D-Link DAP-X3060 Nuclias Connect AX3000 Wi-Fi 6 Access Point
PRODUCT DESCRIPTION
D-Link DAP-X3060 Nuclias Connect AX3000 Wi-Fi 6 Dual-Band PoE Access Point (DAP-X3060) - 5 Years Local Warranty
AX3000 Wi-Fi 6 Performance
The D-Link DAP-X3060 is a dual-band IEEE 802.11ax (Wi-Fi 6) access point delivering up to 574 Mbps on 2.4 GHz and 2401 Mbps on 5 GHz, with 2x2 MIMO, band steering and airtime fairness.
2.5 Gigabit PoE Uplink
A single 10/100/1000/2500 Mbps Ethernet port with IEEE 802.3at PoE input carries both data and power, so the 5 GHz radio is not held back by a Gigabit link.
Flexible Management
Manage it with D-Link's free Nuclias Connect software, the DNH-1000 Nuclias Network Controller, D-View 8, or locally via web, with multiple operating modes and a customisable captive portal.
Secure and Certified
WPA/WPA2/WPA3 Personal and Enterprise, and certifications including CE, FCC and EN 60601-1-2.
Need help choosing? Email sales@sourceit.com.sg with your floor plan and user count and we will plan the Nuclias Connect AP mix for you.
D-Link DAP-X3060 Datasheet — Technical Specifications
General
| Product Name | D-Link DAP-X3060 Nuclias Connect AX3000 Access Point |
| Part Number | DAP-X3060 |
| Series | Nuclias Connect |
| Local Warranty (Singapore) | 5 years, supplied by SourceIT with a GST invoice |
Wireless
| Standards | IEEE 802.11a/b/g/n/ac/ax |
| Operating Frequency | 2.4 - 2.483 GHz; 5.15 - 5.35 GHz, 5.47 - 5.85 GHz |
| Data Rate | 2.4 GHz up to 574 Mbps; 5 GHz up to 2401 Mbps |
| Antennas | 4 internal antennas, 3 dBi (2.4 GHz and 5 GHz) |
| Max Output Power | 23 dBm (2.4 GHz); 22 dBm (5 GHz) |
Interfaces & Power
| Ethernet | 1 x 10/100/1000/2500 Mbps Ethernet (PoE) LAN |
| Console | 1 x RJ45 |
| Wired Standards | IEEE 802.3u/ab, IEEE 802.3az EEE, IEEE 802.3at PoE |
| Power Input | IEEE 802.3at PoE, or 12 V / 2.5 A (optional power adapter) |
| Max Power Consumption | 14.07 W (adapter); 16.7 W (PoE) |
Security & Management
| Encryption | WPA/WPA2/WPA3 Personal/Enterprise, WEP 64/128-bit |
| Management | Web (HTTP), SSL, D-Link Nuclias Connect, D-View 8 |
Physical & Environmental
| Dimensions | 190 x 190 x 42.8 mm |
| Weight | 612.4 g |
| Operating Temperature | 0 to 40 °C |
| Storage Temperature | -20 to 65 °C |
| Humidity | Operating 10% to 90%; storage 5% to 95% |
| MTBF | >30,000 hours |
| Certifications | CE, FCC, IC, RCM, LVD, EN 60601-1-2 |
Compatibility & Software Support
Management
Local web interface, D-Link's free Nuclias Connect software, D-View 8, or the DNH-1000 Nuclias Network Controller (D-Link names the DAP-X3060 among its supported devices).
Switching
Connect it to a 2.5GbE switch port with IEEE 802.3at PoE to use the full uplink speed; it also works on a Gigabit 802.3at port at lower wired throughput.
Typical Use
Busy offices, classrooms, clinics and meeting rooms that need more 5 GHz capacity than an AX1800 AP.
Package Contents & Nuclias Connect Ordering Information
Nuclias Connect Models
| Part No. | Description |
| DNH-100 | Nuclias Connect Hub, up to 100 APs/switches |
| DNH-1000 | Nuclias Network Controller, up to 500 devices |
| DNH-3000 | Nuclias Network Controller, up to 1500 devices |
| DAP-2662 | AC1200 Wave 2 AP, 802.3af PoE |
| DAP-2610 | AC1300 Wave 2 AP, 802.3af PoE |
| DAP-X2810 | AX1800 Wi-Fi 6 AP, 1 x GE PoE |
| DAP-X3060 (this listing) | AX3000 Wi-Fi 6 AP, 1 x 2.5GE PoE |
| DAP-X2850 | AX3600 Wi-Fi 6 AP, 2.5GE PoE + GE |
| DAP-X3060OU | AX3000 Wi-Fi 6 outdoor AP, IP68, 2.5GE PoE |
| DAP-E9560 | BE9500 Wi-Fi 7 tri-band AP, 10GE PoE + 2.5GE |
The 12 V power adapter is optional. Package contents are not otherwise listed in D-Link's datasheet — ask us to confirm the mounting kit.
Datasheet & Downloads
| D-Link datasheet | DAP-X3060 Datasheet v1.03 (PDF) |
| D-Link product page | DAP-X3060 on dlink.com |
| D-Link Singapore product page | DAP-X3060 on dlink.com.sg |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting DAP-X3060.
Frequently Asked Questions — D-Link DAP-X3060
What PoE does it need?
IEEE 802.3at (PoE+); maximum consumption is 16.7 W on PoE.
Does it support WPA3?
Yes, WPA3 Personal and Enterprise alongside WPA/WPA2.
Is there an outdoor version?
Yes, the IP68-rated DAP-X3060OU uses the same AX3000 platform for outdoor use.
Do I need a paid controller?
No. Nuclias Connect software is free; hardware controllers are optional.
What warranty do I get?
5 years local warranty in Singapore, supplied by SourceIT with a GST invoice.
