Huawei IdeaHub S2 65" 4K Video Conferencing Interactive Display, IHS2-65SA
Email sales@sourceit.com.sg or use Request for Quotation below and our team will confirm the latest price, availability and lead time.
PRODUCT DESCRIPTION
Huawei IdeaHub S2 65" 4K Video Conferencing Interactive Display (IHS2-65SA) - Local Warranty
The HUAWEI IdeaHub S2 65" (IHS2-65SA) is an all-in-one 4K video conferencing display for regular meeting rooms and executive offices — built-in camera with privacy cap and speaker tracking, 12 m mic pickup with acoustic baffle, 40 W speakers and Bring Your Own Meeting.
Key Features
- 4K D-LED infrared touch screen with zero-gap bonding and 16 ms writing latency.
- Built-in camera (80° horizontal FoV) with privacy lens cap, auto-framing and intelligent speaker tracking.
- 6-mic array with 180° / 12 m pickup, acoustic baffle and 4 speakers (40 W) for medium meeting rooms.
- Huawei Cloud Meeting and WeLink native with 1080p30 video + 1080p30 / 4K8 content sharing; BYOM supported.
- 8-core CPU, 8 GB RAM, 64 GB storage; HarmonyOS, with Windows via optional OPS.
- Wi-Fi 6 dual-band, NFC; front Type-C and 2 x USB 3.0, side HDMI in/out, HD-AI, RJ45, COM and Touch port.
Huawei IHS2-65SA Datasheet — Technical Specifications
General
| Product Name | Huawei IdeaHub S2 65" 4K Video Conferencing Interactive Display |
| Brand | Huawei |
| Huawei Part Number | 55150650 |
| Model | IHS2-65SA |
Display & Writing
| Screen Size | 65-inch infrared touch screen |
| Resolution | 4K (3840 x 2160 pixels) |
| Backlight | D-LED |
| Lamination | Zero-gap bonding |
| Writing Latency | 16 ms |
| Touch Sensing Distance | ≤ 1.5 mm |
System
| CPU | 8-core |
| RAM | 8 GB |
| Storage | 64 GB |
| Operating System | HarmonyOS, Windows (OPS required) |
| OPS PC Slot | Optional |
Camera
| Horizontal Field of View | 80° |
| TV Distortion | <2% |
| Privacy Lens Cap | Yes |
| Auto-Framing | Yes |
| Intelligent Speaker Tracking | Yes |
Audio
| Microphones | 6 |
| Pickup Angle | 180° |
| Pickup Distance | 12 m |
| Microphone Frequency Range | 100 Hz to 20 kHz |
| Speaker Units | 4 |
| Speaker Total Power | 40 W |
| Speaker Frequency Range | 100 Hz to 20 kHz |
| Acoustic Baffle | Yes |
Meetings
| Native Meeting Apps | Huawei Cloud Meeting and WeLink |
| Dual Streams (Video + Content) | 1080p30fps+1080p30fps/4K8fps |
| BYOM (Bring Your Own Meeting) | Yes |
Connectivity
| Wi-Fi | Wi-Fi 6 |
| Wi-Fi Bands | 2.4 GHz + 5 GHz |
| NFC | Yes |
| Ports | Front-panel ports: 1 x Type-C/2 x USB 3.0 Side-panel ports: 1 x 3.5mm LINE IN/1 x 3.5mm LINE OUT; 1 x HDMI IN/1 x HDMI OUT; 1 x USB 3.0/1 x HD-AI; 1 x RJ45 (10/100/1000 Mbit/s LAN); 1 x COM port/1 x Touch port |
Physical
| Dimensions (H x W x D) | 947.5 mm x 1484.5 mm x 91.6 mm |
| Package Dimensions (H x W x D) | 1050 mm x 1650 mm x 220 mm |
| Net / Gross Weight | 35.5 kg/43.0 kg |
Optional Accessories & Ordering Information
The OPS PC, IdeaShare Key (Type-A), HUAWEI Touch panel, rolling stand and wall mount bracket are optional and sold separately.
IdeaHub S2 Sizes
| Model | Huawei part / model |
| Huawei IdeaHub S2 65" 4K Video Conferencing Interactive Display | 55150650 / IHS2-65SA |
| Huawei IdeaHub S2 75" 4K Video Conferencing Interactive Display | 55150651 / IHS2-75SA |
| Huawei IdeaHub S2 86" 4K Video Conferencing Interactive Display | 55150652 / IHS2-86SA |
IdeaHub Accessories
| Accessory | Huawei part / model |
| Huawei IdeaHub OPS W021 Z PC Module | 06190054 / OPS W021 Z |
| Huawei IdeaHub OPS W022 Z PC Module | 06190053 / OPS W022 Z |
| Huawei IdeaHub Rolling Stand II, White | 21155908 / WB1M0IDEAHUB07 |
| Huawei IdeaHub Rolling Stand II, Gray | 21155908-001 / WB1M0IDEAHUB08 |
| Huawei IdeaHub Wall Mount Bracket | 21156005 / WB1M0BRACKET01 |
| Huawei IdeaShare Key (Type-A) 4K Wireless Screen Sharing Dongle | 02170469 / EP02T-H |
| Huawei IdeaShare Key (Type-C) Wireless Screen Sharing Dongle | 02170477 / HWA-01 |
Datasheet & Downloads
| Datasheet | HUAWEI IdeaHub S2 Datasheet (25H2) |
| Product page | HUAWEI IdeaHub S2 |
| Huawei eKit product page | HUAWEI eKit product page |
Frequently Asked Questions — IdeaHub S2 65
How is the S2 different from the B3?
The S2 adds a privacy lens cap, an acoustic baffle, 12 m sound pickup (vs 10 m), 40 W speakers (vs 30 W) and higher content-sharing performance, plus a Touch port for the HUAWEI Touch panel.
Does it support Teams or Zoom?
Huawei Cloud Meeting and WeLink run natively. Other apps can be used in BYOM mode from a connected laptop, or on Windows with the optional OPS PC.
How do I share content wirelessly?
Use Wi-Fi 6 projection with the IdeaShare app, NFC, or the optional IdeaShare Key (Type-A) dongle.
