D-Link DGS-1100-08PV2 8-Port Gigabit PoE Smart Managed Switch
PRODUCT DESCRIPTION
D-Link DGS-1100-08PV2 8-Port Gigabit PoE Smart Managed Switch (DGS-1100-08PV2) - 5 Years Local Warranty
8 PoE Ports in a Compact, Fanless Switch
The D-Link DGS-1100-08PV2 is the 8-port PoE member of D-Link's DGS-1100 V2 Gigabit Smart Managed series. All eight 10/100/1000BASE-T ports deliver IEEE 802.3af/at PoE from a 64 W budget, for IP cameras, access points and VoIP phones.
Silent Desktop Operation
A fanless design (0 dB(A)) and a 171 x 97.8 x 28.6 mm chassis make it easy to place in offices, shops and meeting rooms.
Smart Features for Surveillance and Voice
802.1Q VLANs, Surveillance VLAN and IGMP Snooping keep camera and multicast traffic in check, with static trunking of up to 2 groups for extra uplink bandwidth.
Simple Web Management
Configured through a web-based GUI (IPv4), with D-Link Green energy-saving features.
Need help choosing? Email sales@sourceit.com.sg with your port count and PoE devices and we will size it for you.
D-Link DGS-1100-08PV2 Datasheet — Technical Specifications
General
| Product Name | D-Link DGS-1100-08PV2 8-Port Gigabit PoE Smart Managed Switch |
| Part Number | DGS-1100-08PV2 |
| Series | DGS-1100 V2 Gigabit Smart Managed Switches |
| Local Warranty (Singapore) | 5 years, supplied by SourceIT with a GST invoice |
Interfaces
| Gigabit PoE Ports | 8 x 10/100/1000BASE-T |
PoE
| PoE Standard | IEEE 802.3af / 802.3at |
| PoE Budget | 64 W |
Performance
| Switching Capacity | 16 Gbps |
| Maximum Forwarding Rate | 11.9 Mpps |
| MAC Address Table | 4K entries |
| Packet Buffer | 1.5 Mbits |
| Jumbo Frames | Up to 9216 bytes |
Physical & Environmental
| Dimensions | 171 x 97.8 x 28.6 mm |
| Weight | 0.43 kg |
| Cooling | Fanless (0 dB(A)) |
| Power Consumption | Standby 2.0 W; max 77.9 W (PoE on) / 4.6 W (PoE off) |
| Operating Temperature | 0 to 40 °C |
| MTBF | 786,841 hours |
Certifications
| EMI | FCC Class B, CE Class B, VCCI Class B, BSMI |
| Safety | cUL, CE LVD, CB, BSMI |
Compatibility & Software Support
Management
Web-based GUI (IPv4). Layer 2 features include port-based and 802.1Q VLAN, Surveillance VLAN, IGMP Snooping and static trunking (2 groups).
Typical Use
Small offices, retail and surveillance deployments powering up to 8 PoE devices from a quiet desktop switch.
Package Contents & DGS-1100 V2 PoE Ordering Information
DGS-1100 V2 PoE Models
| Model | Ports | PoE Budget | Part No. |
| DGS-1100-08PV2 (this listing) | 8 x GE PoE | 64 W | DGS-1100-08PV2 |
| DGS-1100-10MPV2 | 8 x GE PoE + 2 x SFP | 130 W | DGS-1100-10MPV2 |
| DGS-1100-18PV2 | 16 x GE PoE + 2 x Combo GE/SFP | 130 W | DGS-1100-18PV2 |
| DGS-1100-24PV2 | 12 x GE PoE + 12 x GE | 100 W | DGS-1100-24PV2 |
| DGS-1100-26MPV2 | 24 x GE PoE + 2 x Combo GE/SFP | 370 W | DGS-1100-26MPV2 |
Package contents are not listed in D-Link's datasheet — ask us if you need confirmation of the included power adapter.
Datasheet & Downloads
| D-Link datasheet | DGS-1100 V2 Series Datasheet (PDF) |
| D-Link series page | DGS-1100 V2 Series on dlink.com |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting DGS-1100-08PV2.
Frequently Asked Questions — D-Link DGS-1100-08PV2
How much PoE power does it provide?
64 W in total across all 8 ports, using IEEE 802.3af and 802.3at (PoE+).
Is it fanless?
Yes. D-Link lists a fanless design with 0 dB(A) acoustic output.
Does it support IPv6 management?
No. D-Link lists IPv4 web management for the 8-port models; IPv6 management is on the 16-port and larger DGS-1100 V2 models.
Does it have an SFP port?
No. For fibre uplinks see the DGS-1100-10MPV2 (2 x SFP).
What warranty do I get?
5 years local warranty in Singapore, supplied by SourceIT with a GST invoice.
