Eaton 9PX2200IRT2U-L Lithium 2200VA RT2U Models 230V

Eaton 9PX2200IRT2U-L Lithium 2200VA RT2U Models 230V - 5 Years Local Warranty

Eaton 9PX Lithium 2200VA RT2U – Unmatched Power Protection with Lithium Technology

The Eaton 9PX Lithium 2200VA RT2U provides superior power protection, making it an excellent choice for critical infrastructure in small to medium-sized businesses, data centers, and IT environments. Built with advanced lithium-ion battery technology, this UPS ensures longer battery life, quicker recharge times, and greater efficiency compared to traditional lead-acid models. With a 2200VA power rating, it is designed to protect vital equipment such as servers, networking gear, and telecommunications devices from unexpected power disturbances.

Lithium-ion Technology for Enhanced Efficiency and Longevity

The Eaton 9PX 2200VA UPS leverages state-of-the-art lithium-ion batteries, which offer a significantly longer operational lifespan compared to conventional lead-acid batteries. This results in fewer battery replacements and reduced maintenance costs over the long term. Lithium-ion technology also enables faster charging times, so the UPS is quickly ready to protect your devices after a power loss, ensuring minimal downtime for your operations.

Energy-Efficient Operation for Cost Savings

With up to 98% efficiency in double-conversion mode, the Eaton 9PX Lithium 2200VA RT2U ensures that your energy consumption is minimized, leading to lower electricity bills. Its energy-efficient performance not only reduces operational costs but also supports environmental sustainability by minimizing power waste. For businesses looking to optimize both cost and environmental impact, this UPS is an ideal solution.

Compact Design with Rack-Mountable Flexibility

The Eaton 9PX 2200VA RT2U is housed in a compact 2U rack-mountable form, allowing for easy integration into standard 19-inch racks. This design saves valuable space while still providing powerful protection for your essential equipment. Whether you're outfitting a data center or a server room, the Eaton 9PX delivers high performance without taking up unnecessary space, making it the perfect solution for environments with limited room.

Comprehensive Monitoring and Control Features

The Eaton 9PX Lithium 2200VA RT2U includes an intuitive LCD display, providing real-time feedback on UPS performance, including input and output voltages, battery charge status, load levels, and system diagnostics. Additionally, the UPS is compatible with Eaton's Intelligent Power Manager software, allowing for remote monitoring and management via a network connection. This ensures seamless integration into your IT infrastructure and allows for proactive management of your power protection system.

Technical Specifications

General
Model: 9PX Lithium 2200 RT2U
Part Number: 9103-LB73949
Product Name: Eaton 9PX Lithium 2200VA RT2U UPS 230V
Manufacturer: Eaton
Product Type: Online Double-Conversion UPS
UPS Topology: Online Double Conversion
Form Factor: Rack/Tower Convertible (RT2U)
Power Capacity: 2200VA / 2200W
Input Voltage: 230V
Output Voltage: 230V
Battery Technology: Lithium-Ion (LiFePO4)
Rack Height: 2U
Application: Servers, Storage, Networking, Edge Computing, Hyperconverged Infrastructure
Warranty: 5 Years Electronics & Battery Warranty

Power Specifications
Rated Power: 2200VA / 2200W
Power Factor: 1.0
UPS Topology: Online Double Conversion
Input Voltage Range: 176V – 276V AC (Typical)
Input Frequency Range: 40Hz – 70Hz
Output Voltage: 200V / 208V / 220V / 230V / 240V Configurable
Output Frequency: 50/60Hz Auto-Sensing
Voltage Regulation: ±1%
Waveform Type: Pure Sine Wave
Efficiency Online Mode: Up to 95%
Efficiency High-Efficiency Mode: Up to 98%

Battery Specifications
Battery Type: Lithium Iron Phosphate (LiFePO4)
Battery Design Life: Up to 8–10 Years
Recharge Time: Less Than 3 Hours to 90% Capacity
Battery Management System (BMS): Integrated
Hot-Swappable Batteries: Supported
Extended Battery Modules: Supported
Battery Monitoring: Advanced Battery Health Monitoring
Battery Replacement Frequency: Significantly Reduced Compared to VRLA UPS Systems

Runtime Features
Runtime Extension: Supported via External Battery Modules
Battery Runtime Optimization: Supported
Load Segment Control: Supported
Automatic Battery Testing: Supported
Predictive Battery Replacement Alerts: Supported
Battery Health Reporting: Supported

