ASUS ZenScreen MB166CR 16" Portable USB Monitor

16” Portable USB Monitor for Mobile Productivity

The ASUS ZenScreen MB166CR 16" Portable USB Monitor (ASU-MB166CR / 90LM07D3-B03110) is designed for professionals who need a lightweight and efficient second screen. Featuring a 15.6-inch Full HD (1920 x 1080) IPS panel, it delivers clear visuals with wide 178° viewing angles, making it ideal for remote work, presentations, and multitasking on the go.

Single USB-C Connection for Simple Setup

With USB-C (DisplayPort Alt Mode) connectivity, the MB166CR supports both power and video transmission through a single cable, reducing cable clutter and enabling quick plug-and-play deployment. This makes it highly suitable for mobile professionals and flexible work environments.

Slim, Lightweight and Travel-Friendly Design

Built for portability, the monitor features an ultra-slim profile of approximately 11.8mm and weighs around 0.78kg, making it easy to carry alongside laptops. Its compact design allows seamless integration into mobile work setups, whether in the office, home, or while travelling.

Flexible Viewing with Kickstand and Auto Rotation

The ZenScreen MB166CR includes a 360° kickstand and tripod socket, providing flexible positioning for both landscape and portrait orientations. It also supports auto-rotation via ASUS DisplayWidget software, allowing seamless switching based on your workflow needs.

Eye Care Technology for Comfortable Viewing

ASUS Eye Care technologies such as Flicker-Free and Low Blue Light help reduce eye strain during extended usage. Combined with an anti-glare IPS panel, the monitor ensures comfortable viewing across different lighting conditions and long working hours.

Technical Specification

• Display Size: 15.6-inch (16" class)
• Resolution: Full HD 1920 × 1080 (16:9 aspect ratio)
• Panel Type: IPS panel with LED backlight
• Viewing Angle: 178° (H) / 178° (V)
• Brightness: 250 nits (typical)
• Contrast Ratio: 800:1 (typical)
• Response Time: 5ms (GTG)
• Refresh Rate: 60Hz
• Pixel Pitch: 0.179 mm
• Display Colours: 262K colours
• Surface Treatment: Anti-glare

Performance & Features

• ASUS SPLENDID display modes
• ASUS GamePlus tools (crosshair, timer, FPS counter)
• QuickFit virtual grid overlay
• Trace Free technology for smoother visuals
• HDCP support
• DisplayWidget Center for auto rotation
• Flicker-Free and Low Blue Light for eye comfort

Audio

• No built-in speakers

Connectivity

• USB-C ×1 (DisplayPort Alt Mode)
• Single-cable solution for power and display
• Plug-and-play compatibility

Mechanical & Design

• Ultra-slim profile (~11.8 mm)
• Lightweight design (~0.78 kg)
• 360° adjustable kickstand for flexible positioning
• Supports landscape and portrait orientation
• 1/4" tripod socket for mounting flexibility
• Dimensions: approx. 360 × 225 × 11.8 mm

Power

• Power Consumption: ~5.24W
• Power Saving Mode: <0.5W
• Power Off Mode: <0.3W
• Voltage: 100–240V, 50/60Hz

Use Case / Deployment

• Mobile professionals and business travellers
• Secondary display for laptops
• On-the-go presentations and meetings
• Hybrid and remote work setups
• Portable dual-screen productivity

Key Advantages

• Single USB-C cable for both power and display
• Lightweight and ultra-portable design
• IPS panel with wide viewing angles
• Eye Care features for extended usage
• Flexible setup with 360° kickstand and tripod support

Detailed Specification

ASUS ZenScreen MB166CR Portable USB Monitor - 16", Full HD, IPS, USB Type-C, 360 Degrees kickstand
