
Frequently Asked Questions — Dell U3023E
What is the resolution of the Dell U3023E?
2560 x 1600 (WQXGA) at 60 Hz on a 30-inch 16:10 IPS panel.
Can the U3023E charge my laptop over USB-C?
Yes. The USB-C upstream port supports DisplayPort 1.4 Alt Mode with Power Delivery up to 90 W.
Does the U3023E have an Ethernet port?
Yes, it has an RJ45 LAN port.
Does it have built-in speakers?
No. It has an audio line-out (3.5 mm mini-jack) for external speakers or headphones.
What warranty comes with the U3023E?
Dell Singapore: 3-Year Advanced Exchange Service and Premium Panel Exchange; supplied by SourceIT with a GST invoice.
