Eaton 5S700i 700VA Tower Models 230V

Eaton 5S700i 700VA Tower Models 230V (9207-53083) - 2 Years Local Warranty

Eaton 5S 700VA Tower UPS - Compact and Reliable Power Backup

The Eaton 5S 700VA Tower UPS offers a robust and reliable solution for protecting your electronic devices from power interruptions and surges. With a power rating of 700VA (or 420W), this UPS is ideal for small offices, home offices, and individuals who need to safeguard computers, network equipment, and other sensitive devices. The Eaton 5S 700VA ensures uninterrupted power and allows enough time for users to save work and perform a safe shutdown during power failures.

Energy Efficient and Eco-Friendly Design

Eaton’s 5S 700VA Tower UPS is designed with energy efficiency in mind. It helps lower energy consumption, reducing both operational costs and environmental impact. The UPS features Automatic Voltage Regulation (AVR), which corrects minor voltage fluctuations without draining the battery, ensuring the longevity of your system and preventing unnecessary energy wastage. By incorporating Energy Star certification, the Eaton 5S 700VA helps you reduce your carbon footprint while ensuring optimal performance.

Space-Saving, User-Friendly Tower UPS

The compact design of the Eaton 5S 700VA Tower UPS makes it perfect for small spaces. Whether you’re working in a home office or a small business environment, this UPS fits easily into tight spaces without compromising on performance. Equipped with an intuitive LCD display, the Eaton 5S provides users with essential information about power status, battery level, and load capacity. This user-friendly design makes it easy to monitor and maintain the UPS, ensuring seamless operation.

Protect Your Devices from Power Surges and Outages

With a 700VA rating, the Eaton 5S Tower UPS is an excellent solution for low to medium power devices, such as personal computers, routers, and networking hubs. It provides reliable protection against power surges, spikes, and blackouts. The UPS ensures that your important devices are shielded from potential damage caused by unexpected power disruptions, giving you peace of mind and confidence that your devices will continue to run smoothly during outages.

Technical Specifications

General
Model: 5S700i
Part Number: 9207-53083
Product Name: Eaton 5S700i 700VA Tower UPS 230V
Manufacturer: Eaton
Product Type: Line-Interactive UPS
UPS Topology: Line-Interactive with Automatic Voltage Regulation (AVR)
Form Factor: Tower / Desktop
Power Capacity: 700VA / 420W
Output Power Factor: 0.6
Input Voltage: 220V / 230V / 240V AC
Output Voltage: 230V AC
Battery Technology: Sealed Lead Acid (VRLA)
Application: Desktop PCs, Workstations, Routers, Switches, NAS Storage, POS Systems, CCTV Systems, Small Office IT Equipment
Warranty: 2 Years Warranty

Power Specifications
Rated Capacity: 700VA / 420W
UPS Topology: Line-Interactive
Output Waveform: Modified Sine Wave / Stepped Approximation Sine Wave
Input Voltage Range: 175V – 275V AC
Output Voltage: 230V Default (220V / 230V / 240V Selectable)
Output Voltage Range: 184V – 276V AC
Input Frequency Range: 46Hz – 70Hz
Output Frequency: 50Hz / 60Hz Auto-Sensing
Efficiency: Up to 97%
Automatic Voltage Regulation (AVR): Supported
Cold Start Capability: Supported
Auto Shutdown Function: Supported
Surge Protection: Supported

Battery Specifications
Battery Type: Sealed Lead Acid (VRLA)
Battery Quantity: 1 Battery
Battery Rating: 12V / 7Ah
Battery Management: Automatic Battery Testing
Battery Replacement: User Replaceable
Deep Discharge Protection: Supported
Cold Start Capability: Supported
Extended Battery Capability: No

Runtime Specifications
Runtime at Full Load: Approximately 2 Minutes
Runtime at Half Load: Approximately 8.5 Minutes
Runtime Monitoring: Supported
Load-Based Runtime Estimation: Supported
Battery Backup for Safe Shutdown: Supported

