NETGEAR APM414V 4-Port 25G SFP28 Interface Card for M4350-16M4V
Email sales@sourceit.com.sg or use Request for Quotation below and our team will confirm the latest price, availability and lead time.
PRODUCT DESCRIPTION
NETGEAR APM414V 4x 25G SFP28 Interface Card for M4350-16M4V (APM414V-10000S) - Limited Lifetime Local Warranty
25G SFP28 for the M4350-16M4V Modular Slot
The NETGEAR APM414V is an interface card with four standard 25G SFP28 ports that run at 10G or 25G. It fits the modular slot of the NETGEAR M4350-16M4V (MSM4320) fully managed AV switch, which provides one slot for four ports at 10G or 25G.
The Card That Ships with the Switch
The M4350-16M4V ships with one APM414V pre-installed. Order this listing as a spare, or to return a switch to SFP28 ports after fitting one of the other APM414 cards.
One of Four APM414 Cards
NETGEAR offers four interface cards for this slot: APM414V (4x SFP28), APM414C (4x 10GBASE-T RJ-45), APM414SD (2x Neutrik opticalCON QUAD, multimode fibre) and APM414LD (2x Neutrik opticalCON QUAD, single-mode fibre). Choose the card that matches the cabling at your site.
Not sure which model fits your project? Email sales@sourceit.com.sg with your requirements and we will confirm it for you.
NETGEAR APM414V Datasheet — Technical Specifications
General
| Product Name | NETGEAR APM414V Interface Card |
| Part Number | APM414V-10000S |
| Local Warranty (Singapore) | Limited lifetime, supplied by SourceIT with a GST invoice |
Ports
| Ports | 4x standard 25G SFP28 |
| Supported Speeds | 10G, 25G |
| Transceivers | SFP28 transceivers or cables are ordered separately |
Host Switch
| Compatible Switch | NETGEAR M4350-16M4V (MSM4320) |
| Host Slot | 1 modular slot for 4 ports 10G; 25G |
| Card Shipped with the Switch | APM414V (4x 25G SFP28), pre-installed |
Compatibility & Software Support
Compatible Switch
In the NETGEAR M4350 series datasheet, the M4350-16M4V (MSM4320-100NES) is the only model with a modular interface card slot.
Transceivers
The card has standard SFP28 cages. NETGEAR does not list transceivers in the card description — order SFP28/SFP+ modules or DAC cables separately. Email sales@sourceit.com.sg to confirm compatible modules for your link.
Installation
The card ships installed in the M4350-16M4V; a spare goes in the same modular slot. Follow the procedure in the NETGEAR M4350 Series Hardware Installation Guide (see Datasheet & Downloads).
Package Contents & APM414 Module Ordering Information
In the Box
1x NETGEAR APM414V interface card. NETGEAR does not publish a separate package-contents list for the card. Email sales@sourceit.com.sg if you need it confirmed before ordering.
NETGEAR APM414 Interface Cards
| Model | Ports |
| APM414V (APM414V-10000S) (this listing) | 4x standard 25G SFP28 (10G, 25G); pre-installed in the M4350-16M4V |
| APM414C (APM414C-10000S) | 4x standard 10GBASE-T RJ-45 (1G, 10G) |
| APM414SD (APM414SD-10000S) | 2x Neutrik opticalCON QUAD for 4x multimode fibre (MMF) transceivers (10G, 25G) |
| APM414LD (APM414LD-10000S) | 2x Neutrik opticalCON QUAD for 4x single-mode fibre (SMF) transceivers (10G, 25G) |
Compatible Host Switch
| M4350-16M4V (MSM4320-100NES) | 16x 2.5G PoE++ (8x Neutrik etherCON), 1 modular slot for 4 ports 10G/25G |
Datasheet & Downloads
| Datasheet | NETGEAR M4350 Series Datasheet (PDF) |
| Product Brief | NETGEAR M4350 Series Product Brief (PDF) |
| Installation Guide | NETGEAR M4350-16M4V Installation Guide (PDF) |
| Hardware Installation Guide | NETGEAR M4350 Series Hardware Installation Guide (PDF) |
| NETGEAR product page | M4350-16M4V (MSM4320) on netgear.com |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting APM414V-10000S.
Frequently Asked Questions — NETGEAR APM414V
Which switches accept the APM414V?
The NETGEAR M4350-16M4V (MSM4320). According to the M4350 datasheet, it is the only M4350 model with a modular interface card slot.
What speeds does it support?
10G and 25G.
Do I need to buy this card with the switch?
No. The M4350-16M4V ships with one APM414V pre-installed. Order the APM414V as a spare or replacement.
What warranty do I get?
Limited lifetime local warranty in Singapore, supplied by SourceIT with a GST invoice.
