Epson EB-1795F Wireless Full HD 3LCD Projector
PRODUCT DESCRIPTION
Epson EB-1795F Wireless Full HD 3LCD Projector (V11H796052) - 3 Years Singapore Local Warranty
Full HD 1080p in a 1.83 kg, 44 mm Chassis
The EB-1795F puts a native Full HD 1080p panel into a body measuring 292 x 44 x 213 mm and weighing about 1.83 kg. For a Singapore consultant or sales engineer who presents detailed material on the move, that combination is unusual: full 1920 x 1080 detail without a case to check in. Fine print on a contract extract, a CAD elevation or a dense financial table stays legible instead of being resampled down to a lower panel resolution, and the 16:9 native aspect ratio matches video content and most modern presentation templates without letterboxing.
3,200 Lumens With Equal Colour and White Brightness
Epson rates the EB-1795F at 3,200 lumens white light output, with colour light output also quoted at 3,200 lumens in Normal mode and 1,900 lumens in Eco. The 3LCD engine produces colour brightness equal to white brightness, so corporate colours and chart series stay distinct under the ceiling lighting of an ordinary client meeting room. Contrast is rated at 10,000:1 through the auto iris. A room with blinds half drawn is normally enough; there is no need to black out a client's meeting room before starting a pitch.
Built-In Wireless, Miracast and NFC for Cable-Free Setup
Wireless LAN, Miracast and NFC are all included rather than optional. A presenter arriving at a client site can mirror from a laptop or compatible mobile device without carrying dongles or borrowing a cable from the host. Infrastructure mode lets the projector join a managed corporate network where IT requires it, while access point mode keeps a standalone room working when there is no network to join. For teams that present in other people's buildings every week, that removes the most common cause of a delayed start.
30 to 300 Inches With Wide Keystone Latitude
Image size runs from 30 to 300 inches, needing 0.67 to 6.86 m at the wide end of the zoom, with a 60-inch image at roughly 1.35 to 1.64 m. Vertical keystone correction of ±45 degrees and horizontal correction of ±30 degrees mean the projector does not have to sit squarely in front of the screen: it can go to one side of a meeting table, off-centre, or on a low credenza, and still produce a rectangular image. Start-up is about 7.2 seconds and Instant Off allows immediate packing down.
Epson EB-1795F Datasheet — Technical Specifications
General
| Product | Epson EB-1795F Wireless Full HD 3LCD Projector |
| Part Number (SKU) | V11H796052 |
| Projector Type | Ultra-mobile 3LCD lamp projector |
| Native Resolution | Full HD 1080p, 16:9 |
| Brightness | 3,200 lm white light output; 3,200 lm / 1,900 lm colour (Normal / Eco) |
| GTIN | 8715946620100 |
| Local Warranty (Singapore) | Supplied by SourceIT with GST invoice |
Projection & Optics
| Projection System | RGB liquid crystal shutter projection system (3LCD) |
| Contrast Ratio | 10,000:1 (auto iris) |
| Screen Size (projection distance) | 30” – 300” (0.67 – 6.86 m wide; 0.81 – 8.28 m tele) |
| Standard Size | 60” screen at 1.35 – 1.64 m |
| Keystone Correction | Vertical ±45°; horizontal ±30° |
Light Source
| Type | Lamp, 214 W UHE |
| Life (Normal / Eco) | 4,000 / 7,000 hours |
| Replacement Lamp | ELPLP94 |
| Start-Up Period | About 7.2 seconds (warm-up 30 seconds) |
| Cool Down Period | Instant Off |
Connectivity
| Digital Input | HDMI x 1 (MHL) |
| Analogue Input | D-Sub 15-pin x 1 (blue); Composite RCA x 1 |
| Audio Input | Stereo mini jack x 1 |
| USB | USB Type A x 1 (USB memory, document camera, firmware update); USB Type B x 1 (USB Display, mouse, keyboard, control, firmware update) |
| Network | Wireless LAN built in |
| Wireless LAN | IEEE 802.11b 11 Mbps, 802.11g 54 Mbps, 802.11n 130 Mbps; infrastructure and access point modes |
| Wireless Security | WPA2-PSK, WPA/WPA2-PSK, WPA2-EAP; PEAP, PEAP-TLS, EAP-TLS, EAP-Fast, LEAP |
| Miracast | IEEE 802.11g/n (2.4 GHz), 802.11a/n/ac (5 GHz), Wi-Fi Direct |
| NFC | Included |
Audio & Features
| Internal Speaker | 1 W |
| Direct Power On / Off | Yes / Yes |
Physical & Environmental
| Dimensions (excluding feet, W x H x D) | 292 x 44 x 213 mm |
| Weight | Approx. 1.83 kg |
| Fan Noise (Normal / Eco) | 39 dB / 30 dB |
| Operating Temperature | 5 °C – 40 °C to 2,286 m; 5 °C – 35 °C above 2,286 m; 20% – 80% humidity, no condensation |
| Operating Altitude | 0 – 3,000 m (high altitude mode above 1,500 m) |
Power
| Power Consumption (Normal / Eco) | 295 W / 208 W |
Specifications are taken from Epson's published product data for this model. Where Epson does not publish a figure for this exact model it has been left out rather than estimated.
