NVIDIA RTX PRO™ 6000 Blackwell Max-Q Workstation Edition
PRODUCT DESCRIPTION
NVIDIA RTX PRO™ 6000 Blackwell Max-Q Workstation Edition 96 GB GDDR7 with ECC (900-5G153-2500-000) - 3 Years Local Warranty
RTX PRO 6000 Blackwell Max-Q Workstation Edition — 96 GB in a 300 W Envelope
The NVIDIA RTX PRO™ 6000 Blackwell Max-Q Workstation Edition answers a specific problem: you need the full 96 GB of GDDR7 with ECC and all 24,064 CUDA cores, but your chassis or your power budget cannot absorb a 600 W card. Max-Q keeps the same memory capacity and the same 1,792 GB/s of bandwidth at 300 W total board power in a standard 4.4in x 10.5in dual-slot full-height card.
3,511 AI TOPS for Multi-GPU Workstations
Fifth-generation Tensor Cores deliver up to 3,511 AI TOPS (effective FP4 with sparsity) with 110 TFLOPS FP32 and 333 TFLOPS of RT Core performance. Because each card draws half the power of the Workstation Edition, Max-Q is the variant to specify when you want two or more 96 GB cards in one chassis — 192 GB or more of aggregate ECC VRAM in a workstation that stays inside its thermal and power design.
Multi-Instance GPU for Shared Teams
MIG splits the card into up to four isolated 24 GB instances, two at 48 GB, or one at 96 GB, giving hard boundaries between users or containers on shared hardware.
Standard Form Factor, Standard Power
4.4in x 10.5in, dual slot, full height, active cooling, PCIe 5.0 x16 and a single PCIe CEM5 16-pin connector. It fits the workstation chassis you already buy, which is the whole point of the Max-Q variant.
NVIDIA RTX PRO™ 6000 Blackwell Max-Q Workstation Edition Datasheet — Technical Specifications
General
| Part Number | 900-5G153-2500-000 |
| Model | NVIDIA RTX PRO™ 6000 Blackwell Max-Q Workstation Edition |
| GPU Architecture | NVIDIA Blackwell |
| Product Family | NVIDIA RTX PRO Blackwell Workstation / Professional Desktop GPUs |
| Warranty | 3 Years Local Warranty (Singapore) |
Memory
| GPU Memory | 96 GB GDDR7 with ECC |
| Memory Interface | 512-bit |
| Memory Bandwidth | 1,792 GB/s |
| ECC | Yes — error-correcting code memory |
Compute & Performance
| CUDA Cores | 24,064 |
| Tensor Cores | Fifth-generation Tensor Cores — 752 (core count per NVIDIA RTX PRO Blackwell architecture whitepaper) |
| RT Cores | Fourth-generation RT Cores — 188 (core count per NVIDIA RTX PRO Blackwell architecture whitepaper) |
| Single-Precision (FP32) Performance | 110 TFLOPS |
| RT Core Performance | 333 TFLOPS |
| AI Performance | 3,511 AI TOPS (effective FP4 TOPS with sparsity, peak rates based on GPU Boost Clock) |
| Multi-Instance GPU (MIG) | Yes — up to 4x 24 GB, up to 2x 48 GB, or 1x 96 GB (maximum 4 instances) |
Media Engines
| Encoders (NVENC) | 4x NVENC (ninth generation) |
| Decoders (NVDEC) | 4x NVDEC (sixth generation), 4:2:2 support |
Display
| Display Connectors | 4x DisplayPort 2.1b |
| Maximum Simultaneous Displays | 4x 4096 x 2160 @ 120 Hz; 4x 5120 x 2880 @ 60 Hz; 2x 7680 x 4320 @ 60 Hz |
Power, Form Factor & Interface
| Maximum Power Consumption | 300 W total board power |
| Graphics Bus | PCIe 5.0 x16 |
| Form Factor | 4.4in (H) x 10.5in (L), dual slot, full height |
| Thermal Solution | Active |
| Power Connector | 1x PCIe CEM5 16-pin |
Specifications are taken from NVIDIA's published datasheet for this model. Fields NVIDIA does not publish for a given card are shown as such rather than estimated.
Compatibility & Software Support
| Graphics APIs | DirectX 12 (Shader Model 6.6), OpenGL 4.6, Vulkan 1.4 |
| Compute APIs | CUDA 12.8, OpenCL 3.0, DirectCompute |
| Operating Systems | Windows 10/11 64-bit; Linux — RHEL 8.10, SUSE Linux Enterprise Desktop 15.6, OpenSUSE 15.6, Fedora 41, Ubuntu 22.04; FreeBSD 14.2; Solaris 11 U4 (per NVIDIA RTX PRO Blackwell Quick Start Guide) |
| Drivers | NVIDIA RTX Enterprise Driver — Production Branch and New Feature Branch |
| Professional Applications | Certified across leading CAD, DCC, BIM, medical imaging and simulation ISV applications |
| AI Frameworks | CUDA, cuDNN, TensorRT, PyTorch, TensorFlow, NVIDIA NIM and NGC containers |
| Omniverse / Digital Twin | Supported via NVIDIA Omniverse and OpenUSD workflows |
| Chassis Check | 4.4in (H) x 10.5in (L), dual slot, full height — confirm slot clearance, power headroom and airflow before ordering |
SourceIT can verify fit against your specific workstation or server model before you order. For ISV certification status on a named application version, check the NVIDIA professional product literature library.
