Dell UltraSharp 32 U3226Q 32" 4K QD-OLED Monitor
PRODUCT DESCRIPTION
Dell UltraSharp 32 4K QD-OLED Monitor U3226Q (210-BVHP) - 3 Years Local Warranty
4K QD-OLED, True Black
31.5-inch 4K QD-OLED panel at 120 Hz with 0.03 ms GTG response, 1,500,000:1 contrast, VESA DisplayHDR True Black 500 and Dolby Vision.
Built-in colour calibration
Integrated colorimeter with 99% DCI-P3, 94% Adobe RGB and 100% sRGB coverage, managed through Dell Color Management.
Thunderbolt 4 connectivity
Thunderbolt 4 with up to 140 W power delivery and daisy chaining, dual HDMI 2.1, DisplayPort 1.4, KVM and 2.5GbE RJ45.
Equipping a team or studio? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
Dell U3226Q Datasheet — Technical Specifications
General
| Product Name | Dell UltraSharp 32 4K QD-OLED Monitor - U3226Q |
| Model | U3226Q |
| Dell SKU | 210-BVHP |
| Local Warranty (Singapore) | 3-Year Advanced Exchange Service and Premium Panel Exchange, including coverage for OLED burn-in (Dell), supplied by SourceIT with a GST invoice |
Display
| Screen Size Class | 32" |
| Viewable Screen Size | 31.5" |
| Screen Mode | 4K UHD |
| Panel Technology | Quantum Dot OLED |
| Maximum Resolution | 3840 x 2160 at 120 Hz |
| Standard Refresh Rate | 120 Hz |
| Response Time | 0.03 ms GTG |
| Aspect Ratio | 16:9 |
| Pixel Pitch | 0.18140 mm x 0.18140 mm |
| Pixel Per Inch (PPI) | 140 |
| Viewing Angle | 178° horizontal / 178° vertical |
| Colour Supported | 1.07 Billion Colours |
| Native Contrast Ratio | 1,500,000:1 |
| Brightness | 300cd/m², 1000cd/m² |
| Colour Gamut | 99% DCI-P3 (CIE 1976), 94% Adobe RGB (CIE 1931), 100% sRGB (CIE 1931), 100% BT.709 (CIE 1931), 99% Display P3 (CIE 1976), 80% BT.2020 (CIE 1976) |
| HDR | VESA DisplayHDR True Black 500; Dolby Vision |
| Surface Treatment | Anti-glare Low Reflectance |
| Glass Hardness | 3H |
| Built-in Colorimeter | Yes |
Ports & Connectivity
| Thunderbolt 4 upstream | 1 x Thunderbolt 4 40Gbps upstream port (DisplayPort 1.4 Alt Mode, Power Delivery up to 140 W EPR) |
| Thunderbolt 4 downstream | 1 x Thunderbolt 4 40Gbps downstream port for daisy chaining (Power Delivery up to 15 W) |
| HDMI | 2 x HDMI ports (HDCP 1.4 & HDCP 2.2) (Supports up to 3840 x 2160, 120 Hz, HDR, VRR, DSC as specified in HDMI 2.1 (FRL)) |
| DisplayPort | 1 x DisplayPort 1.4 (HDCP 1.4 & HDCP 2.2) port |
| USB-C upstream | 1 x USB-C 10Gbps upstream port |
| USB-C downstream | 2 x USB-C 10Gbps downstream ports, Power Delivery up to 27 W |
| USB-A | 2 x USB Type-A 10Gbps downstream ports; 1 x USB Type-A 10Gbps downstream port with Battery Charging 1.2 |
| Ethernet | 1 x RJ45 Ethernet port, 2.5GbE |
| Features | KVM, Picture by Picture, Picture in Picture |
Ergonomics / Stand
| Stand Adjustments | Swivel, Height, Pivot, Tilt |
| Maximum Adjustable Height | 150 mm |
| Tilt Angle | -5° to 21° |
| Swivel Angle | -30° to 30° |
| Pivot Angle | +/-90° |
| VESA Mount | 100 x 100 |
| Security | Security lock / cable lock slot |
Power
| Input Voltage Range/Current | 100 VAC to 240 VAC/50 Hz or 60 Hz ± 3 Hz/5.3 A |
| Operating Power Consumption | 33.70 W |
| Standby Power Consumption | 0.4 W |
| Off-Mode Power Consumption | 0.3 W |
| Maximum Power Consumption | 460 W |
Dimensions & Weight
| Dimensions without Stand (H x W x D) | 436 mm x 718.28 mm x 65.48 mm |
| Height with Stand | 473.77 mm (compressed) to 623.77 mm (extended) |
| Width with Stand | 718.28 mm |
| Depth with Stand | 217.16 mm |
| Stand (H x W x D) | 488.30 mm x 287.34 mm x 217.16 mm |
| Bezel Width | Top 9.30 mm, Bottom 37.77 mm, Left/Right 12.30 mm |
| Weight (panel only, approx.) | 6.43 kg |
| Colour | Magnetite |
Environmental Conditions
| Operating Temperature | 0°C to 45°C |
| Non-operating Temperature | -20°C to 60°C |
| Operating Humidity | 20% to 90% (Non-condensing) |
| Non-operating Humidity | 10% to 90% (Non-condensing) |
| Maximum Operating Altitude | 5 km |
| Maximum Non-operating Altitude | 12.19 km |
