Lenovo ThinkVision T32p-30 31.5-inch 4K UHD Monitor
PRODUCT DESCRIPTION
Lenovo ThinkVision T32p-30 (63D2GAR1WW) - 3 Years Local Warranty
31.5-Inch 4K With a 90 W Dock, Gigabit Ethernet and a KVM Switch
The ThinkVision T32p-30 is the most capable monitor in this T-series group: 3840 x 2160 across 31.5 inches, a USB-C port delivering DisplayPort 1.4 Alt Mode video and up to 90 W of charging, gigabit Ethernet, a four-port USB hub, and — uniquely in this family — a KVM switch.
The KVM Is the Feature Worth Buying It For
One keyboard and one mouse, shared between two connected computers, switched from the monitor. A desktop on DisplayPort and a laptop on USB-C both drive the same screen and the same peripherals. Lenovo publishes KVM only on this model in this family — the T32h-30 beside it does not have it, and physically cannot, since it lacks the second upstream port a KVM needs.
100% sRGB, 95% DCI-P3, 10-Bit Colour
Lenovo publishes 100% sRGB and 95% DCI-P3 (CIE 1976) at 10-bit (8-bit + FRC) and 350 cd/m². That is a wide-gamut panel — well beyond office requirements and into the territory where design and video review work is realistic. Note that Lenovo publishes no Delta E or factory-calibration figure for this model, so we make no accuracy claim beyond the gamut coverage.
A Correction to This Listing
This page previously carried an unfinished internal editing note in place of a proper warranty line, stated the term as one year, and described the monitor as a bare panel, mentioning none of the USB-C docking, the Ethernet, the USB hub or the KVM. Lenovo publishes a 3-year limited warranty. The page has been rebuilt.
Lenovo ThinkVision T32p-30 Datasheet — Technical Specifications
General
| Product | Lenovo ThinkVision T32p-30 |
| Part Number | 63D2GAR1WW |
| Machine Type | 63D2 |
| Type | 31.5-inch 4K UHD USB-C docking monitor with KVM |
| Warranty | 3-Year Limited Warranty (Lenovo, per PSREF) |
| Local Warranty (Singapore) | Included with every SourceIT purchase, with GST invoice |
Panel & Image
| Screen Size | 31.5" |
| Panel Type | 3-side NearEdgeless In-Plane Switching (IPS), WLED backlight |
| Resolution | 3840 x 2160 (4K UHD) |
| Aspect Ratio | 16:9 |
| Pixel Pitch | 0.182 x 0.182 mm |
| Refresh Rate | 60 Hz |
| Response Time | 4 ms Extreme mode / 6 ms Normal mode |
| Brightness | 350 cd/m² |
| Contrast Ratio | 1000:1 typical; 3,000,000:1 dynamic |
| Colour Gamut | 100% sRGB and 95% DCI-P3 (CIE 1976, per Lenovo's datasheet) |
| Colour Depth | 10-bit (8-bit + FRC) |
| Factory Calibration / Delta E | Not published by Lenovo for this model. Neither "Delta E" nor "factory calibration" appears in Lenovo's specification sheet or datasheet, so we make no accuracy claim. If your work needs a calibrated panel, the ThinkVision P-series publishes Delta E figures and ships a calibration report — ask us |
| Viewing Angles | 178° horizontal / 178° vertical |
| Surface | Anti-glare |
| Bezel | 2.0 mm sides, 2 mm top, 18.6 mm bottom |
Connectivity
| USB-C (docking) | 1 x USB-C 3.2 Gen 1 — DisplayPort 1.4 Alt Mode, data, gigabit Ethernet and up to 90 W power delivery on one cable |
| Video Inputs | 1 x HDMI 2.1 TMDS, 1 x DisplayPort 1.4 (HBR2), plus video over USB-C |
| DisplayPort Out | None |
| USB Hub | 4 x USB 3.2 Gen 1 Type-A downstream, one with BC 1.2. Two upstream connections: 1 x USB-B 3.2 Gen 1 and the USB-C port — which together are what make the KVM possible |
