ViewSonic M1 Max 1080p Smart LED Portable Projector with Google TV
PRODUCT DESCRIPTION
ViewSonic M1 Max 1080p Smart LED Portable Projector with Built-in Google TV - 2 Years Local Warranty
Built-in Google TV
Stream with Google TV and the native Netflix app built in, with no extra streaming stick needed.
Full HD 1080p
Native 1920 x 1080 resolution and 500 LED lumens for sharp pictures from 24" to 100".
3-in-1 Smart Stand
ViewSonic's patented stand rotates for 360° projection, including walls and ceilings.
Battery Powered
The integrated 12,000 mAh battery gives up to 1.5 hours (Normal) or 2 hours (Eco), and doubles as a power bank.
Harman Kardon Sound
Dual 3 W Harman Kardon speakers, with Bluetooth 5.0 audio out for headphones or an external speaker.
Questions about screen size, mounting or setup? Email sales@sourceit.com.sg and our team will help you choose.
ViewSonic M1 Max Datasheet — Technical Specifications
General
| Product Name | ViewSonic M1 Max 1080p Smart LED Portable Projector with Built-in Google TV |
| Model | M1 Max |
| Local Warranty (Singapore) | 2 years local limited warranty on parts and labour; LED light source, no lamp to replace |
Optical
| Projection System | 0.23" 1080p |
| Native Resolution | 1920 x 1080 |
| Brightness | 500 LED lumens |
| Contrast Ratio | 120,000:1 |
| Display Colour | 1.07 billion colours |
| Light Source | LED |
| Light Source Life | 60,000 hours (Normal) |
| Lens | F=1.7, f=7.4 mm |
| Throw Ratio | 1.2 |
| Optical Zoom | Fixed |
| Digital Zoom | 0.8x–1.0x |
| Image Size | 24"–100" |
| Throw Distance | 0.64–2.65 m (40" at 1.06 m) |
| Projection Offset | 100% ±5% |
| Keystone | H: ±40°, V: ±40°; auto H: ±20°, V: ±40° |
| Focus | Auto focus |
| Input Lag | 165 ms |
Compatibility
| Resolution Support | VGA (640 x 480) to Full HD (1920 x 1080) |
| HDTV Compatibility | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| Horizontal Frequency | 15–102 kHz |
| Vertical Scan Rate | 23–85 Hz |
Smart Features
| Platform | Built-in Google TV with native Netflix |
| Local Storage | 8 GB (4 GB available) |
| Wi-Fi | 5 GHz |
| Bluetooth | BT 5.0 audio out |
Connectivity
| HDMI | 1 x HDMI 1.4 (HDCP 1.4) |
| USB-C | 1 x USB Type-C (video; 5 V / 1 A out; DC in 15 V / 3 A) |
| USB-A | 1 x USB 2.0 (reader; 5 V / 1 A power and service, shared) |
| Audio Out | 1 x 3.5 mm |
| Speaker | 2 x 3 W cube (Harman Kardon) |
Power & Battery
| Power Supply | External adapter, 100–240 V input; 19 V DC / 3.26 A output |
| Battery | 12,000 mAh (4,000 mAh 3.7 V x 3) |
| Battery Life | 1.5 hours (Normal); 2 hours (Eco) |
| Power Consumption | 46 W (Normal); <0.5 W standby |
| Audible Noise | 26 dB (Normal); 25 dB (Eco) |
| Operating Temperature | 0–35 °C |
Physical
| Dimensions (W x D x H) | 182 x 141 x 62 mm (with adjustment foot) |
| Net Weight | 0.96 kg |
| Packing Dimensions | 235 x 190 x 130 mm |
| Gross Weight | 2.02 kg |
| OSD Languages | 24 |
Compatibility & Software Support
Streaming
Google TV and native Netflix run on the projector itself; add your apps with a Google account over 5 GHz Wi-Fi.
Phones and Laptops
Mirror over Wi-Fi, or connect a USB-C device that supports video output to project over one cable. HDMI 1.4 accepts consoles, laptops and streaming devices.
Audio
Send sound to Bluetooth headphones or speakers (BT 5.0), or use the 3.5 mm audio out.
Typical Use
Bedrooms, ceiling projection, balconies, kitchens, travel and outdoor movie nights.
Package Contents & ViewSonic Smart LED & Laser Home Projectors Ordering Information
In the Box
M1 Max projector, power cord, USB-C cable (1 m), Bluetooth remote control, sleeve bag, quick start guide, warranty card.
ViewSonic Smart LED & Laser Home Projectors
| Model | Key feature |
| M1 Max (this listing) | Portable 1080p LED, Google TV, battery |
| M10 | Portable 1080p RGB laser |
| X2 | 1080p short throw LED |
| X11-4KP | Portable 4K short throw LED |
| X100-4K+ | 4K UHD LED home cinema |
Datasheet & Downloads
| ViewSonic datasheet | M1 Max Datasheet |
| User guide | M1 Max User Guide (PDF, English) |
| Quick start guide | M1 Max Quick Start Guide (PDF) |
| ViewSonic product page | M1 Max on viewsonic.com |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting M1 Max.
Frequently Asked Questions — ViewSonic M1 Max
Does it have Netflix built in?
Yes. The M1 Max runs Google TV with the native Netflix app, so you do not need a separate streaming stick.
How long does the battery last?
Up to 1.5 hours in Normal mode or 2 hours in Eco mode from the 12,000 mAh battery; it also works as a power bank.
How big an image can I get?
From 24" up to 100". A 40" image needs about 1.06 m.
Can it project onto the ceiling?
Yes. The 3-in-1 smart stand rotates for 360° projection, and auto focus and auto keystone square up the image.
What warranty do I get?
2 years local limited warranty on parts and labour. Supplied by SourceIT with a GST invoice.
