Eaton 9E3000i 3000VA Tower UPS with internal batteries 230V

Eaton 9E3000i 3000VA Tower UPS with internal batteries 230V (9103-83968) - 2 Years Local Warranty

Eaton 9E 3000VA Tower UPS – Premium Power Protection for Larger Systems

The Eaton 9E 3000VA Tower UPS is engineered to provide reliable power protection for a variety of applications, including medium to large IT environments, networking equipment, and critical load protection. With a 3000VA capacity, this UPS ensures continuous power delivery during power interruptions, providing essential uptime for your business operations. This tower UPS is the ideal solution for protecting servers, routers, switches, and other vital equipment against power outages, voltage fluctuations, and surges.

Efficient Battery Management for Enhanced Longevity

The Eaton 9E 3000VA Tower UPS includes an advanced battery management system, which improves battery life while ensuring optimal performance. The system prevents overcharging and undercharging, ensuring that the internal batteries are maintained in peak condition. When power disruptions occur, the internal batteries offer immediate backup, allowing your systems to stay operational without interruption. With a focus on energy efficiency, the UPS ensures that your equipment is powered without unnecessary power loss or consumption.

Comprehensive Surge Protection and Energy Efficiency

In addition to its primary function of backup power, the Eaton 9E 3000VA UPS offers built-in surge protection. It shields your valuable equipment from electrical spikes, preventing potential damage from power surges. The UPS is designed for energy efficiency, reducing operational costs while delivering clean, stable power to connected devices. This makes it the perfect choice for offices, data centers, and industrial applications, where both performance and cost-effectiveness are essential.

Real-Time Monitoring and Remote Management

The Eaton 9E 3000VA Tower UPS features an intuitive LCD display, providing real-time monitoring of UPS performance and status, including input/output voltage, battery health, load capacity, and more. Users can access detailed information to ensure their systems are running optimally and to troubleshoot any issues. Additionally, the UPS is compatible with Eaton’s Intelligent Power Software, allowing for remote monitoring and management, helping users maintain system uptime and avoid disruptions.

Technical Specifications

General
Model: 9E3000i
Part Number: 9103-83968
Product Name: Eaton 9E3000i 3000VA Tower UPS with Internal Batteries 230V
Manufacturer: Eaton
Product Type: Online Double-Conversion UPS
UPS Topology: Online Double Conversion (VFI)
Form Factor: Tower
Power Capacity: 3000VA / 2400W
Output Power Factor: 0.8
Input Voltage: 220V / 230V / 240V AC
Output Voltage: 220V / 230V / 240V AC
Battery Configuration: Internal Batteries Included
Application: Servers, Storage Systems, Network Equipment, Telecommunications, Industrial Control Systems, SMB Server Rooms
Warranty: 2 Years Warranty

Power Specifications
Rated Capacity: 3000VA / 2400W
UPS Topology: Online Double Conversion
Output Power Factor: 0.8
Output Waveform: Pure Sine Wave
Input Voltage Range: 176V – 300V AC (100V – 300V with Derating)
Nominal Input Voltage: 220V / 230V / 240V
Output Voltage Accuracy: ±2%
Input Frequency Range: 40Hz – 70Hz
Output Frequency: 50Hz / 60Hz Auto-Sensing
Input Power Factor: >0.99
Efficiency (Online Mode): Up to 91%
Efficiency (ECO Mode): Up to 97.5%
Internal Automatic Bypass: Supported
Auto Restart: Supported
Cold Start Capability: Supported

Battery Specifications
Battery Type: Sealed Lead Acid (VRLA)
Battery Quantity: 6 Batteries
Battery Rating: 12V / 9Ah
Battery Management: Automatic Battery Testing
Deep Discharge Protection: Supported
Battery Replacement: User Replaceable
Extended Battery Module (EBM) Support: Supported
Maximum External Battery Packs: Up to 4
Battery Charging: Automatic Intelligent Charging System

Runtime Specifications
Runtime at 50% Load: Approximately 13.5 Minutes
Runtime at Full Load: Approximately 5 Minutes
Extended Runtime Capability: Supported via External Battery Modules
Runtime Monitoring: Supported via LCD Interface

Input Specifications
Input Connector: IEC C20
Input Phase: Single Phase
Input Voltage Monitoring: Supported
Input Frequency Monitoring: Supported
Input Protection: Integrated
Nominal Frequency: 50Hz / 60Hz

