Dell Dock WD19S 180W USB-C Docking Station
PRODUCT DESCRIPTION
Dell Dock - WD19S 180W (210-AZDB) - Local Dell Warranty
One USB-C Cable to the Desk
The Dell Dock WD19S connects a laptop over a single 1 m USB-C cable and fans out to two DisplayPort 1.4 ports, HDMI, a USB-C multi-function DisplayPort, three USB-A 3.2 Gen 1 ports, two USB-C 3.2 Gen 2 ports and Gigabit Ethernet.
Power for Dell Laptops
With the included 180 W adapter it delivers up to 130 W to Dell systems and up to 90 W to non-Dell systems over USB Power Delivery.
Built for Managed Fleets
PXE Boot, Wake-On-LAN, MAC address pass-through, port disablement, Wake-On-Dock and Dell Command Update firmware updates suit IT-managed offices.
Buying for an office roll-out? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
Dell WD19S Datasheet — Technical Specifications
General
| Product Name | Dell Dock - WD19S 180W |
| Model | WD19S |
| Dell SKU (Singapore) | 210-AZDB |
| Product Type | Docking Station |
| Warranty | 3-Year Limited Hardware Warranty with Advanced Exchange (Dell datasheet); supplied locally by SourceIT with a GST invoice |
Host Connection
| Docking Interface | USB-C |
| Cable Length | 1.0 m |
| Power Adapter | 180 W |
| Power Delivery | Up to 130 W (Dell systems); up to 90 W (non-Dell systems) |
Ports
| Video Interfaces | 2 x full-size DisplayPort 1.4, 1 x HDMI, 1 x multi-function DisplayPort USB-C |
| USB | 3 x USB-A 3.2 Gen 1, 2 x USB-C 3.2 Gen 2 |
| Networking | Gigabit Ethernet (RJ-45) |
| Security | 1 x Kensington lock slot, 1 x Noble Wedge lock slot |
| LEDs | Power adapter LED, power button LED, RJ-45 LEDs |
Display Support
| HBR2 PC | 2 x FHD @ 60Hz, 1 x QHD @ 60Hz, 1 x 4K @ 30Hz |
| HBR3 PC | 3 x FHD @ 60Hz, 2 x QHD @ 60Hz, 1 x 4K @ 60Hz |
| HBR3 PC with DSC | 3 x QHD @ 60Hz, 2 x 4K @ 60Hz |
| Max Resolution | 4K @ 60Hz |
Management
| IT Features | PXE Boot, Wake-On-LAN, MAC address pass-through, Port Disablement, Wake-On-Dock button, Wake-On-Dock, Dell Command Update, error messages and dock event notifications |
Physical
| Dimensions | 205 x 90 x 29 mm (8.07 x 3.54 x 1.14 in) |
| Mounting | VESA mounting using the Dell Docking Station mounting kit |
Compatibility & Software Support
Supported Operating Systems
Microsoft Windows 10, Windows 11, Ubuntu 18.04 and Red Hat Enterprise Linux, per the Dell datasheet.
Host Laptops
USB-C laptops; 130 W charging applies to Dell systems, up to 90 W to non-Dell systems. Display modes depend on the host's DisplayPort link (HBR2/HBR3) and DSC support.
Software
Dell Command Update for dock firmware updates.
Package Contents & Dell Docking Stations Ordering Information
In the Box
1 x WD19S dock with USB-C cable attached, 1 x 180 W power adapter.
Dell Docking Stations
| Model | Key feature |
| WD19S (this listing) | USB-C, up to 130 W to Dell PCs (180 W adapter) |
| WD19DCS | Dual USB-C, up to 210 W to Dell Precision 7000 (240 W adapter) |
| WD19TBS | Thunderbolt 3, up to 130 W to Dell PCs |
| HD22Q | USB-C dock with Qi wireless charging pad |
| WD22TB4 | Thunderbolt 4 dock |
| UD22 | USB-C universal dock |
| D6000S | Universal dock with DisplayLink |
| WD25 | Dell Pro USB-C dock, 100 W to Dell PCs |
| SD25 | Dell Pro USB-C smart dock |
| SD25TB4 | Dell Pro Thunderbolt 4 smart dock |
| SD25TB5 | Dell Pro Thunderbolt 5 smart dock |
Datasheet & Downloads
| Dell datasheet | Dell Dock WD19S 180W Datasheet (PDF) |
| User guide | WD19S User Guide on Dell Support |
| Manuals & drivers | Documents and drivers on Dell Support |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting WD19S.
Frequently Asked Questions — Dell WD19S
How much power does it give my laptop?
Up to 130 W to Dell systems and up to 90 W to non-Dell systems, from the included 180 W adapter.
Is it Thunderbolt?
No, it connects over USB-C. For Thunderbolt 3 see the WD19TBS.
How many monitors can I connect?
Up to three FHD or QHD displays, or two 4K @ 60Hz displays on HBR3 laptops with Display Stream Compression.
Can it be mounted?
Yes, with the Dell Docking Station mounting kit (VESA).
What warranty do I get?
The Dell datasheet states a 3-Year Limited Hardware Warranty with Advanced Exchange. SourceIT supplies it locally with a GST invoice; email us to confirm cover for your order.
