HPE ProLiant DL365 Gen11 1U Rack Server
Email sales@sourceit.com.sg or use Request for Quotation below and our team will confirm the latest price, availability and lead time.
PRODUCT DESCRIPTION
HPE ProLiant DL365 Gen11 1U Rack Server (Configure-to-Order) - Local Warranty
Dense 1U, Dual-Socket AMD EPYC Compute
The HPE ProLiant DL365 Gen11 takes two 4th or 5th Gen AMD EPYC 9004/9005 series processors (up to 160 cores each with 9005, up to 400 W TDP) and 24 DDR5 RDIMM slots for up to 6 TB at up to 6400 MT/s, in a single rack unit.
Flexible Storage and PCIe Gen5 I/O
Choose 8 SFF (expandable to 10 SFF) or 20 EDSFF E3.S NVMe drives, or a GPU configuration with 8 EDSFF or 4 SFF. PCIe 5.0 x16 slots and two OCP 3.0 slots support up to two single-wide or two double-wide GPUs, such as NVIDIA L4 or A16.
Secure, Cloud-Managed and Liquid-Cooling Ready
HPE iLO 6 with silicon root of trust secures the platform from the firmware up, HPE Compute Ops Management adds cloud-based fleet monitoring, and Direct Liquid Cooling is available for the highest-wattage processors. HPE's standard warranty is 3 years parts, 3 years labour and 3 years onsite next-business-day.
HPE ProLiant DL365 Gen11 Datasheet — Technical Specifications
General
| Product Name | HPE ProLiant DL365 Gen11 Server |
| Form Factor | 1U rack, 2-socket |
| Order Type | Configure-to-Order (CPU, memory, drive cage, controller, NIC, PSU and support term chosen per order) |
| HPE Standard Warranty | 3 years parts, 3 years labour, 3 years onsite, next business day |
| Local Warranty (Singapore) | Supplied by SourceIT with HPE warranty; HPE Care Pack upgrades available at configuration |
Processor & Memory
| Processors | Up to two 4th or 5th Gen AMD EPYC 9004/9005 series processors; up to 128 cores (9004) or 160 cores (9005) per processor, up to 400 W TDP |
| Memory Slots | 24 DIMM slots (12 per processor), HPE DDR5 Smart Memory RDIMM |
| Maximum Memory | 6 TB (24 x 256 GB RDIMM) |
| Memory Speed | Up to 6400 MT/s with 5th Gen; up to 4800 MT/s with 4th Gen AMD EPYC |
Storage
| Drive Cage Options | 8 x SFF (expandable to 10 SFF); 20 x EDSFF E3.S NVMe; GPU configuration with 8 x EDSFF or 4 x SFF |
| RAID Controllers | HPE MR216i-p / MR216i-o, MR408i-o, MR416i-p / MR416i-o, SR932i-p Gen11 |
| Boot Device | HPE NS204i-u Gen11 NVMe Hot Plug Boot Optimized Storage Device |
Expansion & Networking
| PCIe Slots | Primary riser: PCIe 5.0 x16 full-height; secondary riser: PCIe 5.0 x16 full-height or low profile; GPU risers with full-height, full-length PCIe 5.0 x16 slots |
| OCP Slots | 2 x OCP 3.0 |
| Embedded NIC | None; networking via OCP 3.0 or PCIe adapters |
| GPU Support | Up to two single-wide or two double-wide GPUs, including NVIDIA A16, NVIDIA L4 and NVIDIA RTX PRO 4500 Blackwell Server Edition |
Management & Security
| Management | HPE iLO 6; HPE Compute Ops Management |
| Security | HPE iLO silicon root of trust, secure boot and firmware validation; TPM 2.0 (optional) |
Power & Cooling
| Power Supplies | HPE Flex Slot hot-plug options: 800 W Platinum, 1000 W Titanium, 1600 W Platinum, 1600 W -48 VDC and 1800 W to 2200 W Titanium |
| Fans | Up to 7 fans with redundancy |
| Cooling Options | Air cooling; Direct Liquid Cooling (DLC) option |
How to Configure Your Server — Sizing Checklist
Servers are built to order. Answer the questions below so we can size the right configuration for you.
Step 1: Hardware Requirements
- Which server form factor do you need: tower or rackmount?
