Huawei NetEngine AR720 Enterprise Router, 2 x GE Combo WAN, 8 x GE LAN
PRODUCT DESCRIPTION
Huawei NetEngine AR720 Enterprise Router with 2 x GE Combo WAN and 8 x GE LAN (AR720) - 1 Year Local Warranty
Enterprise Routing for SME and Branch Sites
The Huawei NetEngine AR720 is a 1U enterprise router from Huawei's AR700 series, rated by Huawei for up to 700 connected terminals and 9–25 Mpps forwarding performance.
Flexible WAN and LAN
Two GE combo WAN ports accept copper or fibre, and eight Gigabit LAN ports can be switched to WAN ports when you need more internet lines.
Built for the Rack
A 442 mm 1U chassis with a built-in AC power supply that can also sit on a workbench or mount on a wall.
Need help choosing? Email sales@sourceit.com.sg with your number of users, internet lines and branch sites and we will size it for you.
Huawei AR720 Datasheet — Technical Specifications
General
| Product Name | Huawei NetEngine AR720 Enterprise Router |
| Model | AR720 |
| Part Number | 02354GBG-001 |
| Type | Enterprise router / gateway, 1U |
| Local Warranty (Singapore) | 1 year carry-in warranty, supplied by SourceIT with a GST invoice |
Interfaces
| WAN | 2 x GE combo (RJ45/SFP) |
| LAN | 8 x GE RJ45 (can be switched to WAN ports) |
Performance
| Forwarding Performance | 9 Mpps to 25 Mpps |
| Connected Terminals | 700 |
Power & Physical
| Power Supply | Built-in AC, 90–264 V, 47–63 Hz |
| Power Consumption | Typical 28 W; max 33 W |
| Dimensions (H x W x D) | 44.4 x 442 x 220.4 mm, 1U |
| Weight | 3.2 kg (4.6 kg packed) |
| Installation | Rack, workbench or wall |
| Operating Temperature | 0 to 45 °C |
| Operating Humidity | 5% to 95% RH, non-condensing |
Specifications from Huawei's official eKit product page for the AR720 (part number 02354GBG-001).
Compatibility & Software Support
Typical Use
Branch and SME internet gateway / enterprise router for sites of up to 700 connected terminals, per Huawei's eKit product page.
Expansion
The distributor price list describes the AR700 models with 2 x USB and 2 x SIC slots; these are not listed on Huawei's eKit product page — ask us to confirm expansion options and supported cards before ordering.
Features
Huawei's eKit page lists hardware specifications only. Ask us for the software feature set (routing protocols, VPN, security) for your deployment, and we will confirm against Huawei's AR700 datasheet.
Package Contents & Huawei NetEngine AR700 Ordering Information
Huawei NetEngine AR700 Models
| Model | WAN | LAN | Part No. |
| AR720 (this listing) | 2 x GE combo | 8 x GE (switchable to WAN) | AR720 |
| AR730 | 2 x GE combo + 1 x 10GE SFP+ | 8 x GE + 1 x GE combo | AR730 |
Package contents are not listed on Huawei's eKit product page — ask us if you need confirmation of the included power cord and rack-mount kit.
Datasheet & Downloads
| Huawei eKit product page | AR720 on ekit.huawei.com |
| Huawei datasheet | NetEngine AR700 Series Enterprise Router Datasheet (e.huawei.com) |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting AR720.
Frequently Asked Questions — Huawei AR720
How many users does it support?
Huawei's eKit page rates the AR720 for 700 connected terminals. For up to 1,200, see the AR730.
Does it have a 10G port?
No. For a 10GE SFP+ WAN port, choose the AR730.
Does it have built-in Wi-Fi?
No Wi-Fi is listed — pair it with Huawei access points and a controller.
What warranty do I get?
1 year local carry-in warranty in Singapore, supplied by SourceIT with a GST invoice.
