NETGEAR GSM4210PX M4250-8G2XF-PoE+ 8-Port Gigabit PoE+ AV Line Managed Switch with 2x 10G SFP+, 220W
Email sales@sourceit.com.sg or use Request for Quotation below and our team will confirm the latest price, availability and lead time.
PRODUCT DESCRIPTION
NETGEAR M4250-8G2XF-PoE+ 8-Port Gigabit PoE+ AV Line Managed Switch with 2 x SFP+ (GSM4210PX-100UKS) - Limited Lifetime Local Warranty
Compact AV-over-IP Switch with 10G Uplinks
The NETGEAR GSM4210PX (M4250-8G2XF-PoE+) is a 10-port desktop member of the M4250 AV Line with two 1G/10G SFP+ ports for fibre uplinks. It ships pre-configured for AV over IP, with an AV user interface and profiles for Dante, Q-SYS, AES67, AVB, NDI, NVX and SVSI.
8 PoE+ Ports with a 220W Budget
Eight 10/100/1000BASE-T PoE+ ports (802.3at, up to 30W per port) share a 220W PoE budget, enough to run all eight ports at full PoE+ power for speakers, encoders, decoders, PTZ cameras and displays.
Selectable Fan Modes, Mount It Anywhere
Choose Fan Off (0 dBA), Quiet (19.3 dBA) or Cool (35.3 dBA) mode to suit the room. At 210 x 140 x 40 mm and 0.967 kg it sits on a desk or fixes under a table or behind a display with the supplied mounting brackets.
Need help choosing? Email sales@sourceit.com.sg with your endpoint count, PoE and uplink needs and we will size it for you.
NETGEAR GSM4210PX Datasheet — Technical Specifications
General
| Product Name | NETGEAR M4250-8G2XF-PoE+ 8-Port Gigabit PoE+ AV Line Managed Switch with 2 x SFP+ |
| Part Number | GSM4210PX-100UKS |
| Series | NETGEAR M4250 Series (AV Line) Managed Switches |
| Local Warranty (Singapore) | Limited lifetime, supplied by SourceIT with a GST invoice |
Interfaces
| PoE+ Ports | 8 x 10/100/1000BASE-T RJ-45 PoE+ |
| Fibre Ports | 2 x 1000/10GBASE-X SFP+ |
| Console | USB Type-C console |
Performance
| Switching Fabric | 56 Gbps |
| Throughput | 41.67 Mpps (64-byte packets) |
| Latency | 2.140 µs 1G copper; 1.169 µs 1G fibre; 0.838 µs 10G fibre (64-byte packets) |
| MAC Address Table | 16K |
| ARP/NDP Entries | 4K |
| Packet Buffer | 16 Mb |
| Jumbo Frames | Up to 12K |
| CPU / Memory | Integrated ARM A9 1.25 GHz (32-bit); 2 GB RAM |
PoE
| PoE Standard | IEEE 802.3at PoE+ (up to 30W per port) |
| PoE Budget | 220W shared across 8 PoE+ ports |
Power & Environmental
| Power Supply | 1 x external power adapter (254W), 54V 4.7A input |
| Power Consumption | 257.9W with PoE; 18.14W without PoE; 9.51W standby |
| Cooling / Acoustics | Selectable modes at 25 °C: Fan Off 0 dBA (37.4 °C case); Quiet 19.3 dBA (33.6 °C case); Cool 35.3 dBA (28.8 °C case) |
| Operating Temperature | 0 to 40 °C |
| Operating Humidity | 90% max, non-condensing |
Physical
| Dimensions (W x D x H) | 210 x 140 x 40 mm |
| Weight | 0.967 kg (2.13 lb) |
| Mounting | Desktop, under-table or behind a display (mounting brackets supplied) |
Compatibility & Software Support
AV User Interface
Includes NETGEAR's web-based AV user interface designed for AV installers, alongside the full out-of-band IT web GUI (HTTPS). The switch ships pre-configured for out-of-the-box AV-over-IP operation.
Pre-Configured AV Profiles
Audio: Dante, Q-SYS, AES67 and AVB. Video: NVX, SVSI, Q-SYS, NDI and Dante (as listed in the M4250 datasheet).
