ViewSonic X2 3,100 LED Lumens 1080p Short Throw Smart LED Home Projector
PRODUCT DESCRIPTION
ViewSonic X2 3,100 LED Lumens Full HD Short Throw Smart LED Home Projector - 2 Years Local Warranty
Bright Full HD from a Short Throw
The ViewSonic X2 projects native 1920 x 1080 at 3,100 LED lumens with a 3,000,000:1 contrast ratio, HDR and 3D support. A 0.69–0.83 throw ratio with 1.2x optical zoom fills a 100" screen from about 1.53 m.
Built for Gaming and Movies
An 8.3 ms input lag keeps fast games responsive, while Cinema SuperColor+ covers 125% Rec.709 for true-to-life film colour.
Maintenance-Free LED
The third-generation LED light source is rated for 30,000 hours, is mercury-free and powers on and off instantly.
Smart and Wireless
Screen mirroring over 5 GHz Wi-Fi, Bluetooth audio in/out, USB-C streaming from phones, two HDMI 2.0 inputs and Harman Kardon speakers.
Fitting out a home theatre, showroom or several rooms? Email sales@sourceit.com.sg for pricing and delivery lead time.
ViewSonic X2 Datasheet — Technical Specifications
General
| Product Name | ViewSonic X2 3,100 LED Lumens Full HD Short Throw Smart LED Home Projector |
| Model | X2 |
| Local Warranty (Singapore) | 2 years local limited warranty on parts and labour |
Optical
| Projection System | 0.65" 1080p |
| Native Resolution | 1920 x 1080 (Full HD) |
| Brightness | 3,100 LED lumens |
| Contrast Ratio | 3,000,000:1 |
| Display Colour | 1.07 billion colours |
| Light Source | LED |
| Light Source Life | 30,000 hours (Normal) |
| Lens | F=2.6–2.78, f=10.2–11.22 mm |
| Throw Ratio | 0.69–0.83 (short throw) |
| Optical Zoom | 1.2x |
| Digital Zoom | 0.8x–2.0x |
| Image Size | 60"–120" |
| Throw Distance | 0.92–2.2 m (100" at 1.53 m) |
| Projection Offset | 105% ±5% |
| Keystone | H ±40°, V ±40°; 4-corner adjustment; auto vertical keystone |
| Input Lag | 8.3 ms |
Compatibility
| Resolution Support | VGA (640 x 480) to 4K (3840 x 2160) input |
| HDTV Compatibility | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p |
| Horizontal Frequency | 15–135 kHz |
| Vertical Scan Rate | 23–120 Hz |
| Local Storage | 16 GB total (11 GB available) |
Connectivity
| HDMI | 2 x HDMI 2.0 (HDCP 1.4/2.2) |
| USB-C | 1 x USB Type-C (5 V / 1 A) |
| Audio In | 1 x 3.5 mm; Bluetooth 4.2 |
| USB Reader | 1 x USB 2.0 Type-A |
| Wi-Fi | 5 GHz (802.11n) |
| Audio Out | 1 x 3.5 mm; Bluetooth 4.2 |
| USB Power | 1 x USB Type-A (5 V / 1 A, shared) |
| Control | 1 x RS232 (DB9 male) |
| USB Service | 1 x USB Type-A |
| Speakers | 2 x 6 W Harman Kardon (full range) |
Power & Environmental
| Power Supply | 100–240 V ±10%, 50/60 Hz |
| Power Consumption | 218 W (Normal); <0.5 W standby |
| Audible Noise | 31 dB (Normal); 27 dB (Eco) |
| Operating Temperature | 0–40 °C |
Physical
| Dimensions (W x D x H) | 355 x 251 x 121 mm |
| Net Weight | 3.6 kg |
| Packing Dimensions | 490 x 376 x 313 mm |
| Gross Weight | 5.5 kg |
| OSD Languages | 24 |
Compatibility & Software Support
Sources
Two HDMI 2.0 inputs (HDCP 2.2) accept consoles, streaming sticks and laptops; 4K signals are accepted and shown at 1080p. USB-C streams directly from supported phones while charging them.
Wireless
Screen mirroring over 5 GHz Wi-Fi and the vCastSender app for phone-based touch control; Bluetooth to use it as a speaker or pair wireless headphones.
Eye Care
TÜV SÜD low blue light certification.
Typical Use
Living rooms, bedrooms and game rooms where a big screen is wanted without a long throw distance.
Package Contents & ViewSonic Smart LED & Laser Home Projectors Ordering Information
In the Box
X2 projector, power cord, USB-C cable (1 m), backlit remote control, quick start guide.
Optional Accessories
| Wall/ceiling mount | PJ-WMK-007 |
| HDBaseT receiver | HB10B |
ViewSonic Smart LED & Laser Home Projectors
| Model | Key feature |
| M10 | Portable RGB laser 1080p |
| X2 (this listing) | 3,100 LED lm 1080p short throw |
| X11-4KP | 4K portable short throw LED |
| X100-4K+ | 2,900 LED lm 4K, lens shift |
Datasheet & Downloads
| ViewSonic datasheet | X2 Datasheet |
| User guide | X1 / X2 User Guide (PDF, English) |
| Quick start guide | X2 Quick Start Guide (PDF) |
| ViewSonic product page | X2 on viewsonic.com Singapore |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting X2.
Frequently Asked Questions — ViewSonic X2
How far from the wall for a 100" picture?
About 1.53 m. Image sizes run from 60" to 120".
Is it good for gaming?
Yes. ViewSonic rates the input lag at 8.3 ms.
Can I cast from my phone?
Yes, over 5 GHz Wi-Fi, or by USB-C on phones that support video output.
Is there a lamp to replace?
No. The LED light source is rated for 30,000 hours.
What warranty do I get?
2 years local limited warranty on parts and labour. Supplied by SourceIT with a GST invoice.
