NETGEAR GS324TP 24-Port Gigabit PoE+ Smart Managed Pro Switch with 2 SFP (190W)
PRODUCT DESCRIPTION
NETGEAR GS324TP S350 Series 24-Port Gigabit Ethernet PoE+ Smart Managed Pro Switch with 2 SFP Ports (190W) (GS324TP-100EUS) - 5 Years Local Warranty
S350 Smart Managed Pro Control
The NETGEAR GS324TP belongs to the S350 Smart Managed Pro series: 24 Gigabit ports plus 2 dedicated SFP fiber ports, configured through an easy-to-use web GUI with the L2 features small and mid-size businesses need.
24 PoE+ Ports, 190W Budget
All 24 copper ports supply IEEE 802.3at PoE+ from a 190W budget to power IP phones, cameras and access points, with advanced PoE controls for any PoE deployment.
Voice, Video and Security Ready
Auto-VoIP, Auto-Voice and Auto-Video VLAN, 802.1x with RADIUS, DHCP snooping, L2/L3/L4 ACLs and STP/RSTP/MSTP make it a solid access switch for converged networks. 52 Gbps line-rate switching keeps traffic flowing.
Need help choosing? Email sales@sourceit.com.sg with your port count, PoE and uplink needs and we will size it for you.
NETGEAR GS324TP Datasheet — Technical Specifications
General
| Product Name | NETGEAR GS324TP 24-Port Gigabit Ethernet PoE+ Smart Managed Pro Switch with 2 SFP Ports (190W) |
| Part Number | GS324TP-100EUS |
| Series | NETGEAR S350 Smart Managed Pro Switches |
| Local Warranty (Singapore) | 5 years, supplied by SourceIT with a GST invoice |
Interfaces
| Ethernet Ports | 24 x 10/100/1000BASE-T RJ-45 |
| PoE | 24 x IEEE 802.3at PoE+ ports, 190W total budget |
| Fiber Ports | 2 x dedicated 1000BASE-X SFP |
Performance
| Switching Bandwidth | 52 Gbps (line rate) |
| Forwarding Rate | 38.6 Mpps (64-byte packets) |
| Latency | 3.734 µs (1G copper, 64-byte packets) |
| MAC Address Table | 16K |
| Packet Buffer | 512 KB |
| Jumbo Frames | Up to 9,216 bytes |
| VLANs | Up to 64 |
Software Features
| Layer 2 | 802.1Q VLANs, Auto-VoIP, Auto-Voice and Auto-Video VLAN, STP/RSTP/MSTP, 802.3ad LACP (8 LAGs, up to 8 members each), LLDP / LLDP-MED |
| QoS & Multicast | 4 priority queues (WRR and Strict Priority), IPv4/IPv6 DSCP, egress rate limiting; IGMP snooping v1/v2/v3 with querier |
| Security | 802.1x with RADIUS and guest VLAN, DHCP snooping, L2/L3/L4 ingress ACLs (incl. IPv6) |
| Management | Web GUI (HTTPS/TLS 1.2), Smart Control Center, SNMP v1/v2c/v3, RMON 1/2/3/9, dual firmware image, port mirroring |
Power & Environmental
| Power Supply | 1 x internal fixed PSU |
| Power Consumption | 229.9 W max (full PoE); 11.1 W idle |
| Heat Dissipation | 784.88 BTU/hr max |
| Cooling | 2 internal fixed fans, 32.8 dBA at 25 °C |
| MTBF | 1,328,429 hours at 25 °C |
| Operating Temperature | 0 to 45 °C |
| Operating Humidity | 95% max RH, non-condensing |
Physical
| Dimensions (W x D x H) | 330 x 206 x 43 mm |
| Weight | 2.69 kg |
| Mounting | Rackmount (rackmount kit included) or desktop with rubber footpads |
Certifications
| EMC | CE, FCC Part 15 Class A, VCCI Class A, RCM Class A, ISED ICES-003 Class A, CCC, BSMI |
| Safety | CB IEC 60950-1, UL/cUL, CE LVD, RCM, CCC, BSMI |
Compatibility & Software Support
Management
Local web browser GUI (HTTPS) or NETGEAR Smart Control Center utility (Windows PC); SNMP v1/v2c/v3 for network management systems.
Typical Use
Small and mid-size business access layer powering up to 24 PoE+ phones, cameras or access points, with 2 fiber uplinks to the core.
Package Contents & S350 Smart Managed Pro Switch Ordering Information
In the Box
GS324TP switch, power cord (localized), rackmount kit, rubber footpads, installation guide.
NETGEAR S350 Smart Managed Pro Switch Models
| Model | Ports | Part No. |
| GS308T | 8 x GE | GS308T |
| GS310TP | 8 x GE + 2 x SFP (8 x PoE+, 55 W) | GS310TP |
| GS324T | 24 x GE + 2 x SFP | GS324T |
| GS324TP (this listing) | 24 x GE + 2 x SFP (24 x PoE+, 190 W) | GS324TP-100EUS |
| GS348T | 48 x GE + 4 x SFP | GS348T |
Other S350 models are available to order — email sales@sourceit.com.sg for a quote.
Datasheet & Downloads
| NETGEAR datasheet | S350 Smart Switch Series Datasheet (PDF) |
| Installation guide | GS324T / GS324TP / GS348T Installation Guide (PDF) |
| User manual | GS324T / GS324TP / GS348T User Manual (PDF) |
| NETGEAR product page | GS324TP on netgear.com |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting GS324TP-100EUS.
Frequently Asked Questions — NETGEAR GS324TP
How much PoE power does the GS324TP provide?
190W total across 24 PoE+ (802.3at) ports.
Does it have fiber uplinks?
Yes, 2 dedicated 1G SFP ports (SFP modules sold separately, e.g. NETGEAR AGM731F or AGM732F).
Can it be rack mounted?
Yes. A rackmount kit is included in the box.
Does it have fans?
Yes, 2 internal fans rated at 32.8 dBA at 25 °C.
What warranty do I get?
5 years local warranty in Singapore, supplied by SourceIT with a GST invoice.