- How many CPU cores, how much RAM and how much usable storage capacity do you require?
- How many processors: single-socket (1S), dual-socket (2S) or four-socket (4S)?
- Which RAID configuration do you need? Any specific HDD or SSD type, such as 7.2K or 10K rpm drives?
- Which network interface is required: 1GbE Base-T, SFP+ or Fibre Channel?
- How many years of maintenance support do you need? (Minimum 3 years)
Step 2: Deployment & Services
- How many server units are required?
- Will you run virtual machine workloads? Do you need a VMware licence, or Windows Server with Hyper-V?
- How do you store data today? Do you have existing NAS or SAN storage?
- How do you back up today? Would you like a backup proposal, such as an IDPA 8TB appliance?
- Do you require burn-in test services?
- Do you need hard disk retention services?
Operating Systems, Management & Workloads
Operating Systems & Hypervisors
Microsoft Windows Server, VMware ESXi, Red Hat Enterprise Linux, SUSE Linux Enterprise Server and Ubuntu. Check HPE's OS support matrix for the exact versions certified on your chosen processor.
Management Tools
HPE iLO 6 provides out-of-band remote console, monitoring and alerting. HPE Compute Ops Management adds cloud-based firmware compliance, monitoring and lifecycle management across a fleet of ProLiant servers.
Typical Workloads
Virtualisation and containers at high VM density, VDI, high-performance computing, databases and analytics where two high-core-count processors must fit in 1U.
Package Contents & HPE ProLiant Gen11 Ordering Information
What Is Supplied
The DL365 Gen11 is built to order: chassis with the processor(s), memory, drives, storage controller, network adapters and power supplies specified on your quotation, plus rail kit, bezel and power cords where ordered.
HPE ProLiant Gen11
| Model | Key feature |
| ProLiant MicroServer Gen11 | Ultra-compact, 1-socket Intel Xeon E-2400 |
| ProLiant ML30 Gen11 | Tower, 1-socket Intel Xeon E-2400 |
| ProLiant ML110 Gen11 | Tower, 1-socket Intel Xeon Scalable |
| ProLiant ML350 Gen11 | Tower, 2-socket Intel Xeon Scalable |
| ProLiant DL20 Gen11 | 1U, 1-socket Intel Xeon E-2400 |
| ProLiant DL145 Gen11 | Edge, 1-socket AMD EPYC 8004 |
| ProLiant DL320 Gen11 | 1U, 1-socket Intel Xeon Scalable |
| ProLiant DL325 Gen11 | 1U, 1-socket AMD EPYC |
| ProLiant DL345 Gen11 | 2U, 1-socket AMD EPYC |
| ProLiant DL360 Gen11 | 1U, 2-socket Intel Xeon Scalable |
| ProLiant DL365 Gen11 (this listing) | 1U, 2-socket AMD EPYC |
| ProLiant DL380a Gen11 | 2U, 2-socket Intel Xeon, GPU-optimised |
| ProLiant DL385 Gen11 | 2U, 2-socket AMD EPYC |
Datasheet & Downloads
| HPE QuickSpecs | HPE ProLiant DL365 Gen11 QuickSpecs |
| HPE product brief | HPE ProLiant DL365 Gen11 Product Brief (PDF) |
| HPE product page | HPE ProLiant DL365 Gen11 on hpe.com |
Frequently Asked Questions — HPE ProLiant DL365 Gen11
Is this a fixed configuration?
No. The DL365 Gen11 is configure-to-order. Processors, memory, drive cage, RAID controller, network adapters, GPUs, power supplies and the HPE support term are specified to your workload; use the sizing checklist above to brief us.
How much memory can it take?
24 DDR5 RDIMM slots for up to 6 TB, at up to 6400 MT/s with 5th Gen AMD EPYC processors.
How many cores can it hold?
Up to 320 cores in total with two 160-core 5th Gen AMD EPYC 9005 series processors.
DL365 or DL385?
Choose the 1U DL365 Gen11 for compute density. Choose the 2U DL385 Gen11 when you need more drive bays, more PCIe slots or larger GPU configurations.
What warranty does it carry?
HPE's standard warranty is 3 years parts, 3 years labour and 3 years onsite next-business-day. Faster response and longer terms are available as HPE Care Pack upgrades.
