Dell UltraSharp 27 U2724DE 27" QHD Thunderbolt Hub Monitor
PRODUCT DESCRIPTION
Dell UltraSharp 27 Thunderbolt Hub Monitor U2724DE (210-BKMB) - 3 Years Local Warranty
Thunderbolt 4 hub
One Thunderbolt 4 cable delivers video, data and up to 90 W of laptop charging, with a Thunderbolt 4 downstream port for daisy chaining, 2.5GbE RJ45 and a built-in KVM.
IPS Black at 120 Hz
27-inch QHD with 2000:1 contrast, 350 cd/m2, 1.07 billion colours and 98% DCI-P3 coverage, factory calibrated to Delta E < 2.
5-star eye comfort
TÜV 5-star eye comfort certification with ComfortView Plus and an ambient light sensor, on a stand with height, tilt, swivel and pivot.
Equipping a team or meeting rooms? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
Dell U2724DE Datasheet — Technical Specifications
General
| Product Name | Dell UltraSharp 27 Thunderbolt Hub Monitor - U2724DE |
| Model | U2724DE |
| Dell SKU | 210-BKMB |
| Local Warranty (Singapore) | 3-Year Advanced Exchange Service and Premium Panel Exchange (Dell), supplied by SourceIT with a GST invoice |
Display
| Diagonal Size | 684.70 mm / 27.00 inches |
| Preset Display Area (H x V) | 596.74 mm x 335.66 mm / 23.49" x 13.22" / 200,301.74 mm² |
| Panel Type | IPS Black Technology |
| Display Screen Coating | Anti-Glare with 3H hardness |
| Maximum Preset Resolution | 2560 x 1440 at 120 Hz |
| Viewing Angle | 178° vertical / 178° horizontal |
| Pixel Pitch | 0.2331 mm x 0.2331 mm |
| Pixel Per Inch (PPI) | 108.97 |
| Contrast Ratio | 2000 to 1 (typical) |
| Aspect Ratio | 16:9 |
| Backlight Technology | LED Edgelight System |
| Brightness | 350 cd/m² (typical) |
| Response Time Details | 8 ms (Normal) / 5 ms (Fast) |
| HDR Ready | No |
| Ambient Light Sensor | Yes, auto brightness and color temperature adjustment |
| Color Support | 1.07 billion colors |
| Color Gamut | 100% sRGB, 100% BT.709, 98% Display P3, 98% DCI-P3, Delta E < 2 (average) |
Ports & Connectivity
| Port | 1 x DisplayPort 1.4 (DRR for Microsoft Windows) (Supports 2 x QHD 120Hz 8 bit) |
| Port | 1 x DisplayPort 1.4 (Out) |
| Port | 1 x HDMI (HDCP 1.4) (Supports up to QHD 2560 x 1440 120Hz TMDS, VRR as per specified in HDMI 2.1) |
| Port | 1 x Thunderbolt™ 4 downstream port (15W) for daisy chaining |
| Port | 1 x Thunderbolt™ 4 upstream port (Video + Data) Alternate mode with DisplayPort 1.4, power delivery up to 90W |
| Port | 1 x USB-Type C upstream port (data only) (SuperSpeed USB 10 Gbps, USB 3.2 Gen 2) |
| Port | 3 x USB Type-A downstream port (SuperSpeed USB 10 Gbps, USB 3.2 Gen 2) |
| Port | 1 x Audio line out |
| Port | 1 x RJ45 Ethernet port, 2.5GbE |
| Quick access port | 1 x USB Type-A downstream port (SuperSpeed USB 10 Gbps, USB 3.2 Gen 2) with BC1.2 power charging |
| Quick access port | 1 x USB Type-C downstream port (SuperSpeed USB 10 Gbps, USB 3.2 Gen 2) with power charging (15W) |
| Daisy Chain Availability | Yes |
| Keyboard, Video and Mouse (KVM) | Yes |
| PbP / PiP | Yes |
Ergonomics / Stand
| Height adjustable | 150 mm |
| Tilt | -5°/+21° |
| Swivel | -45°/+45° |
| Pivot | -90°/+90° |
| Flat Panel Mount Interface | VESA mounting holes (100 mm x 100 mm - behind attached VESA Cover) |
| Security | Security lock slot (cable lock sold separately) / Anti-theft stand lock slot |
Power
| Voltage Required | 100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 2.65 A (typical) |
| Power Consumption (On mode) | 24.4 W |
| Power Consumption (Max) | 225 W |
| Power Consumption Stand by | 0.5 W |
