NETGEAR GS728TPP 24-Port Gigabit PoE+ Smart Cloud Managed Switch with 4 SFP (380W)
PRODUCT DESCRIPTION
NETGEAR GS728TPP 24-Port Gigabit Ethernet PoE+ Smart Switch with 4 SFP Ports and Remote/Cloud Management (380W) (GS728TPP-300UKS) - Limited Lifetime Local Warranty
Standalone Smart Switch, Cloud Optional
The NETGEAR GS728TPP (GS728TPPv3) is a 24-port Gigabit PoE+ smart switch with 4 dedicated SFP ports, designed for converged networks big or small. Manage it locally through the web GUI, or remotely through the NETGEAR Insight mobile app or Insight Cloud Portal — NETGEAR includes a 1-year Insight subscription.
All Ports PoE+, 380W Budget
Every copper port delivers IEEE 802.3at PoE+ from a 380W budget to power VoIP phones, IP cameras, video-over-IP endpoints and wireless access points, with PoE scheduling and advanced per-port PoE controls for remote power management.
Advanced L2+ Features
IPv4/IPv6 static routing, LACP link aggregation, DiffServ QoS, Private VLAN, Auto-VoIP and Auto-Video VLAN, 802.1X, DHCP snooping, IGMP/MLD snooping and ACLs, with a USB port for configuration backup and firmware updates.
Need help choosing? Email sales@sourceit.com.sg with your port count, PoE and uplink needs and we will size it for you.
NETGEAR GS728TPP Datasheet — Technical Specifications
General
| Product Name | NETGEAR GS728TPP 24-Port Gigabit Ethernet PoE+ Smart Switch with 4 SFP Ports and Remote/Cloud Management (380W) |
| Part Number | GS728TPP-300UKS |
| Hardware Version | GS728TPPv3 |
| Series | NETGEAR Smart Cloud Switches (Insight Managed) |
| Local Warranty (Singapore) | Limited lifetime, supplied by SourceIT with a GST invoice |
Interfaces
| Ethernet Ports | 24 x 10/100/1000BASE-T RJ-45 |
| PoE | 24 x IEEE 802.3at PoE+ ports (all copper ports), 380W total budget |
| Fiber Ports | 4 x dedicated 1000BASE-X SFP |
| USB | 1 x USB (configuration upload/backup and firmware updates) |
Performance
| Switching Bandwidth | 56 Gbps |
| Forwarding Rate | 41.67 Mpps (64-byte packets) |
| Latency | 4.008 µs (1G copper, 64-byte packets) |
| MAC Address Table | 16K |
| Packet Buffer | 1.5 MB |
| Jumbo Frames | Up to 10K bytes |
| VLANs | Up to 256 |
Software Features
| Layer 2 | 802.1Q VLANs, Private VLAN, Auto-VoIP, Auto-Video VLAN, MVR, STP, LACP (16 LAGs, up to 8 members each), LLDP-MED, cable test |
| Layer 3 Lite | IPv4/IPv6 static routing (32 IPv4 + 32 IPv6 routes), 512 ARP entries |
| QoS & Multicast | DiffServ QoS; IGMP snooping and MLD snooping; 512 multicast groups |
| Security | 100 shared ACLs (MAC/IP/IPv6 ingress), 802.1X, DHCP snooping |
| Management | Web GUI (HTTP/HTTPS), NETGEAR Insight mobile app or Insight Cloud Portal, zero-touch provisioning, PoE scheduling |
Power & Environmental
| Power Supply | 1 x internal fixed PSU |
| Power Consumption | 427 W max (full PoE and line-rate traffic); 14 W idle |
| Heat Dissipation | 1,460.34 BTU/hr |
| Cooling | 2 internal fixed fans, 33.3 dBA at 25 °C |
| MTBF | 1,252,990 hours at 25 °C |
| Operating Temperature | 0 to 50 °C |
| Operating Humidity | 90% max RH, non-condensing |
Physical
| Dimensions (W x D x H) | 440 x 257 x 43.2 mm |
| Weight | 4.11 kg |
| Mounting | Rackmount (brackets and screws included) or desktop with rubber footpads |
Certifications
| EMC | CE, FCC Class A, RCM, ICES Class A, VCCI, KC, BSMI, UKCA |
| Safety | CB, CE, CSA, RCM, KC, BSMI |
Compatibility & Software Support
Management
Local web browser GUI (HTTP/HTTPS), or NETGEAR Insight remote/cloud management through the Insight mobile app or Insight Cloud Portal (1-year Insight subscription included per NETGEAR).
Typical Use
SMB, education, hospitality and retail networks powering up to 24 PoE+ phones, cameras, video endpoints or access points, with 4 SFP ports for fiber uplinks.
Package Contents & GS728TP / GS752TP Smart Cloud PoE+ Switch Ordering Information
In the Box
GS728TPP switch, AC power cord with C13 connector (localized), rack-mount brackets and screws, rubber footpads, rubber protection caps in the SFP sockets, installation guide.
NETGEAR GS728TP / GS752TP Smart Cloud PoE+ Switch Models
| Model | Ports | Part No. |
| GS728TP | 24 x GE + 4 x SFP (24 x PoE+, 190 W) | GS728TP |
| GS728TPP (this listing) | 24 x GE + 4 x SFP (24 x PoE+, 380 W) | GS728TPP-300UKS |
| GS752TP | 48 x GE + 4 x SFP (48 x PoE+, 380 W) | GS752TP |
| GS752TPP | 48 x GE + 4 x SFP (48 x PoE+, 760 W) | GS752TPP-300UKS |
Other models are available to order — email sales@sourceit.com.sg for a quote.
Datasheet & Downloads
| NETGEAR datasheet | GS728TPv3 / GS728TPPv3 / GS752TPv3 / GS752TPPv3 Datasheet (PDF) |
| Installation guide | GS728TPv3 / GS728TPPv3 Installation Guide (PDF) |
| User manual | GS728TPv3 / GS728TPPv3 / GS752TPv3 / GS752TPPv3 User Manual (PDF) |
| NETGEAR product page | GS728TPP on netgear.com |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting GS728TPP-300UKS.
Frequently Asked Questions — NETGEAR GS728TPP
How much PoE power does the GS728TPP provide?
380W total, with PoE+ (802.3at) on all 24 copper ports.
Can it be managed from the cloud?
Yes. NETGEAR lists NETGEAR Insight app and Cloud Portal management alongside the local web GUI, with a 1-year Insight subscription included.
Does it have fiber uplinks?
Yes, 4 dedicated 1G SFP ports (SFP modules sold separately, e.g. NETGEAR AGM731F or AGM732F).
Does it support routing?
Yes, IPv4/IPv6 static routing (32 IPv4 and 32 IPv6 routes).
What warranty do I get?
Limited lifetime local warranty in Singapore, supplied by SourceIT with a GST invoice.
