ViewSonic VP2786-4K 27" 4K ColorPro Monitor with Integrated Calibrator & ColorPro Wheel
PRODUCT DESCRIPTION
ViewSonic VP2786-4K 27" UHD Fogra & G7 Validated Photo Editing Monitor with Integrated Calibrator - 3 Years Local Warranty
Ultimate Precision
100% Adobe RGB and 98% DCI-P3 with true 10-bit colour for professional photo and design work.
Screen-to-Print Match
Fogra and Idealliance (G7) certified so on-screen colour matches your final printout.
ColorPro Wheel
Included dial for fingertip control of Adobe apps, OSD settings and calibration.
Integrated Calibrator
Built-in X-Rite calibrator with Colorbration+ software keeps colour consistent over time.
Need monitors for a whole office, studio or classroom? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
ViewSonic VP2786-4K Datasheet — Technical Specifications
General
| Product Name | ViewSonic VP2786-4K 27" UHD Fogra & G7 Validated Photo Editing Monitor with Integrated Calibrator |
| Model | VP2786-4K |
| Local Warranty (Singapore) | 3 years on-site limited warranty on parts and labour |
Display
| Screen Size | 27" |
| Panel Type | IPS |
| Resolution | 3840 x 2160 (4K UHD) |
| Refresh Rate | 60 Hz |
| Response Time | 5 ms (GTG) |
| Brightness | 350 cd/m² (typ) |
| Contrast Ratio | 1,300:1 static (typ); 20M:1 dynamic |
| HDR | HDR10 |
| Colours | 1.07B, true 10-bit |
| Colour Gamut | Adobe RGB 100%; DCI-P3 98%; sRGB 100%; Rec.709 100% coverage (typ) |
| Viewing Angles | 178° H / 178° V |
| Pixel Size | 0.155 x 0.155 mm |
| Surface | Anti-glare, 3H hard coating |
| Flicker-Free / Low Blue Light | Yes / software solution |
| Backlight Life | 30,000 hours (min) |
Connectivity
| USB-C | 1 x USB 3.2 Type-C upstream (DisplayPort Alt Mode, 90 W power charger) |
| HDMI | 2 x HDMI 2.1 |
| DisplayPort | 1 x DisplayPort 1.4 |
| USB Hub | 4 x USB 3.2 Type-A downstream, 1 x USB 3.2 Type-B upstream |
| Micro USB | 1 |
| Audio Out | 1 x 3.5 mm |
| Speakers | 2 x 3 W |
| Controls | Joystick; ColorPro Wheel included |
| Kensington Lock Slot | 1 |
Power
| Voltage | AC 100–240 V |
| Consumption | 67 W typical; 70 W max; 0.5 W standby |
| Eco Mode | 45 W (conserve) / 55 W (optimised) |
| Power Supply | Internal |
Operating Conditions
| Temperature | 0–40 °C |
| Humidity (non-condensing) | 20%–90% |
Physical & Ergonomics
| Dimensions with Stand (W x H x D) | 613 x 449.11–569.11 x 232 mm |
| Dimensions without Stand | 613 x 358 x 55 mm |
| Net Weight | 8.3 kg (4.9 kg without stand) |
| Packaging (W x H x D) | 692 x 505 x 225 mm |
| Gross Weight | 13.2 kg |
| Height Adjustment | 120 mm |
| Swivel | 120° |
| Tilt | -3° / 21° |
| Pivot | 90° / 90° |
| VESA | 100 x 100 mm |
Compatibility & Software Support
Devices
Windows 10/11 certified and macOS tested. USB-C laptops with DisplayPort Alt Mode get 4K video, data and up to 90 W charging on one cable; desktops connect by DisplayPort 1.4 or HDMI 2.1.
Software
Colorbration+ drives the integrated X-Rite calibrator; the ColorPro Wheel works with Adobe applications and the on-screen menu.
Package Contents & ViewSonic ColorPro VP Series Ordering Information
In the Box
VP2786-4K monitor, power cable (IEC C13), HDMI cable (v2.0), USB A/B cable (v3.2), USB-C cable, monitor hood, ColorPro Wheel, quick start guide.
ViewSonic ColorPro VP Series Monitors
| Model | Key feature |
| VP2456 | 24" FHD IPS, Pantone Validated, USB-C 60 W |
| VP2756-2K | 27" QHD IPS, Pantone Validated, USB-C 60 W |
| VP2756-4K | 27" 4K UHD IPS, Pantone Validated, USB-C 60 W |
| VP2766-2K-W | 27" QHD IPS 120 Hz, white, USB-C 90 W |
| VP2786-4K (this listing) | 27" 4K IPS, 100% Adobe RGB, built-in calibrator, ColorPro Wheel |
| VP2788-5K | 27" 5K ColorPro, Thunderbolt |
| VP3256-4K | 32" 4K UHD ColorPro |
| VP3481A | 34" WQHD+ curved ColorPro |
Datasheet & Downloads
| ViewSonic datasheet | VP2786-4K Datasheet |
| User guide | VP2786-4K User Guide (PDF, English) |
| Quick start guide | VP2786-4K Quick Start Guide (PDF) |
| ViewSonic product page | VP2786-4K on viewsonic.com |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting VP2786-4K.
Frequently Asked Questions — ViewSonic VP2786-4K
Do I need a separate calibrator?
No, an X-Rite calibrator is built in and driven by ViewSonic Colorbration+ software.
Is a monitor hood included?
Yes, the shading hood and the ColorPro Wheel are in the box.
Will it charge my laptop?
Yes, up to 90 W over USB-C if your laptop supports USB-C charging and DisplayPort Alt Mode.
What warranty do I get?
3 years on-site limited warranty on parts and labour in Singapore. Supplied by SourceIT with a GST invoice.
