Dell PowerEdge R570 Rack Server

Dell PowerEdge R570 Rack Server (Advance CTO, Please Enquire for Further Information) - Local Warranty

Enterprise Rack Server for Modern IT Infrastructure

Dell Technologies PowerEdge R570 Rack Server is a scalable enterprise server platform designed to support virtualization, cloud computing, databases, analytics, and business-critical workloads. Engineered for modern data center environments, the PowerEdge R570 delivers reliable performance, flexibility, and scalability for organizations managing growing infrastructure demands.

Optimized for Virtualization and Enterprise Applications

The Dell PowerEdge R570 supports workloads including virtualization clusters, ERP systems, software-defined infrastructure, collaboration platforms, databases, and analytics environments. Its enterprise architecture enables businesses to efficiently manage operational workloads while maintaining system performance and reliability.

Flexible Configure-To-Order Deployment Platform

As an Advance CTO (Configure-To-Order) solution, the Dell PowerEdge R570 Rack Server supports customizable configurations including processors, memory, storage, networking, and expansion options. Organizations can tailor infrastructure deployments according to workload requirements and future scalability plans.

Designed for Enterprise and Data Center Environments

The PowerEdge R570 is suitable for enterprises, educational institutions, government agencies, and service providers requiring dependable server infrastructure. Its rack-mounted design supports efficient deployment and centralized management while delivering enterprise-grade operational reliability.

Technical Specifications

General
Model: PowerEdge R570
Product Name: Dell PowerEdge R570 Rack Server
Manufacturer: Dell Technologies
Server Type: Enterprise Rack Server
Form Factor: 2U Rack Server
Deployment: Virtualization, cloud computing, enterprise applications, software-defined storage, AI-ready infrastructure
Configuration Type: Advanced CTO (Configure-To-Order)
Processor Platform: Intel® Xeon® 6 Processors
Architecture: Dual-Socket Enterprise Server Platform
Target Workloads: Virtualization, databases, cloud infrastructure, enterprise applications, analytics, scalable compute environments

Processor Specifications
Processor Support: Up to 2 x Intel Xeon® 6 Processors
Maximum CPU Cores: Up to 144 Cores per Processor (processor dependent)
Maximum Total Cores: Up to 288 Cores
Processor Architecture: Intel Xeon 6 Platform
Processor Socket: Dual Socket Platform
Performance Optimization: High performance and energy-efficient enterprise compute platform

Memory Specifications
Memory Technology: DDR5 ECC RDIMM
DIMM Slots: Up to 32 DIMM Slots
Maximum Memory Capacity: Up to 8TB (processor dependent)
Memory Speed: Up to 6400 MT/s
Memory Protection: ECC Supported

Storage Specifications
Storage Architecture: Flexible CTO Configuration

Supported Storage Types:
• NVMe SSD
• SAS SSD
• SATA SSD
• HDD

Drive Bay Options: Multiple 2.5-inch and EDSFF configurations available
Hot Swap Drives: Supported
RAID Support: Supported
Storage Controllers: Dell PERC RAID Controller options available

Expansion & PCIe
PCIe Generation: PCIe Gen5
Expansion Slots: Multiple PCIe Gen5 Slots
GPU Support: Selected GPU and accelerator support
OCP Support: OCP NIC 3.0 Supported
Networking Expansion: Supported

Networking
Network Interface: CTO Dependent

Supported Networking Options:
• 1GbE Ethernet
• 10GbE Ethernet
• 25GbE Ethernet
• 100GbE Networking Options
• OCP 3.0 Network Adapters

Remote Management: Dell iDRAC10
Out-of-Band Management: Supported

Power Specifications
Power Supply Type: Dual Hot Plug Redundant Power Supplies
Power Redundancy: Supported
Power Efficiency: 80 PLUS Platinum / Titanium Supported

Cooling & Thermal Design
Cooling Type: Enterprise High Efficiency Cooling
Redundant Fans: Supported
Optimized Airflow Design: Supported
Thermal Monitoring: Supported

Management & Security
Management Platform: Dell OpenManage with iDRAC10
Remote Monitoring: Supported
Firmware Updates: Supported
Server Health Monitoring: Supported
Secure Boot: Supported
TPM Security: Supported
Silicon Root of Trust: Supported
System Lockdown: Supported

Virtualization Support
Supported Hypervisors:
• VMware vSphere
• Microsoft Hyper-V
• Linux KVM
• Red Hat Virtualization

Cloud Ready: Supported
Container Platforms: Kubernetes Ready

Operating System Compatibility
Supported Operating Systems:
• Microsoft Windows Server
• Ubuntu Server
• Red Hat Enterprise Linux
• SUSE Linux Enterprise Server
• VMware ESXi

Design & Construction
Form Factor: 2U Rack Mount
Rack Compatibility: Standard Enterprise Rack
Deployment Environment: Enterprise Data Center / Cloud Infrastructure / Virtualization Environment
Construction: Enterprise Grade Rack Chassis

Performance & Features
Dual-socket enterprise compute platform
Intel Xeon 6 high-core-count architecture
DDR5 high-speed memory support
PCIe Gen5 expansion capability
Flexible NVMe storage configurations
Enterprise remote lifecycle management
Optimized for virtualization and cloud environments
Scalable enterprise infrastructure deployment

Package Contents
Dell PowerEdge R570 Rack Server Chassis
Power Supply Units (configuration dependent)
Rail Kit (optional)
Documentation
CTO Components according to final build

Key Features
2U enterprise rack server
Intel Xeon 6 processor platform
DDR5 ECC memory support
PCIe Gen5 architecture
Flexible storage deployment
Dell iDRAC10 remote management
Virtualization optimized platform
Advanced CTO configurable deployment

Typical Use Cases
Enterprise virtualization
Database hosting
Cloud infrastructure
Application hosting
Software-defined storage
Private cloud environments
Analytics workloads
Enterprise IT infrastructure

How to Configurate Server?

Step 1:
What is the Server Form Factor? Tower or Rackmount Server?
What is the number of CPU Core or Ram or HDD usable size require?
What is the number of CPU Processor? 1S or 2S or 4S?
What is the RAID Configuration? Any specific HDD or SSD? 7.2K or 10K?
What is the specific NIC is required? Base-T 1G or SFP+? Or Fibre Channel?
What is the number of year maintenance support required? Minimum 3 years

Step 2:
How many number of unit Server?
Any VM workload? Required any VMware license? Or Window OS Hyper-V?
How do you store data currently? Any NAS or SAN Storage?
How do you doing the backup? Required any backup proposal? IDPA 8TB?
Do you require burn-in test services?
Do you need hard disk retention services?