Output Specifications
Total Output Outlets: 7
IEC C13 Outlets: 6
IEC C19 Outlets: 1
Output Voltage: 220V / 230V / 240V Configurable
Output Distortion: <2% at 100% Linear Load
Overload Capacity:
• 105%–130% Load: 60 Seconds
• 130%–150% Load: 10 Seconds
• >150% Load: ≥300ms
Pure Sine Wave Output: Supported

Display & User Interface
Display Type: LCD Display
Real-Time Power Monitoring: Supported
Input Voltage Monitoring: Supported
Output Voltage Monitoring: Supported
Battery Status Monitoring: Supported
Load Monitoring: Supported
Runtime Estimation: Supported
Alarm Notifications: Supported
Status Monitoring: Supported

Management & Communication
USB Port (HID Compliant): 1
RS232 Serial Port: 1
Communication Slot: 1 Expansion Slot
Optional Network Card: Supported
Optional ModBus Card: Supported
Optional Relay Card: Supported
Remote Monitoring: Supported
Remote Shutdown: Supported
Eaton Intelligent Power Manager (IPM): Supported
Eaton Intelligent Power Protector (IPP): Supported

Virtualization & Software Support
VMware Compatible
Microsoft Hyper-V Compatible
Citrix Xen Compatible
Red Hat Virtualization Compatible
Virtual Machine Shutdown Automation Supported
Centralized UPS Monitoring Supported

Protection Features
Online Double Conversion Protection
Voltage Regulation
Frequency Regulation
Brownout Protection
Overvoltage Protection
Undervoltage Protection
Surge Protection
Short Circuit Protection
Overload Protection
Battery Deep Discharge Protection
Internal Automatic Bypass
Continuous Power Conditioning

Environmental Specifications
Operating Temperature: 0°C to 40°C
Storage Temperature: -25°C to 55°C
Operating Humidity: 0% – 95% Non-Condensing
Maximum Operating Altitude: 3000m
Noise Level: <37 dB at Typical Load

Design & Construction
Color: Black
Form Factor: Tower
Construction Type: Free Standing Model
Cooling System: Intelligent Forced-Air Cooling
Industrial Deployment Ready: Supported
Professional LCD Front Panel Design

Physical Specifications
Dimensions (H × W × D): 399 × 190 × 330 mm
Weight: 24.2 kg
Installation Type: Tower Floor Standing

Package Contents
Eaton 9E3000i UPS
USB Communication Cable
RS232 Serial Cable
Quick Start Guide
Safety Instructions
Power Management Software Support

Features
3000VA / 2400W Capacity
Online Double Conversion Technology
Pure Sine Wave Output
LCD Monitoring Display
Up to 97.5% ECO Mode Efficiency
Automatic Internal Bypass
USB & RS232 Communication
Optional SNMP Network Management
Extended Battery Runtime Support
Virtualization Ready
Generator Compatible
Low Noise Operation (<37 dB)

Performance & Features
The Eaton 9E3000i delivers enterprise-grade online double-conversion protection for servers, networking equipment, storage systems, and business-critical applications. Its wide input voltage range minimizes battery usage during voltage fluctuations, helping extend battery lifespan. The UPS provides pure sine wave output, integrated LCD monitoring, and optional network management capabilities, making it ideal for SMB server rooms, branch offices, telecommunications systems, and industrial deployments. Support for up to four external battery modules allows extended runtime for critical applications.

Key Features
3000VA / 2400W Capacity
Online Double Conversion UPS
Pure Sine Wave Output
LCD Display Interface
6 × IEC C13 Outputs
1 × IEC C19 Output
Automatic Battery Testing
Up to 97.5% Efficiency in ECO Mode
Optional SNMP Management
Supports Up to 4 External Battery Modules
VMware & Hyper-V Compatible
Generator Compatible
Low Noise Design

Typical Use Cases
Enterprise Servers
Network Switches
Firewalls & Security Appliances
NAS & SAN Storage Systems
Telecommunications Equipment
Industrial Automation Systems
Branch Offices
Server Rooms
Healthcare Equipment
Retail Infrastructure
Edge Computing Deployments
Business-Critical Applications

Certifications & Compliance
CE Certified
TÜV Certified
IEC/EN 62040-1
IEC/EN 62040-2
EAC Certified
CB Report Certified
RoHS Compliant

UPC / GTIN
UPC: 786689166588
