Epson CO-FH02 Full HD 3LCD Smart Projector
PRODUCT DESCRIPTION
Epson CO-FH02 Full HD 3LCD Smart Projector (V11HA85052) - 3 Years Singapore Local Warranty
Android TV Dongle and Chromecast Built-in - No Source Device to Carry
The CO-FH02 ships with an Android TV dongle and Chromecast built-in, so the projector is the whole system. Staff walk into a meeting room or a breakout space and cast a deck or a training video straight from a phone or laptop, with no dongle to hunt for and no HDMI cable to thread across the table. In a home it means streaming apps run on the projector itself. For a small office, a showroom or a hospitality space, that removes the single most common cause of a delayed start - somebody looking for the right adapter.
3,000 Lumens of Colour and White Light Output from Epson 3LCD
White light output and colour light output are both 3,000 lumens in Normal mode, dropping to 2,000 lumens in Eco. Equal white and colour figures are characteristic of Epson's 3LCD system: each frame carries all three colour channels at once rather than cycling them, so colour saturation holds up at full brightness rather than fading into grey. That matters in the rooms these actually get used in - a living room with the blinds part-open, a meeting room with the downlights on, a retail corner with spill from the shopfront.
Full HD 1080p Up to a 391-Inch Picture
The CO-FH02 projects native Full HD from three 0.62-inch C2 Fine LCD panels. Image size runs from 34 inches to 391 inches, with a 60-inch picture at 1.58 metres of throw and a throw ratio of 1.19 to 1.61 - close enough to a standard-throw geometry that it works on a coffee table, a shelf or a ceiling bracket without a specialist calculation. There is no optical zoom; size is set by placement, with a 1.0 to 1.35 digital zoom for fine adjustment and manual focus.
Automatic Vertical Keystone, 5W Enclosed Speaker, GST Invoice
Automatic vertical keystone correction of plus or minus 30 degrees straightens the image as soon as the projector is tilted, and manual vertical and horizontal keystone of plus or minus 30 degrees covers off-axis placement. The 5W speaker sits in a proper enclosure, which gives it more body than the bare driver in most projectors this size - enough for a training video or a presentation without a separate soundbar. SourceIT supplies the CO-FH02 in Singapore with a GST invoice and 3 years local warranty, with volume quotations available.
Epson CO-FH02 Datasheet — Technical Specifications
General
| Product | Epson CO-FH02 Full HD 3LCD Smart Projector |
| Part Number (SKU) | V11HA85052 |
| Projection Technology | RGB liquid crystal shutter projection system (3LCD) |
| Native Resolution | Full HD |
| Smart Platform | Android TV dongle supplied; Chromecast built-in |
| Local Warranty (Singapore) | 3 Years Singapore Local Warranty — supplied by SourceIT with GST invoice |
Projection & Optics
| LCD Panel Size | 0.62-inch (C2 Fine) |
| White Light Output (Normal / Eco) | 3,000 lm / 2,000 lm |
| Colour Light Output | 3,000 lm |
| Lens Type | No optical zoom / manual focus |
| F-Number | 1.44 |
| Focal Length | 16.4 mm |
| Zoom Ratio | 1.0 – 1.35 (digital zoom) |
| Throw Ratio | 1.19 – 1.61 |
| Screen Size (Projected Distance) | 34" to 391" [0.89 to 10.40 m] (zoom: wide); 26" to 290" [0.91 to 10.41 m] (zoom: tele); 60" screen at 1.58 m |
| Keystone Correction | Vertical ± 30 degrees, horizontal ± 30 degrees |
| Auto Keystone | Vertical ± 30 degrees |
Light Source
| Light Source Type | Lamp (fixed), 188 W UHE |
| Lamp Life (Normal / Eco) | 6,000 / 12,000 hours |
Connectivity
| HDMI | 1 (HDCP 1.4) |
| USB Type A | 1 (for 2A power supply, firmware update and copy OSD settings) |
| USB Type B | 1 (for firmware update and copy OSD settings) |
| Wireless | Smart Media Player |
Audio & Features
| Internal Speaker | 5 W monaural (with enclosure) |
| Fan Noise (Normal / Eco) | 37 dB / 29 dB |
| Direct Power On/Off | Yes |
Physical & Environmental
| Dimensions Excluding Feet (D x W x H) | 211 x 320 x 82 mm |
| Weight | Approx. 2.6 kg |
Power
| Power Consumption (Normal / Eco) | 270 W / 214 W |
Specifications are taken from Epson Singapore's published product data for this model. Where Epson Singapore does not publish a figure for this exact model it has been left out rather than estimated.
