Epson WorkForce DS-530III A4 Duplex Sheet-fed Document Scanner
PRODUCT DESCRIPTION
Epson WorkForce DS-530III A4 Duplex Sheet-fed Document Scanner (B11B286501) - 1 Year Local Warranty
The Epson WorkForce DS-530III A4 Duplex Sheet-fed Document Scanner - High-Speed Scanning That Keeps Demanding Businesses Moving.
Fast and Reliable Scanner
DS-530III delivers one-pass duplex scanning at up to 40 ppm / 80 ipm, and its 60-sheets ADF efficiently handles stacks of everyday documents – ideal for high-volume workflows.
Versatile Media Scanning
Handle a wide range of media to meet diverse business needs. The ADF processes high‑volume, mixed‑size documents with ease – from standard and long paper to plastic cards such as ID, credit, and business cards.
Intuitive One-Touch Control
Work efficiently with essential buttons at your fingertips. Easily skip double feed alerts, enable slow scan mode for delicate documents, or start and stop scans directly from the control panel.
Flatbed Option for Enhanced Versatility
Expand the capability of DS-530III with the optional Flatbed Dock and Epson Perfection V39II for scanning of thick booklets, small and delicate documents.
Paper Protection
Safeguard your documents with the scanner's built-in Paper Protection feature, which automatically stops scanning when feeding errors are detected to prevent damage to important originals.
Glass Dirt Detection
Get on-screen notification when dirt is detected on the glass surface inside the scanner. This helps prevent poor image quality and reduces the need for re-scanning.
Document Capture Pro
Simplify your scanning workflow and automate your scanning tasks for processing or send documents to cloud storage services with Document Capture Pro. Convert documents into Searchable PDF files or editable Office documents with built-in OCR capability.
Ideal For
Offices, clinics, accounts and admin teams in Singapore that digitise documents, receipts and records at volume. Supplied by SourceIT with local Singapore warranty, GST invoice and corporate or project pricing on request.
WorkForce DS-530III Datasheet — Technical Specifications
General
| Model | WorkForce DS-530III |
| Official Product Name | Epson WorkForce DS-530III A4 Duplex Sheet-fed Document Scanner |
| Epson Product Code | B11B286501 |
| Brand | Epson |
| Warranty | 1 Year Local Warranty (Singapore) - 12 months |
Scanner
| Scanner Type | A4 sheet-fed, one-pass duplex colour scanner |
| Sensor Type | Contact Image Sensor (CIS) x 2 |
| Scanning Method | Fixed carriage and moving document |
| Light Source | RGB LED x 2 |
| Optical Resolution | 600 x 600 dpi |
| Output Resolution | 50 – 1,200 dpi (in 1 dpi increments) |
| Bit Depth | Colour: 30-bit input, 24-bit output; Grayscale: 10-bit input, 8-bit output; Black & White: 10-bit input, 1-bit output |
| Supported Paper Weight | 27 – 413 g/m2, Less than A8 size: 127 – 413 g/m2 |
| ADF Capacity | 60 sheets (80 g/m2) |
| Daily Scan Volume | Up to 6,500 sheets / day |
| Multi-feed Detection | Ultrasonic Sensor and Length Detection |
| Interface | USB 3.2 Gen 1 |
| Max Document Size | 215.9 x 6,096 mm |
| Min Document Size | 50.8 x 50.8 mm |
Scan Speed
| Resolution (A4, Colour/Monochrome) 300 dpi | 40 ppm / 80 ipm |
| Resolution (A4, Colour/Monochrome) 600 dpi | 12 ppm / 24 ipm |
Drivers and Software
| Supported OS (Scanner Driver) | Windows 7 / 8 / 8.1 / 10 / 11 or later, Windows Server 2008 or later, Mac OS X 10.9.5 or later, macOS 11 or later |
| Driver Compatibility | TWAIN, SANE, WIA, ICA, ISIS |
| Bundled Software | Epson Scan 2, ISIS Driver (Web Download), Epson Scan OCR Component, Epson Scan PDF Extensions, Document Capture Pro (Windows) / Document Capture (Mac) |
| Software Solutions Compatibility | Epson Device Admin |
| File Format | Epson Scan 2: JPEG, TIFF, Multi-TIFF, PDF, Searchable PDF, BMP, PNG; Document Capture Pro: JPEG, JPEG2000, BMP, PDF, Searchable PDF, TIFF, Multi-TIFF, PNG, DOCX, XLSX, PPTX |
Environmental Conditions
| Temperature | Operating: 5 – 35 °C; Storage: -25 – 60 °C |
| Humidity | Operating: 15 – 80 % (No condensation); Storage: 15 – 85 % (No condensation) |
Dimensions and Weight
| Dimensions (W x D x H) | 296 x 169 x 176 mm |
| Weight | 3.7 kg |
Electrical Specifications
| Rated Voltage | AC 220 – 240 V |
| Rated Frequency | 50 – 60 Hz |
| Power Consumption | Operating: 13.0 W; Ready Mode: 5.5 W; Sleep Mode: 0.8 W; Power Off: 0.1 W |
Options & Consumables
| Flatbed Dock | B12B819011 |
| Roller Assembly Kit | Durability: 200,000 scans; B12B819671 |
| Carrier Sheet | Durability: 3,000 scans; B12B819051 |
| Cleaning Kit | B12B819291 |
Compatibility & Software Support
Compatibility details below are taken from Epson Singapore's published specification for the WorkForce DS-530III. Drivers, utilities and firmware are available from Epson Singapore's support site (see Datasheet & Downloads).
| Interface | USB 3.2 Gen 1 |
| Supported OS (Scanner Driver) | Windows 7 / 8 / 8.1 / 10 / 11 or later, Windows Server 2008 or later, Mac OS X 10.9.5 or later, macOS 11 or later |
| Driver Compatibility | TWAIN, SANE, WIA, ICA, ISIS |
| Bundled Software | Epson Scan 2, ISIS Driver (Web Download), Epson Scan OCR Component, Epson Scan PDF Extensions, Document Capture Pro (Windows) / Document Capture (Mac) |
| Software Solutions Compatibility | Epson Device Admin |
Package Contents & Ordering Information
Ordering Information
| Model | WorkForce DS-530III |
| Epson Product Code | B11B286501 |
| Recommended Retail Price (incl. GST) | S$688.00 |
| Consumables | Roller Assembly Kit B12B819671 (200,000 scans); Carrier Sheet B12B819051 (3,000 scans); Cleaning Kit B12B819291; optional Flatbed Dock B12B819011 |
Epson Singapore does not publish an itemised in-the-box list for this model. Please ask SourceIT if you need the exact package contents confirmed before ordering.
Datasheet & Downloads
Frequently Asked Questions — WorkForce DS-530III
What warranty does the WorkForce DS-530III come with?
1 Year Local Warranty from Epson Singapore: 12 months. Every unit sold by SourceIT is a genuine Singapore set with a GST invoice.
Which consumables does the WorkForce DS-530III use?
Roller Assembly Kit B12B819671 (200,000 scans); Carrier Sheet B12B819051 (3,000 scans); Cleaning Kit B12B819291; optional Flatbed Dock B12B819011 Always use genuine Epson consumables to protect print quality and warranty coverage. SourceIT can supply them together with the unit.
Is stock held locally?
SourceIT holds fast-moving Epson models in Singapore. Anything not in local stock is ordered through Epson's local distributor - ask us for the current lead time before committing to a date.
Can SourceIT quote for multiple units or a project?
Yes. Send us your quantity and delivery requirements and we will quote the units together with consumables, options and installation where required, with local warranty and GST invoice.
