ViewSonic TD3207 32" Full HD Open Frame Touch Monitor, 24/7
PRODUCT DESCRIPTION
ViewSonic TD3207 32" Open Frame Touch Monitor with 24/7 Operation - 3 Years Local Warranty
Durable IP65 Touchscreen
Water- and dust-resistant IP65 front with IK08 impact resistance and a 3 mm 7H glass.
10-Point PCAP Touch
Highly responsive projected capacitive touch for kiosks and self-service.
24/7 Operation
Built for continuous commercial use, with a 50,000-hour backlight.
Bright and Flexible
450 nits for bright venues and VESA mounting in multiple screen orientations.
Need touch monitors for a retail counter, kiosk, classroom or office rollout? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
ViewSonic TD3207 Datasheet — Technical Specifications
General
| Product Name | ViewSonic TD3207 32" Open Frame Touch Monitor with 24/7 Operation |
| Model | TD3207 |
| Local Warranty (Singapore) | 3 years on-site limited warranty on parts and labour |
Display
| Screen Size | 32" (31.5" viewable) |
| Panel Type | VA |
| Resolution | 1920 x 1080 (Full HD) |
| Refresh Rate | 60 Hz |
| Response Time | 5 ms (GTG) |
| Brightness | 450 cd/m² (typ) |
| Contrast Ratio | 4,000:1 static (typ); 50M:1 dynamic |
| Colours | 16.7M, 8-bit true |
| Colour Gamut | NTSC 72%; sRGB 104% (typ) |
| Viewing Angles | 178° H / 178° V |
| Pixel Size | 0.364 x 0.364 mm |
| Low Blue Light | Software solution |
| Backlight Life | 50,000 hours (min) |
| Operation | 24/7 |
Touch & Protection
| Touch Technology | Projected capacitive, 10-point multi-touch |
| Surface | Glossy, 7H hard coating |
| Cover Glass Thickness | 3 mm |
| Protection | IP65 front (water & dust); IK08 impact |
| Touch Interface | USB 2.0 Type-B |
Connectivity
| HDMI | 1 x HDMI 1.4 |
| DisplayPort | 1 (v1.2) |
| RS232 | 1 (control in) |
| Audio | 1 x 3.5 mm out |
| Speakers | 2 x 2 W |
Power
| Voltage | AC 100–240 V |
| Consumption | 43 W typical; 45.5 W max; 0.5 W standby |
| Eco Mode | 27 W (conserve) / 35 W (optimised) |
| Power Supply | External power adaptor |
Operating Conditions
| Temperature | 0–50 °C |
| Humidity (non-condensing) | 20%–90% |
Physical
| Dimensions (W x H x D) | 747 x 451 x 64 mm |
| Net Weight | 12.8 kg |
| Packaging (W x H x D) | 863 x 577 x 163 mm |
| Gross Weight | 15.5 kg |
| VESA | 400 x 200 mm; 200 x 100 mm |
| Stand | None (open frame, for mounting) |
Compatibility & Software Support
Devices
Windows 10/11 certified and macOS tested at 1920 x 1080. Connect video by HDMI or DisplayPort plus the USB-B cable for touch.
Integration
Open-frame chassis for kiosk, vending and self-service enclosures; RS232 for remote control and multi-orientation mounting via VESA.
Package Contents & ViewSonic TD Series Ordering Information
In the Box
TD3207 monitor, power cable (IEC C13), AC/DC adapter, HDMI cable (v1.4), USB A/B cable (v2.0), quick start guide.
ViewSonic TD Series Touch Monitors
| Model | Key feature |
| TD1617A-2K | 16" WQXGA IPS 165 Hz portable, 10-point touch, 2 x USB-C |
| TD1630-3 | 16" (15.6") WXGA, 10-point PCAP, HDMI + VGA |
| TD1655 | 16" (15.6") FHD IPS portable, 10-point touch, USB-C, pen |
| TD2223-2 | 22" (21.5") FHD VA, 10-point IR touch, 7H glass |
| TD2230 | 22" (21.5") FHD IPS, 10-point PCAP, frameless, DP/HDMI/VGA |
| TD2423 | 24" (23.6") FHD VA 75 Hz, 10-point IR touch, 7H glass |
| TD2455 | 24" (23.8") FHD IPS in-cell PCAP, USB-C 60 W, stylus |
| TD2465 | 24" (23.8") FHD VA 100 Hz, frameless PCAP, wet-hand/glove touch |
| TD2760 | 27" FHD VA, 10-point PCAP, fold-flat stand, RS232 |
| TD3207 (this listing) | 32" (31.5") FHD open frame PCAP, IP65 front, 24/7, 450 nits |
Datasheet & Downloads
| ViewSonic datasheet | TD3207 Datasheet |
| User guide | TD3207 User Guide (PDF, English) |
| Quick start guide | TD3207 Quick Start Guide (PDF) |
| ViewSonic product page | TD3207 on viewsonic.com |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting TD3207.
Frequently Asked Questions — ViewSonic TD3207
Does it come with a stand?
No. It is an open-frame monitor designed to be built into kiosks or VESA-mounted (400 x 200 or 200 x 100 mm).
Can it run 24/7?
Yes, ViewSonic rates the TD3207 for 24/7 operation.
Is it water resistant?
The front panel is IP65 water- and dust-resistant, with IK08 impact resistance.
What warranty do I get?
3 years on-site limited warranty on parts and labour in Singapore. Supplied by SourceIT with a GST invoice.
