Samsung WA86FX-P 86" 4K Android Interactive Display with Built-in Camera
PRODUCT DESCRIPTION
Samsung WA86FX-P 86" Android Interactive Display with Built-in Camera (LH86WAFPLGCXXS) - Local Warranty
The Whole Video-Call Kit Is Built Into the Panel
The Samsung WA86FX-P builds an entire room video-conferencing system into the display. A 48 MP camera, a far-field microphone array that picks up voices from as far as 10 metres, and dual 20 W speakers with a built-in woofer mean there is no separate camera bar, no ceiling microphone, no soundbar and no rack of cabling to commission. In a large boardroom or lecture theatre that saves an entire AV install, along with its commissioning time and its ongoing maintenance. Start the call on the screen and the room is already live.
Auto Framing, Live Caption and AI Write and Search
Auto Framing keeps the group centred in the shot and re-frames as people join or leave, so remote colleagues see a composed room rather than an empty half of it. Live Caption transcribes what is said on screen, which helps in a noisy room, in a mixed-language meeting, and for anyone who prefers to read along. AI Write and Search tidies handwritten notes and pulls up related material straight from the board. The WAFX-P series took Best of Show and a TNT Award at ISE 2026.
50-Point Touch, Split Note Mode and a Dual-Sided Pen
Infrared touch tracking follows up to 50 simultaneous touch points, so a large class or project team can work on the board together without the panel losing anyone. The bundled dual-sided, dual-colour pen switches ink by flipping it over. Split Note Mode carves the 86-inch canvas into four independent note zones so four people or four teams can work in parallel, and Annotation On lets anyone mark up whatever is on screen without leaving the source application.
EDLA-Certified Android 15 with Wi-Fi 6 and 3-in-1 USB-C
Android 15 on an octa-core processor with 128 GB of storage runs the room, and EDLA certification means licensed Google Play, YouTube and Google Classroom are installed and properly supported. Up to nine devices mirror wirelessly across iOS, macOS, Windows and Android, while the 3-in-1 USB-C port carries video, touch-back and 65 W of charging on a single lead. Wi-Fi 6, two HDMI 2.1 inputs, HDMI Out, DisplayPort 1.2, RJ45, RS232 and an OPS slot complete the connection set.
Samsung WA86FX-P Datasheet — Technical Specifications
General
| Product | Samsung WA86FX-P 86" Android Interactive Display with Built-in Camera |
| Part Number (SKU) | LH86WAFPLGCXXS |
| Display Type | Interactive display with built-in camera (WAFX-P series) |
| Platform | Android 15, EDLA-certified |
| Processor | Octa-Core |
| Licensed Google Services | Google Play, YouTube, Google Classroom |
| Internal Storage | 128 GB |
| AI Features | AI Write and Search, Live Caption |
| Awards | Best of Show and TNT Award, ISE 2026 |
| Expansion | OPS slot |
| Local Warranty (Singapore) | Supplied by SourceIT with GST invoice |
Camera & Audio
| Camera | Built-in 48 MP |
| Camera Framing | Auto Framing |
| Microphone | Far-field microphone array, 10 m pickup |
| Speakers | Dual 20 W with built-in woofer |
| Captions | Live Caption |
Display
| Screen Size | 86" |
| Resolution | 3840 x 2160 (UHD 4K) |
| Brightness | 450 nit |
| Panel Type | IPS |
| Contrast Ratio | 1200:1 |
| Viewing Angle | 178° / 178° |
Touch & Writing
| Touch Technology | Infrared (IR) |
| Touch Points | Up to 50 simultaneous |
| Pen | Dual-sided, dual-colour |
| Note Taking | Split Note Mode with 4 independent note zones |
| Annotation | Annotation On over any source |
| Multitasking | Multi-window |
Smart Platform & Management
| Operating System | Android 15 |
| Certification | EDLA (Enterprise Devices Licensing Agreement) |
| App Store | Licensed Google Play |
| Education Tools | Google Classroom, YouTube |
| Wireless Mirroring | Up to 9 devices (iOS, macOS, Windows, Android) |
Connectivity
| HDMI In | 2 x HDMI 2.1 |
| HDMI Out | 1 |
| DisplayPort | DisplayPort 1.2 |
| USB-C | 3-in-1 USB-C with 65 W power delivery |
| LAN | RJ45 |
| Wi-Fi | Wi-Fi 6 |
| Serial | RS232 |
| Expansion Slot | OPS |
Physical & Environmental
| Dimensions | 1950.4 x 1174.0 x 87.1 mm |
| Weight | 60.9 kg |
| Colour | Black |
Power
| Maximum Power Consumption | 529 W |
Specifications are taken from Samsung's published product data for this model. Where Samsung does not publish a figure for this exact model it has been left out rather than estimated.
