APC Smart-UPS 750VA LCD RM 2U 230V with SmartConnect

APC Smart-UPS 750VA LCD RM 2U 230V with SmartConnect (SMT750RMI2UC) - 2 Years Local Warranty

Compact Rack-Mounted Protection

The APC SMT750RMI2UC is a 2U rackmount line-interactive UPS delivering 750 VA / 500 W of pure sine-wave backup power. Designed for branch servers, network closets, POS systems, and VoIP gear, it provides clean, reliable power during outages. With automatic voltage regulation (AVR), it handles brownouts and spikes efficiently, reducing battery wear and extending the service life of the unit.

Cloud-Ready with SmartConnect and SmartSlot

Integrated SmartConnect allows remote UPS health monitoring, firmware updates, and lifecycle alerts via APC's secure cloud portal, with no network card required. The SmartSlot accepts an optional management card for enhanced connectivity or environmental monitoring. This makes the unit a strong fit for distributed sites that need centralized visibility without added hardware.

User-Friendly Rack Features

The SMT750RMI2UC comes with front-mount rack ears, a multifunction LCD showing load, runtime, and battery status, and local USB/serial ports for PowerChute integration. A hot-swappable battery cartridge (APCRBC123) ensures uptime during replacements and maintenance, letting technicians service the battery without taking connected equipment offline.

Reliable Runtime and Efficiency

The unit provides approximately 5-6 minutes at full load (500 W) and around 16 minutes at half load, with recharge to 90% capacity in about three hours. Green mode boosts efficiency and lowers operating costs by bypassing unused circuitry during normal operation, helping reduce both energy use and heat in the rack.

Technical Specifications

• Model: APC Smart-UPS 750VA LCD RM 2U 230V with SmartConnect (SMT750RMI2UC)
• Capacity: 750 VA / 500 W
• Topology: Line-interactive, pure sine wave, AVR
• Input Voltage: 230 V nominal; output +/-5%, 50/60 Hz +/-3 Hz
• Outlets: 4 x IEC C13 + 2 x IEC jumper
• Connections: USB, RS-232, SmartConnect Ethernet, SmartSlot
• Battery: Sealed lead-acid, hot-swappable (APCRBC123)
• Runtime: ~5 min at full load, ~16 min at half load
• Recharge Time: ~3 hours to 90%
• Dimensions: 432 x 409 x 86 mm
• Weight: ~16.6 kg
• Noise: ~42 dBA
• Certifications: CE, UL 1778, IEC 62040-1/2, RoHS, REACH
• Warranty: 3 years electronics; 2 years battery

Ideal Use Case: Branch offices, network closets, and POS/VoIP deployments needing compact 2U rack-mounted power protection with cloud-based SmartConnect monitoring.

GTIN/UPC: 731304340324