Management
IT web GUI (HTTPS), AV web GUI, CLI via console, Telnet and SSH, SNMP/MIBs and RSPAN.
Multicast & AV Features
NETGEAR IGMP Plus for multicast AV traffic, auto-trunk and auto-LAG, IEEE 802.1BA Audio Video Bridging (AVB — licence required, per NETGEAR's product page) and IEEE 1588 PTPv2 Transparent Clock.
Package Contents & M4250 Ordering Information
In the Box
GSM4210PX switch, external power adapter, AC power cord (varies by region), USB Type-C console cable, mounting brackets with screws, rubber footpads, installation guide. SFP+ modules and cables are sold separately.
NETGEAR M4250 Models
| Model | Ports | Part No. |
| GSM4210PD M4250-9G1F-PoE+ | 8 x 1G PoE+, 1 x 1G, 1 x SFP | GSM4210PD-100UKS |
| GSM4210PX M4250-8G2XF-PoE+ (this listing) | 8 x 1G PoE+, 2 x SFP+ | GSM4210PX-100UKS |
| GSM4212P M4250-10G2F-PoE+ | 8 x 1G PoE+, 2 x 1G, 2 x SFP | GSM4212P-100EUS |
| GSM4212PX M4250-10G2XF-PoE+ | 8 x 1G PoE+, 2 x 1G, 2 x SFP+ | GSM4212PX-100EUS |
| GSM4212UX M4250-10G2XF-PoE++ | 8 x 1G PoE++, 2 x 1G, 2 x SFP+ | GSM4212UX-100EUS |
| GSM4230P M4250-26G4F-PoE+ | 24 x 1G PoE+, 2 x 1G, 4 x SFP | GSM4230P-100EUS |
| GSM4230PX M4250-26G4XF-PoE+ | 24 x 1G PoE+, 2 x 1G, 4 x SFP+ | GSM4230PX-100EUS |
| GSM4230UP M4250-26G4F-PoE++ | 24 x 1G PoE++, 2 x 1G, 4 x SFP | GSM4230UP-100EUS |
| GSM4248P M4250-40G8F-PoE+ | 40 x 1G PoE+, 8 x SFP | GSM4248P-100EUS |
| GSM4248PX M4250-40G8XF-PoE+ | 40 x 1G PoE+, 8 x SFP+ | GSM4248PX-100EUS |
| GSM4248UX M4250-40G8XF-PoE++ | 40 x 1G PoE++, 8 x SFP+ | GSM4248UX-100EUS |
| MSM4214X M4250-12M2XF | 12 x 2.5G, 2 x SFP+ | MSM4214X-100EUS |
| XSM4216F M4250-16XF | 16 x SFP+ | XSM4216F-100EUS |
Datasheet & Downloads
| NETGEAR datasheet | M4250 Series Datasheet (PDF) |
| Installation guide | M4250 Installation Guide (PDF) |
| AV user manual | M4250 AV User Manual (PDF) |
| NETGEAR product page | GSM4210PX on netgear.com |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting GSM4210PX-100UKS.
Frequently Asked Questions — NETGEAR GSM4210PX
How much PoE power does the GSM4210PX provide?
A 220W PoE budget shared across 8 PoE+ ports, with up to 30W per port (IEEE 802.3at).
How is the GSM4210PX different from the GSM4210PD?
The GSM4210PX has two 1G/10G SFP+ uplinks and a 220W PoE budget with selectable fan modes; the GSM4210PD is fanless with 110W, one 1G SFP and one extra 1G copper port.
Is it quiet enough for a meeting room?
NETGEAR rates it at 0 dBA in Fan Off mode and 19.3 dBA in Quiet mode at 25 °C, with Cool mode (35.3 dBA) for warmer installs.
Which AV protocols are pre-configured?
NETGEAR lists profiles for Dante, Q-SYS, AES67 and AVB audio, and NVX, SVSI, Q-SYS, NDI and Dante video.
Does it support AVB?
Yes, IEEE 802.1BA AVB is supported; NETGEAR's product page notes a licence is required.
What warranty do I get?
Limited lifetime local warranty in Singapore, supplied by SourceIT with a GST invoice.
