Dell UltraSharp 27 U2722D 27" QHD IPS Monitor
PRODUCT DESCRIPTION
Dell UltraSharp 27 Monitor U2722D (210-AZFK) - Local Dell Warranty
QHD detail at 27 inches
2560 x 1440 resolution at 108.78 PPI on a 27-inch IPS panel with 350 cd/m² brightness and 1.07 billion colours.
Wide, calibrated colour
Covers 100% sRGB, 100% Rec. 709 and 95% DCI-P3, factory calibrated to an average Delta E < 2.
10 Gbps USB hub
A USB-C upstream link feeds three 10 Gbps USB-A ports (one with Battery Charging 1.2) and a 15 W USB-C downstream port.
Equipping a team or office? Email sales@sourceit.com.sg for volume pricing, delivery lead time and availability of current Dell successors.
Dell U2722D Datasheet — Technical Specifications
Display
| Diagonal size | 27" (68.47 cm) |
| Panel type | IPS (In-Plane Switching), anti-glare 3H hard coating |
| Backlight | LED |
| Aspect ratio | 16:9 |
| Native resolution | 2560 x 1440 (QHD) at 60 Hz |
| Pixel pitch | 0.2331 mm x 0.2331 mm |
| Pixels per inch | 108.78 PPI |
| Brightness | 350 cd/m² (typical) |
| Contrast ratio | 1000:1 (typical) |
| Colour support | 1.07 billion colours |
| Colour gamut | 100% sRGB, 100% Rec. 709, 95% DCI-P3 |
| Factory calibration | Delta E < 2 (average), sRGB and Rec. 709 |
| Response time | 8 ms (Normal); 5 ms (Fast), grey to grey |
| Viewing angle | 178° horizontal / 178° vertical |
| Picture by Picture | Supports PBP Select mode |
Connectivity
| HDMI | 1 x HDMI |
| DisplayPort in | 1 x DisplayPort 1.4 |
| DisplayPort out | 1 x DisplayPort out (MST capable, daisy chain) |
| USB-C upstream | 1 x USB-C 3.2 Gen 2 upstream (data) |
| USB-A downstream | 2 x USB 3.2 Gen 2 (10 Gbps) Type-A |
| USB-A downstream (charging) | 1 x USB 3.2 Gen 2 (10 Gbps) Type-A with Battery Charging 1.2 |
| USB-C downstream | 1 x USB-C 3.2 Gen 2, 15 W (5 V/3 A) |
| Audio | 1 x audio line-out (mini-jack) |
| Speakers | None |
Ergonomics
| Height adjustment | 150 mm |
| Tilt | -5° to +21° |
| Swivel | -45° to +45° |
| Pivot | -90° to +90° |
| VESA mount | 100 x 100 mm |
| Security | Security lock slot (cable lock sold separately); stand lock |
| Stand | Removable stand |
Eye Comfort
| Flicker-free | Yes |
| Blue light reduction | Dell ComfortView Plus; low blue light panel, TÜV Rheinland compliant |
Power
| Input voltage | 100-240 VAC, 50/60 Hz ± 3 Hz, 1.6 A (maximum) |
| On mode | 20 W |
| Maximum | 74 W |
| Pon (ENERGY STAR) | 16.11 W |
| TEC (ENERGY STAR) | 51.39 kWh |
| Standby | 0.3 W |
| Off mode | 0.3 W |
Physical
| Dimensions with stand (W x D x H) | 611.34 x 185.00 x 385.13 mm (compressed) / 535.13 mm (extended) |
| Dimensions without stand (W x D x H) | 611.34 x 49.50 x 352.01 mm |
| Weight with stand and cables | 6.61 kg |
| Weight without stand | 4.38 kg |
| Shipping weight | 9.62 kg |
| Operating temperature | 0°C to 40°C |
| Operating humidity | 10% to 80% (non-condensing) |
Certifications
| Environmental | ENERGY STAR; TCO Certified |
| Materials | Mercury-free; arsenic-free glass |
Warranty
| Local Warranty (Singapore) | Local Dell warranty, supplied by SourceIT with a GST invoice. Dell lists this model with 3-Years Advanced Exchange Service and Premium Panel Guarantee in other markets; email sales@sourceit.com.sg to confirm the Singapore term |
Compatibility & Software Support
PC connection
Connect via DisplayPort 1.4 or HDMI for video; USB-C upstream (A-to-C cable included) is for the USB hub and does not charge a laptop.
Multi-monitor
DisplayPort out supports MST daisy chaining; Picture by Picture (PBP) Select mode shows two sources side by side.
Mounting
Removable stand with VESA 100 x 100 mm mounting and a security lock slot.
Package Contents & Dell UltraSharp Monitors Ordering Information
In the Box
Monitor, stand riser, stand base, power cable, DisplayPort cable (DP to DP, 1.8 m), USB-C cable (A to C, 1 m), Quick Setup Guide, Factory Calibration Report and safety/regulatory information.
Dell UltraSharp Monitors
| Model | Key feature |
| U2421E | 24.1" WUXGA 16:10, USB-C 90 W, RJ45 |
| U2422H | 24" FHD IPS, USB hub |
| U2422HE | 24" FHD IPS, USB-C 90 W, RJ45 |
| U2424H | 24" FHD 120 Hz, USB hub |
| U2424HE | 24" FHD 120 Hz, USB-C 90 W, RJ45 |
| U2520D | 25" QHD IPS, USB-C 90 W |
| U2722D (this listing) | 27" QHD IPS, USB hub |
| U2722DE | 27" QHD IPS, USB-C 90 W, RJ45 |
| U2723QE | 27" 4K IPS Black, USB-C 90 W, RJ45 |
| U2724D | 27" QHD IPS Black 120 Hz |
| U2724DE | 27" QHD 120 Hz, Thunderbolt 4 90 W |
| U2725QE | 27" 4K 120 Hz, Thunderbolt 4 |
| U3023E | 30" WQXGA 16:10, USB-C 90 W, RJ45 |
| U3223QE | 31.5" 4K IPS Black, USB-C 90 W, RJ45 |
| U3224KB | 32" 6K, Thunderbolt 4, webcam |
| U3225QE | 32" 4K 120 Hz, Thunderbolt 4 |
| U3226Q | 32" 4K QD-OLED |
Datasheet & Downloads
| User guide | Dell U2722D Monitor User's Guide (PDF) |
| Manuals & drivers | U2722D on Dell Support (Singapore) |
| Warranty | Dell Monitor Service & Warranty brochure (PDF) |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting U2722D.
Frequently Asked Questions — Dell U2722D
What warranty does the Dell U2722D come with?
Local Dell warranty, supplied by SourceIT with a GST invoice. Dell lists this model with 3-Years Advanced Exchange Service and Premium Panel Guarantee in other markets; email sales@sourceit.com.sg to confirm the Singapore term.
Can the U2722D charge my laptop over USB-C?
No. For USB-C video and laptop charging, see the U2722DE. The U2722D USB-C downstream port supplies up to 15 W to accessories.
What is the resolution and refresh rate?
2560 x 1440 QHD at 60 Hz.
Does it have speakers?
No. It provides an audio line-out port.
Is it height adjustable?
Yes, 150 mm height, tilt -5° to +21°, swivel ±45° and pivot ±90°.
