Samsung WA86F 86" 4K Android Interactive Display
PRODUCT DESCRIPTION
Samsung WA86F 86" Android Interactive Display (LH86WAFWLGCXXS) - Local Warranty
An 86-Inch Board for Rooms a Smaller Panel Cannot Carry
The Samsung WA86F is an 86-inch UHD interactive display for lecture theatres, large classrooms and boardrooms where a smaller panel simply cannot reach the back wall. A 3840 x 2160 IPS screen at 400 nits with a 1200:1 contrast ratio and 178-degree viewing angles holds detail right across the room, and the sheer width lets a whole group write, sketch and annotate together at once. Whiteboard, projector and room PC are replaced by a single panel that wakes to a touch.
40-Point IR Touch, Split Note Mode and a Dual-Sided Pen
Infrared touch tracking follows up to 40 simultaneous touch points, so a large class can work on the board together without the panel losing anyone. The bundled dual-sided, dual-colour pen switches ink by flipping it over. Split Note Mode carves the 86-inch canvas into four independent note zones for four people or four teams working in parallel, and Annotation On lets anyone mark up whatever is currently on screen without leaving the source application. At this width each zone is still a usable working area.
EDLA-Certified Android 14 with Licensed Google Play
The WA86F runs Android 14 and is EDLA-certified, so licensed Google Play, YouTube and Google Classroom are installed and properly supported rather than side-loaded. Teachers and staff sign in with the Google accounts they already use, open their own apps and Drive files, and receive genuine updates. With 64 GB of onboard flash and multi-window multitasking, the display runs the tools your organisation already standardises on with no external room PC required and nothing for IT to work around.
Mirror Nine Devices Wirelessly, or Connect with One USB-C Cable
Up to nine devices can mirror to the screen wirelessly at the same time across iOS, macOS, Windows and Android, so presenters hand over without swapping cables. For a wired link, the 3-in-1 USB-C port carries video, touch-back and 65 W of power delivery on a single lead, charging a laptop while it presents. Two HDMI 2.1 inputs, HDMI Out for a second screen, RJ45, RS232, Wi-Fi 5 and an OPS slot cover the rest of the room.
Samsung WA86F Datasheet — Technical Specifications
General
| Product | Samsung WA86F 86" Android Interactive Display |
| Part Number (SKU) | LH86WAFWLGCXXS |
| Display Type | Interactive display (WAF series) |
| Platform | Android 14, EDLA-certified |
| Licensed Google Services | Google Play, YouTube, Google Classroom |
| Internal Storage | 64 GB flash |
| Expansion | OPS slot |
| Local Warranty (Singapore) | Supplied by SourceIT with GST invoice |
Display
| Screen Size | 86" |
| Resolution | 3840 x 2160 (UHD 4K) |
| Brightness | 400 nit (typical) |
| Panel Type | IPS |
| Contrast Ratio | 1200:1 |
| Viewing Angle | 178° / 178° |
Touch & Writing
| Touch Technology | Infrared (IR) |
| Touch Points | Up to 40 simultaneous |
| Pen | Dual-sided, dual-colour |
| Note Taking | Split Note Mode with 4 independent note zones |
| Annotation | Annotation On over any source |
| Multitasking | Multi-window |
Smart Platform & Management
| Operating System | Android 14 |
| Certification | EDLA (Enterprise Devices Licensing Agreement) |
| App Store | Licensed Google Play |
| Education Tools | Google Classroom, YouTube |
| Wireless Mirroring | Up to 9 devices (iOS, macOS, Windows, Android) |
Connectivity
| HDMI In | 2 x HDMI 2.1 |
| HDMI Out | 1 |
| USB-C | 3-in-1 USB-C with 65 W power delivery |
| LAN | RJ45 |
| Wi-Fi | Wi-Fi 5 |
| Serial | RS232 |
| Expansion Slot | OPS |
Physical & Environmental
| Colour | Black |
Specifications are taken from Samsung's published product data for this model. Where Samsung does not publish a figure for this exact model it has been left out rather than estimated.
