Huawei eKitEngine S380-H8T3ST Multi-Service Gateway, SFP WAN, 8 x GE LAN
PRODUCT DESCRIPTION
Huawei eKitEngine S380-H8T3ST Multi-Service Gateway with SFP WAN and Built-in WAC (S380-H8T3ST) - 1 Year Local Warranty
Router, Switch and Wi-Fi Controller in One Box
The Huawei eKitEngine S380-H8T3ST is a multi-service gateway from Huawei's eKit SME range. It combines routing, switching and a built-in wireless access controller (WAC), so one box runs your internet connection, wired LAN and Huawei Wi-Fi APs.
Three WAN Ports Including Fibre
Two Gigabit RJ45 WAN ports plus a Gigabit SFP WAN port for a fibre internet line, with eight Gigabit LAN ports — the largest model in the S380 family, supporting up to 500 users.
Simple Setup with the HUAWEI eKit App
Huawei supports QR-code onboarding in cloud management mode through the HUAWEI eKit app, alongside web and SSH management.
Need help choosing? Email sales@sourceit.com.sg with your number of users, access points and internet lines and we will size it for you.
Huawei S380-H8T3ST Datasheet — Technical Specifications
General
| Product Name | Huawei eKitEngine S380-H8T3ST Multi-Service Gateway |
| Model | S380-H8T3ST |
| Part Number | 98012181 |
| Type | Multi-service gateway (routing, switching, WAC) |
| Local Warranty (Singapore) | 1 year carry-in warranty, supplied by SourceIT with a GST invoice |
Interfaces
| WAN | 2 x GE RJ45 + 1 x GE SFP |
| LAN | 8 x GE RJ45 |
| PoE | No |
Capacity & Performance
| Max. Users | 500 |
| Managed APs | 128 (eKit product page); 64 per S380 series datasheet |
| Switching Capacity | 16 Gbit/s |
| Forwarding Rate | Upload 500 Kpps; download 420 Kpps |
| Egress Bandwidth | 2 Gbit/s |
Power & Physical
| Dimensions (H x W x D) | 43.6 x 442 x 160 mm (165.2 mm max. depth), 1U |
| Installation | Rack, desk or wall |
| Chassis | Metal |
| Weight | 1.6 kg (2.1 kg packed) |
| Power Supply | Built-in AC, 90–264 V, 45–65 Hz |
| Power Consumption | Typical 11.25 W; max 11.5 W |
| Surge Protection | ±6 kV |
| Cooling | Natural heat dissipation |
| Operating Temperature | 0 to 40 °C |
| Operating Humidity | 5% to 95% RH, non-condensing |
Specifications from Huawei's official eKit product page for the S380-H8T3ST (part number 98012181). Huawei's eKit page and its S380 series datasheet publish different capacity figures for this model; both are shown.
Compatibility & Software Support
Routing, Switching and WAC in One
Per Huawei's S380 series datasheet: static routing, load balancing, DHCP server/client, DNS client, PPPoE client, NAT, ACL and 16 VLANs (access, trunk and hybrid ports), plus a built-in wireless access controller for Huawei eKit APs such as the AP362 and AP263.
Management
Web system, HUAWEI eKit app and SSH per Huawei's datasheet, with QR-code onboarding in cloud management mode. Huawei does not list built-in Wi-Fi — pair it with Huawei eKit access points.
Typical Use
The internet gateway for a small office, shop, clinic or café, running the whole eKit network (switches and APs) from one box.
Package Contents & Huawei eKitEngine S380 Ordering Information
Huawei eKitEngine S380 Models
| Model | WAN / LAN | Users / APs (eKit page) | Part No. |
| S380-L4T1T | 1 x GE WAN / 4 x GE LAN | 200 / 32 | S380-L4T1T |
| S380-L4P1T | 1 x GE WAN / 4 x GE LAN PoE+ (50 W) | 200 / 32 | S380-L4P1T |
| S380-S8T2T | 2 x GE WAN / 8 x GE LAN | 300 / 64 | S380-S8T2T |
| S380-S8P2T | 2 x GE WAN / 8 x GE LAN PoE+ (124 W) | 300 / 64 | S380-S8P2T |
| S380-H8T3ST (this listing) | 2 x GE + 1 x GE SFP WAN / 8 x GE LAN | 500 / 128 | S380-H8T3ST |
Package contents are not listed on Huawei's eKit product page — ask us if you need confirmation of the included power supply and mounting accessories.
Datasheet & Downloads
| Huawei eKit product page | S380-H8T3ST on ekit.huawei.com |
| Huawei datasheet | eKitEngine S380 Series Multi-Service Gateway Datasheet (e.huawei.com) |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting S380-H8T3ST.
Frequently Asked Questions — Huawei S380-H8T3ST
How many users and APs does it support?
500 users. For APs, Huawei's eKit product page lists 128 while Huawei's S380 series datasheet lists 64 — ask us to confirm for your firmware if you plan more than 64 APs.
Does it support a fibre internet line?
Yes, one of its three WAN ports is a Gigabit SFP port.
Does it have built-in Wi-Fi?
No. The S380 is a wired gateway with a built-in wireless access controller — add Huawei eKit access points such as the AP362 or AP263 for Wi-Fi.
Does it support VPN or SD-WAN?
Huawei's eKit page and S380 datasheet do not list VPN or SD-WAN features. For site-to-site VPN requirements, ask us before ordering.
What warranty do I get?
1 year local carry-in warranty in Singapore, supplied by SourceIT with a GST invoice.
