Huawei eKitEngine S310-48T4S 48-Port Gigabit L2+ Managed Switch, 4 x SFP
PRODUCT DESCRIPTION
Huawei eKitEngine S310-48T4S 48-Port Gigabit L2+ Managed Switch (S310-48T4S) - 1 Year Local Warranty
48 Gigabit Ports in 1U
The Huawei eKitEngine S310-48T4S is a Layer 2+ managed switch with 48 Gigabit RJ45 ports and 4 Gigabit SFP uplinks for larger SME offices and floors.
Performance
Huawei rates the switch at 104 Gbit/s switching capacity and a 77 Mpps forwarding rate.
Stack and Manage from the Cloud
iStack lets you stack up to four S310 switches. Per Huawei's S310 series datasheet, it supports static routing and policy-based routing and cloud management through the HUAWEI eKit app.
Built for Rack, Desk or Wall
A 1U metal chassis with a built-in AC power supply, ±6 kV surge protection and a single fan module.
Need help choosing? Email sales@sourceit.com.sg with your port count and uplink needs and we will size it for you.
Huawei S310-48T4S Datasheet — Technical Specifications
General
| Product Name | Huawei eKitEngine S310-48T4S Gigabit Switch |
| Model | S310-48T4S |
| Part Number | 98012203 |
| Switch Type | Layer 2+ managed (static routing) |
| Local Warranty (Singapore) | 1 year carry-in warranty, supplied by SourceIT with a GST invoice |
Interfaces
| GE RJ45 Ports | 48 x 10/100/1000BASE-T |
| GE SFP Ports | 4 x GE SFP |
| PoE | No |
Performance
| Switching Capacity | 104 Gbit/s |
| Forwarding Rate | 77 Mpps |
| MAC Address Table | 16K entries (per S310 series datasheet) |
| Stacking | iStack, up to 4 switches of the same series |
Power & Physical
| Power Supply | Built-in AC: 90–264 V AC, 45–65 Hz |
| Power Consumption | Static 27.55 W; typical 44.9 W; max 52.05 W |
| Surge Protection | ±6 kV |
| Cooling | 1 fan module; air in left, out right |
| Dimensions (H x W x D) | 43.6 x 442 x 220 mm (227 mm max. depth) |
| Weight | 2.71 kg (3.59 kg packed) |
| Installation | Rack, desk or wall |
| Chassis | Metal |
| Operating Temperature | -5 to +50 °C |
Specifications from Huawei's official eKit product page for the S310-48T4S (part number 98012203); MAC table from Huawei's S310 series datasheet.
Compatibility & Software Support
Management
Per Huawei's S310 series datasheet: web, CLI and SNMP v1/v2/v3 management, plus cloud configuration, monitoring and inspection through the HUAWEI eKit app.
Layer 2+ Features
L2 switching with static routing and policy-based routing (PBR), 4,094 VLANs and L2–L4 ACLs per Huawei's S310 series datasheet.
Typical Use
Access switching for SME offices, shops and branches, uplinked by SFP to a core switch or an eKitEngine S380 / NetEngine AR gateway.
Package Contents & Huawei eKitEngine S310 Ordering Information
Huawei eKitEngine S310 Models
| Model | Ports | PoE | Part No. |
| S310-24T4S | 24 x GE + 4 x GE SFP | — | S310-24T4S |
| S310-24P4S | 24 x GE PoE+ + 4 x GE SFP | 400 W | S310-24P4S |
| S310-48T4S (this listing) | 48 x GE + 4 x GE SFP | — | S310-48T4S |
Package contents are not listed on Huawei's eKit product page — ask us if you need confirmation of the included power cord and mounting kit.
Datasheet & Downloads
| Huawei eKit product page | S310-48T4S on ekit.huawei.com |
| Huawei datasheet | eKitEngine S310 Series Switches Datasheet (e.huawei.com) |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting S310-48T4S.
Frequently Asked Questions — Huawei S310-48T4S
Does the S310-48T4S support PoE?
No. For PoE in the S310 family choose the S310-24P4S (24 x PoE+, 400 W).
Is it a Layer 3 switch?
Huawei's S310 series datasheet lists static routing and policy-based routing; dynamic routing protocols such as OSPF are not listed. Ask us before planning dynamic routing on it.
Can I stack it?
Yes, iStack supports up to 4 switches of the same series.
What warranty do I get?
1 year local carry-in warranty in Singapore, supplied by SourceIT with a GST invoice.
