D-Link DWM-313 4G LTE Industrial M2M Wi-Fi VPN Router
PRODUCT DESCRIPTION
D-Link DWM-313 4G LTE Industrial M2M Wi-Fi VPN Router (DWM-313) - 3 Years Local Warranty
Compact 4G Router for Remote Sites
The D-Link DWM-313 pairs a 4G LTE Cat.4 module (up to 150 Mbps down / 50 Mbps up) with a Fast Ethernet WAN/LAN port, a Fast Ethernet LAN port and 2.4 GHz Wi-Fi N150, bringing kiosks, signage and small cabinets online over cellular.
Dual-SIM and Ethernet Failover
Two Micro-SIM slots provide carrier failover, and the WAN/LAN port can be used as a wired uplink with 4G as backup.
Industrial-Grade Design
A metal case, -30 to 70 °C operating range and included DIN-rail kit suit roadside, utility and factory enclosures.
VPN Security and Central Management
IPSec, OpenVPN, PPTP, L2TP and GRE tunnels, an SPI firewall with IPS, SNMP and D-Link D-ECS management plus SMS event alerts keep remote fleets secure and visible.
Need help choosing? Email sales@sourceit.com.sg with your site, carriers and bandwidth needs and we will recommend the right M2M router.
D-Link DWM-313 Datasheet — Technical Specifications
General
| Product Name | D-Link DWM-313 4G M2M Router |
| Part Number | DWM-313 |
| Series | D-Link 5G/4G LTE Industrial M2M Routers |
| Local Warranty (Singapore) | 3 years, supplied by SourceIT with a GST invoice |
Cellular
| Cellular Module | 4G LTE Cat.4 |
| LTE Throughput | 150 Mbps (DL) / 50 Mbps (UL) |
| LTE Bands (EU SKU, HW C1) | FDD B1/B3/B7/B8/B20/B28A; TDD B38/B40/B41 |
| LTE Bands (US SKU, HW C2) | B2/B4/B5/B12/B13/B14/B66 |
| LTE Bands (TW SKU, HW C3) | FDD B1/B2/B3/B4/B5/B7/B8/B28; TDD B40 |
| SIM Slots | 2 x SIM (Micro SIM) |
Interfaces & Wi-Fi
| Ethernet | 1 x WAN/LAN FE, 1 x LAN FE |
| Wi-Fi | IEEE 802.11 n/b/g, 2.4 GHz, 150 Mbps, AP router mode |
| Antenna Connectors | 2 x SMA(F) cellular, 1 x SMA(RP-F) Wi-Fi |
| Power Input | DC 5V (DC jack) |
Network, Security & Administration
| VPN | IPSec, OpenVPN, PPTP, L2TP, GRE |
| Firewall | SPI firewall with stealth mode, IPS, Block WAN Ping |
| Access Control | Packet filter, URL blocking, MAC control |
| Routing | Static, dynamic RIPv1/v2, OSPF |
| Configuration | Web UI, CLI, command script |
| Management | SNMPv1/2/3, D-Link D-ECS |
| Cellular Toolkit | Data usage, SMS, SIM PIN, network scan; event management and notifying events |
Physical & Environmental
| Dimensions | 93 x 90 x 27 mm |
| Housing & Mounting | Metal casing; DIN-rail kit included |
| Operating Temperature | -30 to 70 °C |
| Storage Temperature | -40 to 85 °C |
| Humidity | Operating 10% to 95%; storage 0% to 95% (non-condensing) |
| Certifications | CE, UKCA |
Compatibility & Software Support
Management
Web UI, CLI and command script locally; SNMPv1/2/3 and D-Link D-ECS for central management; SMS event notifications.
Typical Use
Cellular or backup uplink for store and shop systems, remote branches, kiosks, vending and small unmanned sites.
Package Contents & M2M Router Ordering Information
Package Contents
2 x cellular SMA antennas, 1 x Wi-Fi RP-SMA antenna, 1 x RJ-45 cable, 1 x power adapter, 1 x DIN-rail kit.
D-Link M2M Router Models
| Model | Cellular | Ports / Wi-Fi | Part No. |
| DWM-313 (this listing) | 4G LTE Cat.4, 2 SIM | 1 x WAN/LAN FE + 1 x LAN FE / N150 | DWM-313 |
| DWM-530-T | 4G LTE Cat.4, 2 SIM | 1 x WAN/LAN FE + 3 x LAN FE / N300 | DWM-530-T |
| DWM-550-G | 5G NR / 4G LTE, 2 SIM | 1 x WAN/LAN GE + 3 x LAN GE / Wi-Fi 6 AX1800 | DWM-550-G |
Datasheet & Downloads
| D-Link datasheet | DWM-313 Datasheet (PDF) |
| D-Link product page | DWM-313 on dlink.com |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting DWM-313.
Frequently Asked Questions — D-Link DWM-313
Does it support dual-SIM failover?
Yes, two Micro-SIM slots provide carrier failover.
What Wi-Fi does it have?
2.4 GHz Wi-Fi 802.11 n/b/g at up to 150 Mbps in AP router mode.
Can I use a wired line as the main uplink?
Yes. The WAN/LAN port can act as Ethernet WAN with 4G as failover.
How is it powered?
DC 5V via the DC jack; a power adapter is included.
What warranty do I get?
3 years local warranty in Singapore, supplied by SourceIT with a GST invoice.