Input Specifications
Input Connector: IEC C14
Input Phase: Single Phase
Input Voltage Monitoring: Supported
Input Frequency Monitoring: Supported
Input Protection: Integrated
Nominal Input Voltage: 230V Default (220V / 230V / 240V Selectable)

Output Specifications
Total Output Outlets: 6
Battery Backup & Surge Protected Outlets: 3 × IEC C13
Surge Protection Only Outlets: 3 × IEC C13
Output Phase: Single Phase
Output Voltage: 230V AC
Critical Equipment Protection: Supported

Display & User Interface
Display Type: LED Status Indicators
UPS Status Monitoring: Supported
Battery Status Monitoring: Supported
Power Monitoring: Supported
Alarm Notifications: Supported
User-Friendly Monitoring Interface: Supported

Management & Communication
USB Port (HID Compliant): 1
Communication Interface: USB
Network Management Card: Not Supported
SNMP Monitoring: Not Supported
Software Included: Eaton UPS Companion Software
Automatic Safe Shutdown: Supported
Windows Compatible: Supported
macOS Compatible: Supported
Linux Compatible: Supported
Energy Usage Metering: Supported

Data Line Protection
RJ11 Telephone/Fax Protection: Supported
RJ45 Ethernet Protection: Supported
Internet Line Protection: Supported
Network Equipment Protection: Supported

Protection Features
Automatic Voltage Regulation (AVR)
Surge Protection
Brownout Protection
Overvoltage Protection
Undervoltage Protection
Short Circuit Protection
Overload Protection
Battery Deep Discharge Protection
Auto Restart After Power Recovery
Power Line Conditioning

Environmental Specifications
Operating Temperature: 0°C to 35°C
Operating Humidity: 0% – 85% Non-Condensing
Maximum Operating Altitude: 2000m
Noise Level: Less Than 25 dB at 1 Meter

Design & Construction
Color: Black
Form Factor: Tower / Desktop
Construction Type: Free Standing Model
Space-Saving Design: Supported
Monitor Stand Installation: Supported
Office-Friendly Design: Supported

Physical Specifications
Dimensions (H × W × D): 250 × 87 × 260 mm
Weight: 5.98 kg
Installation Type: Tower / Desktop Placement

Package Contents
Eaton 5S700i UPS
2 × IEC-to-IEC Power Cables
USB Communication Cable
User Manual
Safety Instructions

Features
700VA / 420W Capacity
Line-Interactive UPS Technology
Automatic Voltage Regulation (AVR)
USB HID Communication
RJ11 & RJ45 Data Line Protection
User Replaceable Battery
Automatic Battery Testing
Cold Start Capability
6 IEC C13 Outlets
Compact Tower Design
97% Efficiency
Safe System Shutdown Support

Performance & Features
The Eaton 5S700i is designed to protect desktop computers, networking equipment, NAS devices, and small office infrastructure from power interruptions and voltage fluctuations. Its AVR technology corrects voltage variations without switching to battery power, extending battery lifespan and improving efficiency. Built-in USB connectivity enables automated operating system shutdown, while integrated RJ11 and RJ45 surge protection safeguards communication and network lines from electrical disturbances.

Key Features
700VA / 420W Capacity
Automatic Voltage Regulation (AVR)
6 × IEC C13 Outlets
3 Battery Backup Outlets
3 Surge Protection Outlets
USB HID Connectivity
RJ11 & RJ45 Protection
Automatic Battery Testing
User Replaceable Battery
97% Efficiency
Cold Start Capability
Compact Tower Design

Typical Use Cases
Desktop Computers
Professional Workstations
NAS Storage Systems
Network Switches
Routers & Firewalls
Business Telephony Systems
Retail POS Systems
Home Offices
Security & Surveillance Systems
Internet Access Points
Small Business IT Infrastructure

Certifications & Compliance
IEC/EN 62040-1
IEC/EN 62040-2
CE Certified
EAC Certified
RoHS Compliant

UPC / GTIN
UPC: 743172436894
