Dell P2223HC 22" Full HD USB-C Hub Monitor
PRODUCT DESCRIPTION
Dell 22 USB-C Monitor P2223HC (210-BDJT) - 3 Years Local Warranty
One-cable USB-C connectivity
A single USB-C connection (DisplayPort 1.2 Alt Mode) carries video, data and up to 65W of power to charge a compatible laptop, with four USB 3.2 Gen 1 downstream ports built in.
Full HD IPS with 99% sRGB
A 21.5-inch viewable IPS panel at 1920 x 1080, 250 cd/m2 brightness and 178/178 degree viewing angles, with an anti-glare coating and a 3-sided bezel-less design.
Comfortable all-day setup
Height (150 mm), tilt, swivel and pivot adjustment, ComfortView Plus built-in low blue light, and DisplayPort out with MST for daisy-chaining a second monitor.
Equipping a whole office? Email sales@sourceit.com.sg for volume pricing, delivery lead time and availability of current Dell successors.
Dell P2223HC Datasheet — Technical Specifications
Display
| Screen Size | 21.5 in viewable (22-inch class) |
| Panel Type | IPS, LED-backlit LCD / TFT active matrix |
| Resolution | Full HD 1920 x 1080 at 60 Hz |
| Aspect Ratio | 16:9 |
| Pixel Pitch | 0.24795 mm x 0.24795 mm |
| Brightness | 250 cd/m2 |
| Contrast Ratio | 1000:1 |
| Response Time | 14 ms (normal); 5 ms (fast) |
| Viewing Angles | 178 degrees horizontal / 178 degrees vertical |
| Colour Gamut | 99% sRGB |
| Colour Support | 16.7 million colours |
| Screen Coating | Anti-glare |
| Design | 3-sided bezel-less |
Connectivity
| USB-C | 1 x USB-C 3.2 Gen 1 upstream (DisplayPort 1.2 Alt Mode, Power Delivery up to 65W) |
| DisplayPort | 1 x DisplayPort 1.2 (HDCP 1.4) |
| HDMI | 1 x HDMI (HDCP 1.4) |
| DisplayPort Out | 1 x DisplayPort output (HDCP 1.4, MST) |
| USB Downstream | 4 x USB 3.2 Gen 1 (Type-A) |
Ergonomics
| Adjustments | Height, tilt, swivel, pivot |
| Height Adjustment | 150 mm |
| Tilt | -5 to +21 degrees |
| Swivel | -45 to +45 degrees |
| Pivot | -90 to +90 degrees |
| VESA Mounting | 100 x 100 mm |
Eye Comfort
| Low Blue Light | Dell ComfortView Plus (hardware-based) |
| Flicker | Flicker-free |
Power
| Input Voltage | AC 100-240 V (50/60 Hz) |
| USB-C Power Delivery | Up to 65W |
| Standby / Sleep | 0.3 W |
| Off Mode | 0.2 W |
Physical
| Dimensions with Stand (W x D x H) | 48.73 x 17.96 x 48.20 cm |
| Weight with Stand | 4.97 kg |
| Weight without Stand | 3.03 kg |
| Shipping Weight | 6.63 kg |
| Environmental | ENERGY STAR certified, TCO Certified Edge, RoHS, BFR-free, PVC-free, mercury-free, arsenic-free glass |
Warranty
| Dell SKU (Singapore) | 210-BDJT |
| Local Warranty (Singapore) | 3-Years Advanced Exchange Service and Premium Panel Guarantee, per dell.com Singapore |
Compatibility & Software Support
Connections
Connect a laptop over a single USB-C cable (DisplayPort Alt Mode with up to 65W charging), or use the DisplayPort 1.2 or HDMI inputs for desktops; DisplayPort out with MST allows daisy-chaining a second monitor.
Software
Dell Display Manager.
Package Contents & Dell P-Series 22–24-inch Monitors Ordering Information
In the Box
Monitor with stand, power cable, DisplayPort to DisplayPort cable (1.8 m), USB-C cable (1.8 m), cable tie and quick setup guide.
Dell P-Series 22–24-inch Monitors
| Model | Key feature |
| P2223HC 21.5" (this listing) | Full HD IPS, USB-C 65W hub, DP MST out |
| P2222H 21.5" | Full HD IPS, HDMI + DP + VGA, 4-port USB hub |
| P2319H 23" | Full HD IPS, DP/HDMI/VGA, USB 3.0 hub |
| P2418HT 23.8" Touch | Full HD IPS, 10-point touch, 60° tilt stand |
| P2422H 23.8" | Full HD IPS, 99% sRGB, 4-port USB 5Gbps hub |
| P2422HE 23.8" | Full HD IPS, USB-C 65W hub with RJ-45 |
| P2423 24" 16:10 | WUXGA 16:10 IPS, DP/HDMI/DVI/VGA, USB hub |
| P2423D 23.8" | QHD IPS, DP/HDMI, USB 3.2 hub |
| P2423DE 23.8" | QHD IPS, USB-C 90W hub, RJ45 |
| Pro 24 Plus P2424HT | Current-generation 24-inch touch USB-C hub monitor |
| Pro 24 Plus P2425H | Current-generation 24-inch Full HD |
| Pro 24 Plus P2425HE | Current-generation 24-inch Full HD USB-C hub |
| Pro 24 Plus P2425 | Current-generation 24-inch 16:10 WUXGA |
| Pro 24 Plus P2425D | Current-generation 24-inch QHD |
| Pro 24 Plus P2425DE | Current-generation 24-inch QHD USB-C hub |
Datasheet & Downloads
| Dell product page | Dell 22 USB-C Monitor - P2223HC on Dell Singapore |
| User guide | User's Guide, Quick Start Guide and other manuals on Dell Support |
| Datasheet | Dell P2223HC datasheet (PDF, Japanese) |
| Manuals & drivers | Dell Support: drivers, firmware and manuals for P2223HC |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting P2223HC.
Frequently Asked Questions — Dell P2223HC
Can the P2223HC charge my laptop over USB-C?
Yes. The USB-C upstream port supports USB Power Delivery up to 65W while also carrying video (DisplayPort 1.2 Alt Mode) and USB data.
How many USB ports does it have?
Four USB 3.2 Gen 1 downstream ports, fed through the USB-C upstream connection.
Can I daisy-chain two monitors?
Yes. The P2223HC has a DisplayPort output with MST support for connecting a second monitor.
What warranty does it come with?
Dell lists 3-Years Advanced Exchange Service and Premium Panel Guarantee for this monitor.