Compatibility & Installation
Placing and mounting
The CO-FH02 measures 211 x 320 x 82 mm excluding feet and weighs approximately 2.6 kg — a little wider and heavier than the CO-FH01 because of the speaker enclosure. It sits on a table, a shelf or a credenza, and is light enough for a standard projector ceiling bracket. A 60-inch image needs about 1.58 metres of throw, with the full range running 34 inches to 391 inches at a throw ratio of 1.19 to 1.61. Set the size by placement; there is no optical zoom, only a 1.0 to 1.35 digital zoom and manual focus.
Squaring the image up
Automatic vertical keystone correction of plus or minus 30 degrees handles tilt on its own, so a unit dropped onto a coffee table straightens itself. Manual vertical and horizontal keystone of plus or minus 30 degrees is there for placements that are off to one side as well as tilted.
Streaming and casting
The CO-FH02 is supplied with an Android TV dongle and has Chromecast built-in, so apps run on the projector and phones or laptops can cast to it directly. The USB Type A port supplies 2A of power, which is what feeds the dongle, and also handles firmware updates and copying OSD settings between units — worth using if you are commissioning several rooms to a common configuration.
Wired sources
There is one HDMI input with HDCP 1.4, which covers a laptop, a games console, a set-top box or a document camera alongside the built-in streaming. Use it whenever you need a guaranteed wired path rather than relying on the room Wi-Fi.
Sibling model
If streaming is not needed — for example on a fixed install where a room PC or a video bar already supplies the picture — the CO-FH01 is the same Full HD 3LCD engine and the same 3,000 lumens without the Android TV dongle.
Package Contents & Epson CO Range
In the box
- Epson CO-FH02 projector
- Android TV dongle (Epson Singapore states the CO-FH02 comes with an Android TV dongle)
Package contents follow Epson Singapore's product data for this model; items not listed by Epson are not claimed here.
Epson CO range
| Model | Key difference |
| CO-FH01 | Same Full HD 3LCD engine and 3,000 lm, HDMI source only, optional wireless LAN |
| CO-FH02 (this listing) | Full HD, 3,000 lm, supplied with Android TV dongle and Chromecast built-in |
Related Epson portable and home projectors at SourceIT
| EF-11 | Compact laser projector |
| EF-12 | Compact laser projector with Android TV |
| EH-TW750 | Full HD home projector |
Datasheet & Downloads
The specifications above are taken from the Epson Singapore product page for the CO-FH02. SourceIT can email the current data sheet revision and the Singapore warranty terms on request with a quotation.
Frequently Asked Questions — Epson CO-FH02
What makes the CO-FH02 a "smart" projector?
It is supplied with an Android TV dongle and has Chromecast built-in, so streaming apps run on the projector and phones or laptops can cast to it without a cable. The dongle draws its power from the projector's own USB Type A port, which supplies 2A, so there is no second power brick to find.
How does it differ from the CO-FH01?
The picture engine is the same — Full HD, 0.62-inch C2 Fine 3LCD panels, 3,000 lumens white and colour, the same lens and the same 34-inch to 391-inch range. The CO-FH02 adds the Android TV dongle and Chromecast, automatic vertical keystone, a 5W speaker in an enclosure rather than bare, and is slightly larger and heavier at 320 mm wide and about 2.6 kg. The CO-FH01 is the choice when a room PC or video bar already supplies the picture.
Is it bright enough for a room with the lights on?
It produces 3,000 lumens of white light output and 3,000 lumens of colour light output in Normal mode, which suits rooms with controlled ambient light — blinds drawn, downlights on, away from direct window glare. Eco mode runs at 2,000 lumens and is quieter at 29 dB rather than 37 dB.
How far back does it sit for a given screen size?
Throw ratio is 1.19 to 1.61. Epson Singapore quotes a 60-inch image at 1.58 metres, and the full range runs 34 inches to 391 inches between 0.89 m and 10.40 m at the wide setting. There is no optical zoom, so set the distance for the screen size you want and use the digital zoom only to trim.
Do I still need the HDMI input if it streams?
Often, yes. The single HDMI input with HDCP 1.4 is what you use for a laptop, a console, a document camera or a set-top box, and it is the reliable path when room Wi-Fi is congested. The streaming dongle and the HDMI source coexist.
Does it correct the image automatically if it is tilted?
Yes, for tilt. Automatic vertical keystone correction covers plus or minus 30 degrees. If the projector is also off to one side, manual horizontal keystone of plus or minus 30 degrees is available as well.
How long does the lamp last?
Epson Singapore rates the fixed 188 W UHE lamp at 6,000 hours in Normal mode and 12,000 hours in Eco mode. Epson Singapore does not publish a separate lamp warranty term for this model, so the 3-year Singapore local warranty is the figure to work to; ask SourceIT to confirm lamp coverage in writing on the quotation.
Does it come with a Singapore warranty and a GST invoice?
Yes. Every Epson CO-FH02 sold by SourceIT is supplied with 3 years Singapore local warranty and a GST invoice, quoted in Singapore dollars. Volume pricing for meeting room, training room or hospitality rollouts is available on request.