| KVM Switch | Yes. Share one keyboard and mouse between two connected computers, switched from the monitor |
| Network | 1 x RJ45 gigabit Ethernet (10/100/1000 Mbps) |
| Audio Out | 1 x 3.5 mm |
| Speakers | None built in. Lenovo offers the MS30 Monitor Soundbar as a separately-sold modular accessory that clips to the display; a 3.5 mm audio-out is provided for powered speakers or headphones |
| Camera | None built in; a webcam is sold separately |
| Picture-in-Picture / Picture-by-Picture | Not published by Lenovo for this model |
| Security | Kensington Security Slot |
Stand & Ergonomics
| Tilt | -5° to +23.5° |
| Swivel | 45° left and right |
| Pivot | -90° to +90° |
| Height Adjustment | Up to 155 mm |
| VESA | 100 x 100 mm |
Features
| Software | Lenovo ThinkColour (Lenovo Accessories and Display Manager) |
| Eye Care | Natural Low Blue Light |
| Power Management | Smart Power |
Power & Certifications
| Power Consumption | 32 W typical / 161 W maximum — the highest in this T-series group |
| ENERGY STAR Power-On | 32 W; TEC 99 kWh |
| Sleep / Off Mode | < 0.5 W |
| Switch-off Mode | < 0.3 W |
| Power Supply | Internal, AC 100–240 V, 50–60 Hz |
| Certifications | ENERGY STAR certified; EPEAT Gold registered; TCO Certified 9.0; TCO edge 2.0; RoHS; Volatile Organic Compound certification; Eyesafe Certified 2.0; TÜV Rheinland Eye Comfort; TÜV Rheinland Low Blue Light (hardware solution) |
Physical
| Dimensions with Stand | 714.2 x 234.9 x 444.5 mm at lowest; 599.5 mm high at highest |
| Head Only | 714.2 x 59.5 x 420.9 mm |
| Weight | 10.0 kg with stand; 7.2 kg head only |
| Packaged | 950 x 525 x 148 mm; 14.0 kg |
Compatibility & Fit
How the KVM actually works in practice. Connect a desktop to the DisplayPort or HDMI input and to the USB-B upstream port; connect a laptop to the USB-C port. Plug your keyboard and mouse into the monitor's USB ports. Switching the input now switches the peripherals with it. This is the setup that removes a second keyboard from a desk, and it is the single reason to choose this monitor over the T32h-30.
One thing Lenovo does not put in the box, which the KVM needs. The published box contents are a USB-C to USB-C cable and a power cable — no USB-B cable, despite the USB-B upstream port being essential to the KVM function. Order a USB-A to USB-B cable with the monitor; ask us and we will include one.
4K at 31.5 inches — a word on scaling. 3840 x 2160 across 31.5 inches gives a 0.182 mm pixel pitch. Most people run this at 125% or 150% display scaling in Windows, which looks excellent. A few older line-of-business applications still scale badly. If your fleet runs one of those, the QHD T32h-30 beside it may be the safer choice; if you are on modern software, the 4K panel is a substantial upgrade.
Colour, honestly stated. 100% sRGB and 95% DCI-P3 at 10-bit is a genuinely wide gamut. But Lenovo publishes no Delta E figure and no factory calibration for this model, so it is not a colour-critical monitor in the sense a print or grading professional means. For that, the ThinkVision P-series publishes Delta E under 2 and ships a printed calibration report — ask us and we will quote one.
Power budget. At 161 W maximum this is the heaviest draw in this group. That is the panel plus 90 W going out to the laptop; plan the desk circuit accordingly if several are on one spur.