Compatibility & Installation
Mounting and orientation
The WA86F is a landscape front-of-room display for lecture theatres, large classrooms and boardrooms. At 86 inches it needs a structurally sound wall or a heavy-duty trolley and a multi-person lift, so involve your installer at the design stage rather than on delivery day. In a teaching space, set the mounting height so the writing area is reachable for the shortest user. Confirm the VESA pattern and load rating against the Samsung installation guide for this exact part number before ordering any mount.
What it connects to
The 3-in-1 USB-C port keeps the cable count down: one lead carries video, touch-back and 65 W of charging, so a laptop presents and charges together. Two HDMI 2.1 inputs take a room PC, a visualiser or a document camera, and HDMI Out feeds an overflow display at the rear of a lecture theatre. RJ45 gives a wired network drop, RS232 supports a room control system, and Wi-Fi 5 covers spaces with no cabling. The OPS slot takes an OPS PC where Windows is the room standard.
Network and content management
EDLA-certified Android 14 means the WA86F enrols with licensed Google services rather than side-loaded apps, so staff sign in with existing Google Workspace accounts and IT manages it alongside other Google-licensed devices. Put it on a managed VLAN over RJ45 where update and access control matter, and use Wi-Fi 5 where a drop is impractical. Ask your SourceIT account manager which Samsung management tooling is licensed for this model before planning a campus-wide rollout.
Accessories
The dual-sided, dual-colour pen is supplied with the display. The Samsung Flip connectivity tray CY-TF65BFCXXS is a Flip accessory and is not an accessory for this WAF model.
Package Contents & Samsung WAF Range
In the box
- Samsung WA86F 86" Android interactive display
- Dual-sided, dual-colour pen
Package contents follow Samsung's product data for this model; items not listed by Samsung are not claimed here.
Samsung WAF range
| Model | Size |
| WA65D | 65" |
| WA75D | 75" |
| WA86D | 86" |
| WA65F | 65" |
| WA75F | 75" |
| WA86F (this listing) | 86" |
| WA65FX-P (with camera) | 65" |
| WA75FX-P (with camera) | 75" |
| WA86FX-P (with camera) | 86" |
Datasheet & Downloads
Samsung has not published a public Singapore data sheet page for the WA86F (LH86WAFWLGCXXS) that we can link to here, so no download link is given rather than pointing you at the wrong revision. SourceIT can email the current data sheet revision for this exact part number on request, together with a quotation.
Frequently Asked Questions — Samsung WA86F
What do the suffix letters mean — WMF, WAF and FX-P?
They are three different products that buyers mix up constantly. WAF, which this listing is, is the Samsung Interactive Display: an Android 14, EDLA-certified panel with licensed Google Play, YouTube and Google Classroom, 40-point touch and a 3-in-1 USB-C port. WMF (the WMFX generation) is the Samsung Flip, a Tizen digital flipchart built around writing, with Enhanced Whiteboard, SMARTVIEW+ and Knox. FX-P is this WAF plus a built-in 48 MP camera, a far-field microphone array and dual 20 W speakers, so the room needs no separate video kit.
Does it have a built-in camera and microphone?
No. The WA86F has no built-in camera or microphone array. For video calling without a separate camera bar and microphone, choose the WA86FX-P, which adds a 48 MP camera, a far-field microphone array and dual 20 W speakers.
Do I need an external PC?
No. Android 14 runs on the display with 64 GB of flash and multi-window multitasking. An OPS slot is available if your organisation still wants a Windows PC in the room.
Is Google Play properly licensed?
Yes. The WA86F is EDLA-certified, so Google Play, YouTube and Google Classroom are licensed and supported rather than side-loaded.
Is 86 inches too large for a normal classroom?
It is sized for lecture theatres, large classrooms and boardrooms where the back row sits well away from the board. For a standard classroom or meeting room the 65" or 75" is usually the better fit.
How many people can write on it at the same time?
Infrared touch tracks up to 40 simultaneous touch points, and Split Note Mode gives four independent note zones.
Can one cable handle video, touch and laptop charging?
Yes. The 3-in-1 USB-C port carries video, touch-back and 65 W of power delivery on a single lead.
What warranty and invoice do I get?
Every unit sold by SourceIT carries local Singapore warranty and comes with a GST invoice.