Compatibility & Installation
Mounting and positioning
This is a table-top projector rather than an installation unit. At 44 mm high it sits in front of a laptop without blocking the presenter's view of the room. Vertical keystone correction of ±45 degrees and horizontal correction of ±30 degrees allow off-centre placement on a meeting table or a side credenza while keeping the image square. A 60-inch image needs about 1.35 to 1.64 m of throw.
What it connects to
One HDMI input with MHL support covers laptops, docks and compatible mobile adapters, while a D-Sub 15-pin input serves older notebooks and site equipment that still output VGA. A composite RCA input handles legacy video. USB Type B supports USB Display so a laptop can send image and control over a single USB cable, and USB Type A reads a memory stick or drives an Epson document camera with no computer connected at all.
Network and wireless presenting
Wireless LAN is built in and supports both infrastructure and access point modes. Enterprise security is covered through WPA2-EAP and WPA/WPA2-EAP with PEAP, PEAP-TLS, EAP-TLS, EAP-Fast and LEAP, so corporate IT can admit the projector to a managed SSID rather than requiring an open hotspot. Miracast runs on 2.4 GHz and 5 GHz including Wi-Fi Direct, and NFC is included for tap-to-pair with compatible devices.
Where it sits in the range
The EB-1795F and the EB-1785W share a chassis, a lamp and a 3,200-lumen rating. The EB-1795F has the Full HD 1080p panel at 16:9; the EB-1785W has a WXGA 1280 x 800 panel at 16:10. Pick on the aspect ratio and detail level your material needs.
Package Contents & Epson Ultra-Mobile Range
In the box
- Epson EB-1795F projector main unit
- 1.8 m computer cable
- 3 m USB A to USB B cable
- Remote control
- Soft carry case
- Manual
Package contents follow Epson's product data for this model; items not listed by Epson are not claimed here.
Epson Ultra-Mobile range
| Model | Resolution & light source |
| Epson EB-1785W | WXGA (1280 x 800), 3,200 lm, lamp |
| EB-1795F (this listing) | Full HD 1080p, 3,200 lm, lamp |
Datasheet & Downloads
Epson Singapore no longer lists a product page for this model. SourceIT can email the current data sheet revision, the user's guide and a formal quotation on request.
Frequently Asked Questions — Epson EB-1795F
Is the EB-1795F really Full HD?
Yes. The native panel resolution is Full HD 1080p with a 16:9 native aspect ratio, so 1080p sources are displayed without scaling.
How long does the lamp last and which lamp does it take?
Epson rates the 214 W UHE lamp at 4,000 hours in Normal mode and 7,000 hours in Eco mode. The replacement lamp model is the ELPLP94.
Does wireless presenting need an optional module?
No. Wireless LAN is built in on this model, and Miracast and NFC are included as standard.
How big an image will it produce in a normal meeting room?
Image size runs from 30 to 300 inches. A 60-inch image needs roughly 1.35 to 1.64 m of throw, which most meeting rooms allow from the end of the table.
Can it be placed off to one side of the table?
Yes, within limits. Vertical keystone correction of ±45 degrees and horizontal correction of ±30 degrees square the image up when the projector is not centred on the screen.
Is the internal speaker enough for video playback?
The internal speaker is rated at 1 W, which suits speech in a small room. For video or a larger audience, connect external speakers to the source device.
What is the difference between this and the EB-1785W?
The chassis, lamp and 3,200-lumen brightness are the same. The EB-1795F is Full HD 1080p at 16:9; the EB-1785W is WXGA 1280 x 800 at 16:10.
What warranty and invoicing applies?
This unit carries local Singapore warranty, and SourceIT issues a GST invoice with every unit sold.