Eye Comfort
| Eye Comfort Rating | TÜV 4 Star |
| Blue Light | Reduces harmful blue light emissions to ≤35% |
| Flicker Free | Yes |
| Anti-glare | Anti-Glare Low-Reflectance (AGLR) screen |
Compliance / Certifications
| Energy Efficiency | ENERGY STAR 8.0; Energy-related Products Directive Lot 5 (ErP Lot 5); ERP Lot 5 (Tier2) |
| Environmental Compliance | China Restriction of Hazardous Substances (China RoHS); Restriction of Hazardous Substances (RoHS) |
| Materials | BFR/PVC reduce monitor (Circuit boards are made from BFR/PVC-free laminates); Arsenic-Free glass and Mercury-Free for the panel only |
| Safety | Meets NFPA 99 leakage current requirements |
| Country of Origin | China/Vietnam |
Software
| Operating System Supported | Windows, macOS, Linux |
| Management Software | Dell Display and Peripheral Manager (DDPM); Dell Device Management Console (DDMC); Dell Color Management 4.0 (DCM 4.0) |
Compatibility & Software Support
Laptop & PC Connection
1 x Thunderbolt 4 40Gbps upstream port (DisplayPort 1.4 Alt Mode, Power Delivery up to 140 W EPR); 1 x Thunderbolt 4 40Gbps downstream port for daisy chaining (Power Delivery up to 15 W); 2 x HDMI ports (HDCP 1.4 & HDCP 2.2) (Supports up to 3840 x 2160, 120 Hz, HDR, VRR, DSC as specified in HDMI 2.1 (FRL)); 1 x DisplayPort 1.4 (HDCP 1.4 & HDCP 2.2) port; 1 x USB-C 10Gbps upstream port; 2 x USB-C 10Gbps downstream ports, Power Delivery up to 27 W; 2 x USB Type-A 10Gbps downstream ports; 1 x USB Type-A 10Gbps downstream port with Battery Charging 1.2; 1 x RJ45 Ethernet port, 2.5GbE; Features: KVM, Picture by Picture, Picture in Picture.
Software
Operating System Supported: Windows, macOS, Linux; Management Software: Dell Display and Peripheral Manager (DDPM); Dell Device Management Console (DDMC); Dell Color Management 4.0 (DCM 4.0).
Mounting
VESA Mount: 100 x 100.
Package Contents & Dell UltraSharp 27 to 49-inch Hub & Creator Monitors Ordering Information
In the Box
Monitor, Stand, Monitor hood, HDMI 2.1 cable (1.80 m), DisplayPort 1.4 cable (1.80 m), Thunderbolt 4 40 Gbps 240 W active cable (2.00 m), USB Type-C to Type-A 10Gbps cable (1.00 m), Power cable, Microfiber cloth, QR card, Safety, Environmental, and Regulatory Information.
Dell UltraSharp 27 to 49-inch Hub & Creator Monitors
| Model | Key feature |
| U2725QE | 27" 4K IPS Black 120 Hz, HDR 600, Thunderbolt 4 140 W, 2.5GbE RJ45 |
| U3224KB | 32" 6K IPS Black, HDR 600, 4K webcam + 2x14W speakers, Thunderbolt 4 140 W, RJ45 |
| U3225QE | 32" 4K IPS Black 120 Hz, Thunderbolt 4 140 W, RJ45 2.5GbE |
| U3226Q (this listing) | 32" 4K QD-OLED 120 Hz, built-in colorimeter, Thunderbolt 4 140 W, RJ45 |
| U3425WE | 34" WQHD 1900R IPS Black 120 Hz, Thunderbolt 4 90 W, RJ45, KVM |
| U3824DW | 38" WQHD+ 2300R IPS Black 60 Hz, USB-C 90 W, RJ45, KVM |
| U4025QW | 40" 5K2K (5120x2160) IPS Black 120 Hz curved, Thunderbolt 4 140 W, RJ45 |
| U4924DW | 49" DQHD (5120x1440) IPS Black 60 Hz curved, USB-C 90 W, RJ45 |
Datasheet & Downloads
| Datasheet (PDF) | U3226Q datasheet on delltechnologies.com |
| Product page | U3226Q on dell.com Singapore |
| Manuals & drivers | U3226Q manuals and documents on Dell Support |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting U3226Q.
Frequently Asked Questions — Dell U3226Q
Does the U3226Q calibrate itself?
Yes. It has a built-in colorimeter and supports Dell Color Management 4.0.
Can it power my laptop over one cable?
Yes. The Thunderbolt 4 upstream port provides power delivery up to 140 W (EPR).
What HDR formats are supported?
VESA DisplayHDR True Black 500 and Dolby Vision.
How many computers can I connect?
It has 2 HDMI 2.1, 1 DisplayPort 1.4, Thunderbolt 4 and USB-C upstream inputs, with built-in KVM, Picture-in-Picture and Picture-by-Picture.
What warranty does it come with in Singapore, and is burn-in covered?
Dell Singapore lists 3-Year Advanced Exchange Service and Premium Panel Exchange, including coverage for OLED burn in.