Package Contents & ThinkVision Ordering Information
In the box, per Lenovo PSREF:
- Monitor with stand
- 1 x USB-C to USB-C cable (1.8 m)
- 1 x power cable (1.8 m)
- Quick setup guide and warranty booklet
Not in the box: a USB-B cable, a DisplayPort cable or an HDMI cable. The USB-B cable in particular is what the KVM function needs in order to work with a second computer. Tell us how the desk will be wired and we will supply the right cables with the order.
ThinkVision T-Series Ordering Information
| 63B0MAR6MY | ThinkVision T22i-30 — 21.5" FHD IPS, 4-port USB hub, full ergonomic stand |
| 63CFMARXMY | ThinkVision T24i-30 — 23.8" FHD IPS, 4-port USB hub, full ergonomic stand |
| 63FFMAR1MY | ThinkVision T24d-30 — 24" WUXGA 16:10, 1500:1, speakers, 100 Hz |
| 63A4MAR1WW | ThinkVision T27i-30 — 27" FHD IPS, 300 nits, 4-port USB hub |
| 61F1GAR2WW | ThinkVision T32h-20 — 31.5" QHD, USB-C 75 W, previous generation |
| 63D3GAR1WW | ThinkVision T32h-30 — 31.5" QHD, USB-C 90 W dock, gigabit Ethernet |
| 63D2GAR1WW (this listing) | ThinkVision T32p-30 — 31.5" 4K, USB-C 90 W dock, GbE, KVM |
| 63D4GAR1WW | ThinkVision T34w-30 — 34" 21:9 curved 1500R VA, USB-C 75 W dock, GbE |
Datasheet & Downloads
- Lenovo PSREF specification sheet — ThinkVision T32p-30 (PDF)
- Lenovo ThinkVision T32p-30 product datasheet (PDF)
PSREF is Lenovo's own Product Specifications Reference and is the source for every figure on this page unless the table says otherwise. PSREF publishes its spec sheets per model rather than per part number, so this SKU does not appear inside the PDF itself; a per-part-number detail page also exists at psref.lenovo.com and will render in a normal browser if you need this exact configuration confirmed before ordering. Ask us and we will pull it for you.
Frequently Asked Questions — Lenovo ThinkVision T32p-30
Is the warranty one year or three?
Three. Lenovo PSREF states a 3-year limited warranty. Our earlier version of this page said one year, and left an unfinished internal editing note in the warranty line where a proper answer should have been. Neither should have been visible to a customer, and both are corrected.
What do I need to make the KVM work?
Three things: a second computer connected to the DisplayPort or HDMI input, a USB-A to USB-B cable from that computer to the monitor's USB-B upstream port, and your keyboard and mouse plugged into the monitor rather than the computer. The USB-B cable is not supplied in the box — ask us to add one.
How does this differ from the T32h-30?
Two things: resolution and the KVM. The T32p-30 is 4K (3840 x 2160) against the T32h-30's QHD (2560 x 1440), and it has a KVM switch, which the T32h-30 does not and cannot. Otherwise the stand, the 90 W USB-C dock, the gigabit Ethernet and the four-port hub are the same. The T32p-30 also draws more power — 161 W maximum against 153 W.
Is it colour-accurate enough for design work?
It has the gamut for it — 100% sRGB and 95% DCI-P3 at 10-bit. What it does not have is a published accuracy figure: Lenovo states no Delta E and no factory calibration for this model. For work where colour has to be right rather than merely wide, the ThinkVision P-series publishes Delta E under 2 and includes a printed calibration report in the box. Tell us what the work is and we will point you at the right one.
Will 4K at 31.5 inches be too small to read?
At 100% scaling, for most people, yes. Nearly everyone runs a monitor of this size and resolution at 125% or 150% display scaling, at which point it looks superb and gives noticeably more usable space than QHD. The only caution is older line-of-business software that scales badly — if that describes your fleet, tell us and we will help you choose.
What warranty applies in Singapore?
Lenovo PSREF states a 3-year limited warranty as the base warranty for this model, and every unit SourceIT sells comes with local Singapore warranty support and a GST invoice.
