D-Link DGS-712 1000BASE-T Copper SFP Transceiver
Prices in SGD, excluding 9% GST.
PRODUCT DESCRIPTION
D-Link DGS-712 1000BASE-T Copper SFP Transceiver (DGS-712) - 5 Years Local Warranty
Turn an SFP Slot into a Gigabit Copper Port
The D-Link DGS-712 is a 1000BASE-T copper SFP transceiver. It plugs into a standard SFP slot and provides an RJ45 port for Gigabit Ethernet over Category 5, 5e or 6 twisted-pair cable up to 100 m.
Standards-Based and Hot Pluggable
The DGS-712 follows the SFP Multi-Source Agreement and IEEE 802.3ab, and is hot pluggable.
Need help choosing? Email sales@sourceit.com.sg with your switch model, fibre type and link distance and we will match the right module for you.
D-Link DGS-712 Datasheet — Technical Specifications
General
| Product Name | D-Link DGS-712 1000BASE-T Copper SFP Transceiver |
| Part Number | DGS-712 |
| Series | DEM-300 Series Gigabit SFP Transceivers |
| Local Warranty (Singapore) | 5 years, supplied by SourceIT with a GST invoice |
Interface
| Standard | IEEE 802.3ab 1000BASE-T |
| Connector | RJ45 |
| Media | Category 5 / 5e / 6 twisted-pair copper |
| Wavelength | Not applicable (copper) |
| Maximum Distance | 100 m |
Module
| Form Factor | SFP, Multi-Source Agreement (MSA) compliant |
| Power Supply | 3.3 V |
| Hot Pluggable | Yes |
Compatibility & Software Support
Host Ports
Plugs into a standard Gigabit SFP slot on a switch, router or media converter. D-Link's datasheet does not publish a host compatibility list — send us your switch model and we will confirm before you order.
Speed
D-Link's datasheet lists 1000BASE-T only; 10/100 Mbps operation is not stated.
Package Contents & DEM-300 Gigabit SFP Ordering Information
D-Link Gigabit SFP Transceivers (DEM-300 Series)
| Model | Standard | Wavelength | Distance | Part No. |
| DEM-310GT | 1000BASE-LX, single-mode | 1310 nm | 10 km | DEM-310GT |
| DEM-311GT | 1000BASE-SX, multi-mode | 850 nm | 550 m | DEM-311GT |
| DEM-312GT2 | 1000BASE-SX, multi-mode | 1310 nm | 2 km | DEM-312GT2 |
| DEM-314GT | 1000BASE-LHX, single-mode | 1550 nm | 50 km | DEM-314GT |
| DEM-315GT | 1000BASE-ZX, single-mode | 1550 nm | 80 km | DEM-315GT |
| DEM-330T | 1000BASE-BX-D, single-mode | Tx 1550 / Rx 1310 nm | 10 km | DEM-330T |
| DEM-330R | 1000BASE-BX-U, single-mode | Tx 1310 / Rx 1550 nm | 10 km | DEM-330R |
| DEM-331T | 1000BASE-BX-D, single-mode | Tx 1550 / Rx 1310 nm | 40 km | DEM-331T |
| DEM-331R | 1000BASE-BX-U, single-mode | Tx 1310 / Rx 1550 nm | 40 km | DEM-331R |
| DGS-712 (this listing) | 1000BASE-T, copper RJ45 | — | 100 m | DGS-712 |
Specifications per D-Link's DEM-300 Series datasheet (v1.02 WW, updated 31 Jan 2024).
Package contents are not listed in D-Link's datasheet — ask us if you need confirmation of what is in the box.
Datasheet & Downloads
| D-Link datasheet | DEM-300 Series Datasheet v1.02 WW (PDF) |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting DGS-712.
Frequently Asked Questions — D-Link DGS-712
Does the DGS-712 support 10/100 Mbps?
D-Link's datasheet lists 1000BASE-T only; it does not state 10/100 Mbps support. Ask us if you need to connect a Fast Ethernet device.
What cable do I need?
Category 5, 5e or 6 twisted-pair copper, up to 100 m.
Is it a fibre module?
No — it is a copper RJ45 SFP. For fibre, choose a DEM-300 series optic from the table above.
What warranty do I get?
5 years local warranty in Singapore, supplied by SourceIT with a GST invoice.