Compatibility & Installation
Mounting and orientation
The WA86FX-P is a landscape front-of-room display for large hybrid boardrooms and lecture theatres. At 1950.4 x 1174.0 x 87.1 mm and 60.9 kg it needs a structurally sound wall or a heavy-duty trolley and a multi-person lift, so involve your installer at design stage. Because the camera is built in, mounting height sets the camera angle as well as the writing height, so position it for a natural eye line on the far end of the call. Confirm the VESA pattern and load rating against the Samsung installation guide for this exact part number.
What it connects to
The 3-in-1 USB-C port carries video, touch-back and 65 W of charging on one lead, so a laptop presents and charges together. Two HDMI 2.1 inputs and DisplayPort 1.2 take a room PC, a visualiser or a second source, and HDMI Out feeds an overflow display at the rear of a lecture theatre. RJ45 gives a wired drop, RS232 supports a room control system, and Wi-Fi 6 covers spaces with no cabling. The OPS slot takes an OPS PC where Windows is the room standard. No external camera, microphone or speaker is needed.
Network and content management
EDLA-certified Android 15 means the WA86FX-P enrols with licensed Google services rather than side-loaded apps, so staff sign in with existing Google Workspace accounts and IT manages it alongside other Google-licensed devices. Put it on a managed VLAN over RJ45 where update and access control matter. Allow 529 W maximum draw per panel when sizing the circuit, and ask your SourceIT account manager which Samsung management tooling is licensed for this model before planning a campus-wide rollout.
Accessories
The dual-sided, dual-colour pen is supplied with the display. No separate camera bar, microphone or soundbar is required, because all three are built in. The Samsung Flip connectivity tray CY-TF65BFCXXS is a Flip accessory and is not an accessory for this WAFX-P model.
Package Contents & Samsung WAF Range
In the box
- Samsung WA86FX-P 86" Android interactive display with built-in camera
- Dual-sided, dual-colour pen
Package contents follow Samsung's product data for this model; items not listed by Samsung are not claimed here.
Samsung WAF range
| Model | Size |
| WA65D | 65" |
| WA75D | 75" |
| WA86D | 86" |
| WA65F | 65" |
| WA75F | 75" |
| WA86F | 86" |
| WA65FX-P (with camera) | 65" |
| WA75FX-P (with camera) | 75" |
| WA86FX-P (this listing, with camera) | 86" |
Datasheet & Downloads
Samsung has not published a public Singapore data sheet page for the WA86FX-P (LH86WAFPLGCXXS) that we can link to here, so no download link is given rather than pointing you at the wrong revision. SourceIT can email the current data sheet revision for this exact part number on request, together with a quotation.
Frequently Asked Questions — Samsung WA86FX-P
What do the suffix letters mean — WMF, WAF and FX-P?
They are three different products that buyers mix up constantly. FX-P, which this listing is, is the camera build: everything in the WAF interactive display plus a built-in 48 MP camera, a far-field microphone array and dual 20 W speakers, on Android 15 with 128 GB and 50-point touch. WAF is the same family without the camera and audio array, on Android 14. WMF (the WMFX generation) is the Samsung Flip, a Tizen digital flipchart built around writing, with Enhanced Whiteboard, SMARTVIEW+ and Knox.
Do I still need a separate camera, microphone and speakers?
No. The 48 MP camera with Auto Framing, the far-field microphone array with 10 m pickup and the dual 20 W speakers with a woofer are all built into the panel, so a room video kit is not required.
Will the microphone cover a large boardroom?
The far-field microphone array is rated for pickup at up to 10 metres. For a room deeper than that, plan additional room audio with your AV integrator.
What does it add over the WA86F?
The camera and audio array, plus Android 15 instead of 14, 128 GB instead of 64 GB, 450 nit instead of 400 nit, 50-point touch instead of 40, Wi-Fi 6 instead of Wi-Fi 5, DisplayPort 1.2, and AI Write and Search with Live Caption.
How much does it weigh and what does it draw?
The panel measures 1950.4 x 1174.0 x 87.1 mm, weighs 60.9 kg and draws a maximum of 529 W, so plan the mount, the lift and the circuit accordingly.
Do I need an external PC?
No. Android 15 on an octa-core processor with 128 GB of storage runs the room. An OPS slot is available if your organisation still wants a Windows PC in the room.
Is Google Play properly licensed?
Yes. The WA86FX-P is EDLA-certified, so Google Play, YouTube and Google Classroom are licensed and supported rather than side-loaded.
What warranty and invoice do I get?
Every unit sold by SourceIT carries local Singapore warranty and comes with a GST invoice.