Package Contents & NVIDIA RTX PRO Blackwell Ordering Information
What is in the box: NVIDIA's RTX PRO Blackwell Quick Start Guide lists a Quick Start Card and an auxiliary power cable (2x PCIe 8-pin PSU to 1x PCIe Gen5 16-pin GPU adapter). NVIDIA does not publish a per-SKU box-contents list on the datasheet.
NVIDIA RTX PRO Blackwell range available from SourceIT:
| Part Number | Model & Memory |
| 900-5G144-2500-000 | RTX PRO 6000 Blackwell Workstation Edition — 96 GB GDDR7 with ECC |
| 900-5G153-2500-000 | RTX PRO 6000 Blackwell Max-Q Workstation Edition — 96 GB GDDR7 with ECC (this item) |
| 900-2G153-0000-000 | RTX PRO 6000 Blackwell Server Edition — 96 GB GDDR7 with ECC |
| 900-5G153-2570-000 | RTX PRO 5000 Blackwell 72 GB — 72 GB GDDR7 with ECC |
| 900-5G153-2550-000 | RTX PRO 5000 Blackwell 48 GB — 48 GB GDDR7 with ECC |
| 900-5G147-2550-000 | RTX PRO 4500 Blackwell — 32 GB GDDR7 with ECC |
| 900-5G147-2570-000 | RTX PRO 4000 Blackwell — 24 GB GDDR7 with ECC |
| 900-5G195-2501-000 | RTX PRO 4000 Blackwell SFF Edition — 24 GB GDDR7 with ECC |
| 900-5G195-2551-000 | RTX PRO 2000 Blackwell — 16 GB GDDR7 with ECC |
Choosing between them: memory capacity is usually the deciding factor for AI work and scene size, while form factor and power decide what will physically fit. The Max-Q variant exists to give full 96 GB capacity at 300 W for chassis that cannot take a 600 W card or that need more than one GPU. The Server Edition is passively cooled and belongs in a server, not a workstation. The SFF Edition trades bandwidth and PCIe lanes for a 70 W low-profile board.
Datasheet & Downloads
- NVIDIA RTX PRO™ 6000 Blackwell Max-Q Workstation Edition official NVIDIA datasheet
- NVIDIA RTX PRO™ 6000 Blackwell Max-Q Workstation Edition product page on NVIDIA.com
- NVIDIA RTX PRO Blackwell GPU Architecture Whitepaper (PDF)
- NVIDIA RTX PRO Blackwell Quick Start Guide (PDF)
- NVIDIA professional workstation product literature library
Frequently Asked Questions — RTX PRO 6000 Blackwell Max-Q Workstation Edition
How much GPU memory does it have, and why does that matter?
96 GB GDDR7 with ECC. For AI work, VRAM capacity decides which models fit on the card at all — a model that does not fit runs an order of magnitude slower or not at all. For visualisation it decides scene and texture budget. ECC means single-bit memory errors are corrected rather than silently corrupting a long job.
What do I give up versus the full 600 W Workstation Edition?
Roughly 12 percent of peak throughput for half the power. The Workstation Edition delivers 4,000 AI TOPS and 126 TFLOPS FP32 at 600 W; Max-Q delivers 3,511 AI TOPS and 110 TFLOPS at 300 W. Memory, bandwidth and CUDA core count are identical. In multi-GPU or power-constrained builds Max-Q usually wins on total system throughput.
What power supply and chassis clearance do I need?
This card is 300 w total board power in a 4.4in (H) x 10.5in (L), dual slot, full height form factor with active cooling, powered via 1x PCIe CEM5 16-pin. Check both physical clearance and PSU headroom against your workstation before ordering — send us your machine model and we will confirm fit.
Does it support Multi-Instance GPU?
Yes — up to 4x 24 GB, up to 2x 48 GB, or 1x 96 GB (maximum 4 instances). Each instance gets isolated memory and compute, so several users, containers or services can share one card with hard boundaries instead of contending for it.
Is this a professional card or a gaming card?
Professional. RTX PRO Blackwell cards carry ECC memory, NVIDIA RTX Enterprise drivers with ISV application certification, longer driver support branches and a professional warranty. Consumer GeForce cards have none of these, which is why they are not accepted in most enterprise and regulated deployments regardless of raw frame rate.
Does it come with local warranty in Singapore?
Yes. Every RTX PRO 6000 Blackwell Max-Q Workstation Edition sold by SourceIT comes with 3 years local Singapore warranty and a GST invoice.