| Power Consumption (Off Mode) | 0.3 W |
| Networked standby mode | 1.5 W |
Dimensions & Weight
| Height with stand (Compressed ~ Extended) | 385.58 mm ~ 535.58 mm |
| Width with stand | 612.24 mm |
| Depth with stand | 192.28 mm |
| Height without stand | 352.51 mm |
| Width without stand | 612.24 mm |
| Depth without stand | 50.12 mm |
| Weight (panel only - for VESA mount) | 5.23 kg |
| Weight (with stand assembly and cables) | 7.37 kg |
| Weight (with packaging) | 10.21 kg |
Environmental Conditions
| Temperature Range Operating | 0°C to 40°C (32°F to 104°F) |
| Temperature Range Non-operating | –20°C to 60°C (–4°F to 140°F) |
| Humidity Range Operating | 10% to 80% (non-condensing) |
| Humidity Range Non-Operating | 5% to 90% (non-condensing) |
| Altitude Operating | 5000 m (16404 ft) max |
| Altitude Non-Operating | 12192 (40000 ft) max |
Eye Comfort
| TÜV | TÜV 5-star eye comfort certification |
| ComfortView Plus | ComfortView Plus reduces harmful blue light emissions to less than 35% without sacrificing color performance |
Compliance / Certifications
| Compliant Standards | ENERGY STAR certified Monitor; EPEAT registered where applicable; TCO Certified & TCO Certified Edge; RoHS Compliant; BFR/PVC Free monitor (excluding external cables); Arsenic-Free glass and Mercury-Free for the panel only |
Software
| Dell Display Manager Compatibility | Yes, Easy Arrange, Other key features |
Compatibility & Software Support
Laptop & PC Connection
Thunderbolt 4 upstream (video + data, DisplayPort 1.4 Alt Mode, power delivery up to 90 W), USB-C upstream (data only, 10 Gbps), DisplayPort 1.4 and HDMI inputs. Thunderbolt 4 and DP cables are included.
Hub & Network
Thunderbolt 4 downstream (15 W) for daisy chaining, 3 x USB-A 10 Gbps, quick-access USB-C (15 W) and USB-A (BC1.2), 2.5GbE RJ45, audio line-out, DisplayPort out. KVM: Yes; PbP/PiP: Yes.
Software
Dell Display Manager compatible (Easy Arrange and other key features).
Mounting
VESA 100 x 100 mm (behind attached VESA cover).
Package Contents & Dell UltraSharp 24 & 27 Monitors Ordering Information
In the Box
Monitor, Stand Riser, Stand Base, Quick setup guide, Safety, Environmental and Regulatory Information, Factory calibration report, 1 x Power cable, 1 x DisplayPort 1.4 cable - 1.8 m, 1 x USB Type-A to USB Type-C Gen 2 cable - 1 m, 1 x Thunderbolt™ 4 cable - 1 m.
Dell UltraSharp 24 & 27 Monitors
| Model | Key feature |
| U2424H | 24" FHD IPS 120 Hz, USB hub |
| U2424HE | 24" FHD 120 Hz, USB-C 90 W, RJ45, KVM |
| U2724D | 27" QHD IPS Black 120 Hz, USB hub |
| U2724DE (this listing) | 27" QHD IPS Black 120 Hz, Thunderbolt 4 90 W, RJ45, KVM |
Datasheet & Downloads
| Datasheet (PDF) | U2724DE datasheet on delltechnologies.com |
| Manuals & drivers | U2724DE manuals and documents on Dell Support |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting U2724DE.
Frequently Asked Questions — Dell U2724DE
Can the U2724DE charge my laptop?
Yes, the Thunderbolt 4 upstream port delivers up to 90 W.
Can I daisy-chain a second monitor?
Yes, through the Thunderbolt 4 downstream port or DisplayPort out.
Does it have Ethernet?
Yes, a 2.5GbE RJ45 port, with 1.5 W networked standby.
What is the difference from the U2724D?
The U2724DE adds Thunderbolt 4 with 90 W charging, Thunderbolt daisy chaining, RJ45 Ethernet, KVM and an extra USB-A port.
What warranty do I get?
3-Year Advanced Exchange Service and Premium Panel Exchange (Dell), supplied locally by SourceIT with a GST invoice.
