ViewSonic VG2409-MHU 24" Full HD IPS USB-C Monitor with Speakers
PRODUCT DESCRIPTION
ViewSonic VG2409-MHU 24" Full HD USB-C Monitor with Dual Speakers - 3 Years Local Warranty
One Cable for Video, Audio and Power
The ViewSonic VG2409-MHU connects a laptop over USB-C (DisplayPort Alt Mode) and delivers up to 65 W charging on the same cable, for a clean, single-cable desk.
Full HD IPS with Wide Viewing Angles
A 23.6" viewable SuperClear® IPS panel at 1920 x 1080 with 178° viewing angles and sRGB 104% (typ) colour.
Fully Ergonomic Stand
130 mm height adjustment, 360° swivel, -3.5°/28° tilt and 90° pivot let every user set a comfortable position, with cable management built in.
Speakers, Eye Care and Flexibility
Dual 2 W speakers, HDMI and VGA inputs, 75 Hz variable refresh rate, flicker-free backlight and blue light filter.
Need monitors for a whole office, classroom or call centre? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
ViewSonic VG2409-MHU Datasheet — Technical Specifications
General
| Product Name | ViewSonic VG2409-MHU 24" Full HD USB-C Monitor with Dual Speakers |
| Model | VG2409-MHU |
| Local Warranty (Singapore) | 3 years on-site limited warranty on parts and labour |
Display
| Screen Size | 24" (23.6" viewable) |
| Panel Type | IPS |
| Resolution | 1920 x 1080 (Full HD) |
| Refresh Rate | 75 Hz, variable refresh rate |
| Response Time | 5 ms (GTG) |
| Brightness | 250 cd/m² (typ) |
| Contrast Ratio | 1,000:1 static (typ); 50M:1 dynamic |
| Colours | 16.7M, 8-bit (6-bit + FRC) |
| Colour Gamut | NTSC 72%, sRGB 104% (typ) |
| Viewing Angles | 178° H / 178° V |
| Pixel Size | 0.272 x 0.272 mm |
| Surface | Anti-glare, 3H hard coating |
| Flicker-Free / Low Blue Light | Yes / software solution |
| Backlight Life | 30,000 hours (min) |
Connectivity
| USB-C | 1 x USB 3.2 Type-C (DisplayPort Alt Mode, 65 W power charger) |
| HDMI | 1 x HDMI 1.4 |
| VGA | 1 |
| Audio Out | 1 x 3.5 mm |
| Speakers | 2 x 2 W |
| Power In | DC socket (centre positive) |
| Kensington Lock Slot | 1 |
Power
| Voltage | AC 100–240 V |
| Consumption | 18 W typical; 19 W max; 0.5 W standby |
| Eco Mode | 10 W (conserve) / 12 W (optimised) |
| Power Supply | External power adaptor |
Operating Conditions
| Temperature | 0–40 °C |
| Humidity (non-condensing) | 20%–90% |
Physical & Ergonomics
| Dimensions with Stand (W x H x D) | 534 x 381.8–511.8 x 233 mm |
| Dimensions without Stand | 534 x 321 x 54 mm |
| Net Weight | 4.7 kg (2.7 kg without stand) |
| Packaging (W x H x D) | 622 x 520 x 144 mm |
| Gross Weight | 6.7 kg |
| Height Adjustment | 130 mm |
| Swivel | 360° |
| Tilt | -3.5° / 28° |
| Pivot | 90° / 90° |
| VESA | 100 x 100 mm |
Compatibility & Software Support
Devices
Works with Windows 10/11 (certified) and macOS (tested) desktops and laptops. USB-C laptops with DisplayPort Alt Mode get video, audio and up to 65 W charging on one cable; other PCs connect by HDMI or VGA.
Typical Use
Laptop-based offices and hot desks, call centres, schools and home offices that want a height-adjustable screen and one-cable laptop charging.
Package Contents & ViewSonic VG Series Ordering Information
In the Box
VG2409-MHU monitor, power cable (IEC C5), HDMI cable (v1.4), USB-C cable, AC/DC adapter, quick start guide.
ViewSonic VG Series Monitors
| Model | Key feature |
| VG1655 | 16" FHD IPS portable, dual USB-C |
| VG2409-MHU (this listing) | 24" FHD IPS, USB-C 65 W, speakers, ergonomic stand |
| VG2409U-2 | 24" FHD USB-C docking |
| VG2439 | 24" FHD ergonomic |
| VG2440V | 24" FHD IPS video conferencing |
| VG2441V | 24" FHD video conferencing |
| VG2448-I | 24" FHD IPS ergonomic |
| VG2709U-2K | 27" QHD USB-C docking |
| VG2740V | 27" FHD video conferencing |
| VG2756-2K | 27" QHD docking |
| VG2757V-2K | 27" QHD webcam docking |
| VG3419C-2 | 34" WQHD curved USB-C docking |
| VG3456 | 34" WQHD docking |
Datasheet & Downloads
| ViewSonic datasheet | VG2409-MHU Datasheet |
| User guide | VG2409-MHU User Guide (PDF, English) |
| Quick start guide | VG2409-MHU Quick Start Guide (PDF) |
| ViewSonic product page | VG2409-MHU on viewsonic.com |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting VG2409-MHU.
Frequently Asked Questions — ViewSonic VG2409-MHU
Will it charge my laptop?
Yes, up to 65 W over USB-C, if your laptop supports USB-C charging and DisplayPort Alt Mode.
Can it rotate to portrait?
Yes, the stand pivots 90° either way and also adjusts height (130 mm), swivel and tilt.
Does it have speakers?
Yes, 2 x 2 W, plus a 3.5 mm audio out.
What warranty do I get?
3 years on-site limited warranty on parts and labour in Singapore. Supplied by SourceIT with a GST invoice.
