ViewSonic TD2760 27" Full HD 10-Point Touch Screen Monitor
PRODUCT DESCRIPTION
ViewSonic TD2760 27" 10-point Touch Screen Monitor - 3 Years Local Warranty
10-Point Multi-Touch
Projected capacitive touch recognises up to 10 points of simultaneous contact.
SuperClear 178° Viewing
Ultra-wide viewing angles with consistent image quality and 50M:1 dynamic contrast.
Advanced Ergonomic Stand
Tilt, raise and lower the screen, or lay it completely flat for collaborative work.
Versatile Connectivity
DisplayPort, HDMI and VGA inputs with RS232 control and a USB 3.2 hub.
Need touch monitors for a retail counter, kiosk, classroom or office rollout? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
ViewSonic TD2760 Datasheet — Technical Specifications
General
| Product Name | ViewSonic TD2760 27" 10-point Touch Screen Monitor |
| Model | TD2760 |
| Local Warranty (Singapore) | 3 years on-site limited warranty on parts and labour |
Display
| Screen Size | 27" |
| Panel Type | VA |
| Resolution | 1920 x 1080 (Full HD) |
| Refresh Rate | 60 Hz |
| Response Time | 6 ms (GTG) |
| Brightness | 250 cd/m² (typ) |
| Contrast Ratio | 3,000:1 static (typ); 50M:1 dynamic |
| Colours | 16.7M, 8-bit (6-bit + Hi-FRC) |
| Colour Gamut | NTSC 72%; sRGB 102% (typ) |
| Viewing Angles | 178° H / 178° V |
| Pixel Size | 0.311 x 0.311 mm |
| Flicker-Free / Low Blue Light | Yes / software solution |
| Backlight Life | 30,000 hours (min) |
Touch
| Touch Technology | Projected capacitive, 10-point multi-touch |
| Surface | Anti-glare, ≥6H hard coating |
| Cover Glass Thickness | 1.88 mm |
| Touch Interface | USB 3.2 Type-B |
Connectivity
| HDMI | 1 x HDMI 1.4 |
| DisplayPort | 1 (v1.2) |
| VGA | 1 |
| RS232 | 1 (control in) |
| USB | 2 x USB 3.2 Type-A downstream; 1 x USB 3.2 Type-B upstream |
| Audio | 1 x 3.5 mm in; 1 x 3.5 mm out |
| Speakers | 2 x 2 W |
| Kensington Lock Slot | 1 |
Power
| Voltage | AC 100–240 V |
| Consumption | 26 W typical; 28 W max; 0.3 W standby |
| Eco Mode | 19 W (conserve) / 22 W (optimised) |
| Power Supply | Internal |
Operating Conditions
| Temperature | 0–40 °C |
| Humidity (non-condensing) | 20%–90% |
Physical & Ergonomics
| Dimensions with Stand (W x H x D) | 660 x 443 x 239 mm |
| Dimensions without Stand | 660 x 410 x 58 mm |
| Net Weight | 7.9 kg (5.5 kg without stand) |
| Packaging (W x H x D) | 753 x 525 x 204 mm |
| Gross Weight | 10.2 kg |
| Tilt | -4° / 90° |
| VESA | 100 x 100 mm |
Compatibility & Software Support
Devices
Windows 7/8/8.1/10/11 certified and macOS tested; ViewSonic also lists Linux, Chrome and Android compatibility. Connect video by HDMI, DisplayPort or VGA plus the USB-B cable for touch.
Control & Software
RS232 and HDMI CEC for remote control; on-screen menu with colour, audio and flicker-free / low blue light settings.
Package Contents & ViewSonic TD Series Ordering Information
In the Box
TD2760 monitor, power cable (IEC C13), VGA cable, HDMI cable (v1.4), audio cable, USB A/B cable (v3.2), quick start guide.
ViewSonic TD Series Touch Monitors
| Model | Key feature |
| TD1617A-2K | 16" WQXGA IPS 165 Hz portable, 10-point touch, 2 x USB-C |
| TD1630-3 | 16" (15.6") WXGA, 10-point PCAP, HDMI + VGA |
| TD1655 | 16" (15.6") FHD IPS portable, 10-point touch, USB-C, pen |
| TD2223-2 | 22" (21.5") FHD VA, 10-point IR touch, 7H glass |
| TD2230 | 22" (21.5") FHD IPS, 10-point PCAP, frameless, DP/HDMI/VGA |
| TD2423 | 24" (23.6") FHD VA 75 Hz, 10-point IR touch, 7H glass |
| TD2455 | 24" (23.8") FHD IPS in-cell PCAP, USB-C 60 W, stylus |
| TD2465 | 24" (23.8") FHD VA 100 Hz, frameless PCAP, wet-hand/glove touch |
| TD2760 (this listing) | 27" FHD VA, 10-point PCAP, fold-flat stand, RS232 |
| TD3207 | 32" (31.5") FHD open frame PCAP, IP65 front, 24/7, 450 nits |
Datasheet & Downloads
| ViewSonic datasheet | TD2760 Datasheet |
| User guide | TD2760 User Guide (PDF, English) |
| Quick start guide | TD2760 Quick Start Guide (PDF) |
| ViewSonic product page | TD2760 on viewsonic.com |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting TD2760.
Frequently Asked Questions — ViewSonic TD2760
Can the screen lie flat?
Yes. The ergonomic stand tilts from -4° to 90° and can lay the screen flat for tabletop collaboration.
How is touch connected?
Connect the supplied USB A/B cable to your PC in addition to HDMI, DisplayPort or VGA video.
Can it be controlled remotely?
Yes, via RS232 or HDMI CEC.
What warranty do I get?
3 years on-site limited warranty on parts and labour in Singapore. Supplied by SourceIT with a GST invoice.