Output Connections
IEC C13 Outlets: 8
IEC C19 Outlets: 2
Load Segment Groups: 2
Programmable Outlets: Supported
Critical Load Prioritization: Supported
Surge Protection: Supported

Input Connections
Input Connector: IEC C20
Input Cord: Included
Input Protection: Integrated

Display & User Interface
Display Type: Graphical LCD Display
Display Orientation: Rotates Automatically for Rack or Tower Use
Real-Time Power Monitoring: Supported
Input/Output Measurements: Supported
Battery Status Monitoring: Supported
Load Monitoring: Supported
Event Logging: Supported
Alarm Notifications: Supported
Multi-Language Interface: Supported

Management & Communication
USB Port: Supported
Serial Port: Supported
Network Management Card Slot: 1
Gigabit Network Management: Optional
SNMP Support: Supported
Remote Shutdown: Supported
Remote Monitoring: Supported
Power Management Software: Eaton Intelligent Power Manager (IPM)
Virtualization Integration: Supported

Virtualization & IT Integration
VMware Compatibility: Supported
Microsoft Hyper-V Compatibility: Supported
Citrix Compatibility: Supported
Nutanix Compatibility: Supported
Red Hat Virtualization Support: Supported
Hyperconverged Infrastructure Support: Supported
Cloud-Based Monitoring: Supported

Protection Features
Online Double Conversion Protection
Power Surge Protection
Brownout Protection
Overvoltage Protection
Undervoltage Protection
Frequency Regulation
Short Circuit Protection
Overload Protection
Battery Deep Discharge Protection
Automatic Restart Function

Environmental Specifications
Operating Temperature: 0°C to 40°C
Storage Temperature: -15°C to 50°C
Relative Humidity: 0% to 95% Non-Condensing
Audible Noise: Less Than 40 dB Typical

Design & Construction
Color: Black
Rack Height: 2U
Form Factor: Rack/Tower Convertible
Chassis Construction: Enterprise-Grade Steel Enclosure
Cooling System: Intelligent Variable-Speed Fans
Front Service Access: Supported

Physical Specifications
Dimensions (H x W x D): Approximately 86.5 x 438 x 605 mm
Weight: Approximately 25–30 kg (Configuration Dependent)
Rack Mountable: Yes
Tower Installation: Yes

Software Support
Eaton Intelligent Power Manager (IPM): Supported
Eaton Intelligent Power Protector (IPP): Supported
VMware vCenter Integration: Supported
Microsoft SCVMM Integration: Supported
Remote Firmware Updates: Supported

Features
2200VA / 2200W True Online UPS
Lithium-Ion Battery Technology
Up to 10-Year Battery Life
1.0 Power Factor Output
Pure Sine Wave Output
Hot-Swappable Batteries
Rack/Tower Convertible Design
Graphical LCD Interface
High Efficiency Up to 98%
Network Management Ready
Extended Runtime Support
Advanced Battery Health Monitoring

Performance & Features
Provides continuous clean power through online double-conversion technology, ensuring connected equipment remains protected from power disturbances, voltage fluctuations, and outages. The lithium-ion battery design significantly reduces maintenance requirements while delivering longer service life and faster recharge times compared to traditional lead-acid UPS systems. Ideal for modern IT environments requiring high availability, lower total cost of ownership, and reliable backup power for critical infrastructure.

Package Contents
Eaton 9PX Lithium 2200VA RT2U UPS
Rack Mount Rail Kit
Tower Stand Kit
USB Communication Cable
Safety Documentation
Quick Start Guide
Power Management Software Download Information

Key Features
2200VA / 2200W Capacity
Online Double Conversion Topology
Lithium Iron Phosphate (LiFePO4) Battery
Up to 10-Year Battery Life
Pure Sine Wave Output
2U Rack/Tower Convertible Design
8 x IEC C13 Outputs
2 x IEC C19 Outputs
Hot-Swappable Battery Modules
Network Management Card Ready
VMware & Hyper-V Integration
Up to 98% Efficiency

Typical Use Cases
Enterprise Servers
Virtualization Hosts
Hyperconverged Infrastructure
Network Switches
Storage Arrays
Edge Data Centers
Telecommunications Equipment
Security Appliances
Healthcare IT Systems
Industrial Control Systems
Corporate Server Rooms
Mission-Critical Business Applications
