Epson WorkForce DS-50000 A3 Flatbed Document Scanner
PRODUCT DESCRIPTION
Epson WorkForce DS-50000 A3 Flatbed Document Scanner (B11B204141) - 1 Year Local Warranty
The Epson WorkForce DS-50000 A3 Flatbed Document Scanner - The Epson WorkForce DS-50000 A3 colour scanner maximises productivity at work.
Fast and Flexible A3 Scanning
The DS-50000 flatbed scanner lets you quickly and easily scan A3-sized and wide-format documents such as maps, drawings, or large bound books and even odd-shaped articles. Images, graphics and text are captured with amazing clarity and accuracy with its high resolution of 600 dpi CCD sensor.
Eco-Conscious Scanning Performance
It is equipped with Epson ReadyScan LED technology that require zero warm-up time, resulting in lower power consumption. It also has a power-saving sleep mode that reduces energy consumption even further.
Epson Scan 2 - Text Enhancement
Improves text recognition when scanning text documents, whether in colour, greyscale or black-and-white. Removes background for better clarity, which is especially useful for double-sided printed documents.
Document Skew Correction
Automatically adjusts and straightens scanned images.
Colour Enhancement & Colour Dropout
Remove or enhance the visibility of ink signatures such as 'Confidential' and 'Urgent' stamps. Users can pick one of the preset colours (red, green, blue, pink, purple, yellow, orange, or all colours except black), or use the customised settings to dropout or enhance up to 5 colours of your choice with a single scan. Up to 10 preset colours can be saved for reuse.
Advanced PDF Features
Built-in OCR function to create Searchable PDF files. Secure your PDF files by setting a password to prevent unauthorised viewing, editing or printing.
Advanced Document Management – Document Capture Pro
The DS-50000 comes bundled with document management software that allows you to easily manage your scanned files. Easily scan, view, edit, save and transfer scanned documents. The software optically recognizes barcodes, characters and blank pages in scanned documents to separate them into different folders. It allows you to create up to 30 customised job settings, making multiple scan jobs a breeze. The software also provides quick access to post-scan destinations, including scan-to-print, email, Windows® Public Folder, FTP, Web Folder, and Scan-to-Cloud services such as Microsoft® SharePoint Server, Evernote®, Google® Drive™ and SugarSync®.
Ideal For
Offices, clinics, accounts and admin teams in Singapore that digitise documents, receipts and records at volume. Supplied by SourceIT with local Singapore warranty, GST invoice and corporate or project pricing on request.
WorkForce DS-50000 Datasheet — Technical Specifications
General
| Model | WorkForce DS-50000 |
| Official Product Name | Epson WorkForce DS-50000 A3 Flatbed Document Scanner |
| Epson Product Code | B11B204141 |
| Brand | Epson |
| Warranty | 1 Year Local Warranty (Singapore) - 12 months |
Scanner
| Scanner Type | A3 flatbed colour image scanner |
| Sensor Type | 4-line colour CCD |
| Scanning Method | Fixed document and moving carriage |
| Light Source | White LED |
| Optical Resolution | 600 x 600 dpi |
| Output Resolution | 50 – 9,600 dpi (in 1 dpi increments) |
| Bit Depth | Colour: 48-bit input, 24-bit output; Grayscale: 16-bit input, 8-bit output; Black & White: 16-bit input, 1-bit output |
| Interface | USB 2.0 |
| Max Document Size | 297 x 420 mm |
Drivers and Software
| Supported OS (Scanner Driver) | Windows XP / Vista / 7 / 8 / 8.1 / 10 / 11, Server 2003 / 2008 / 2012 / 2016 / 2019 / 2022; Mac OS X 10.6.8 or later |
| Driver Compatibility | TWAIN, SANE, WIA, ICA, ISIS |
| Bundled Software | Epson Scan 2, ISIS Driver (Web Download), Epson Scan OCR Component, Epson Scan PDF Extensions, Document Capture Pro (Windows), Document Capture (Mac) |
| Software Solutions Compatibility | Epson Device Admin |
| File Format | Epson Scan 2: JPEG, TIFF, Multi-TIFF, PDF, Searchable PDF, BMP, PNG; Document Capture Pro (Windows): JPEG, JPEG2000, BMP, PDF, Searchable PDF, TIFF, Multi-TIFF, PNG, DOCX, XLSX, PPTX |
Electrical Specifications
| Rated Voltage | AC 100 - 240 V |
| Rated Frequency | 50 - 60 Hz |
| Power Consumption | Operating: 25.5 W; Ready Mode: 9.5 W; Sleep Mode: 1.5 W; Power Off: 0.5 W |
Environmental Conditions
| Temperature | Operating: 5 - 35 °C; Storage: -25 - 60 °C |
| Humidity | Operating: 10 - 80 % (No Condensation); Storage: 10 - 85 % (No Condensation) |
Dimensions and Weight
| Dimensions (W x D x H) | 640 x 468 x 156 mm |
| Weight | 14.8 kg |
Scan Speed
| Flatbed (Black / Colour) | 300 dpi: 4 sec / 4 sec; 600 dpi: 10 sec / 6 sec |
Compatibility & Software Support
Compatibility details below are taken from Epson Singapore's published specification for the WorkForce DS-50000. Drivers, utilities and firmware are available from Epson Singapore's support site (see Datasheet & Downloads).
| Interface | USB 2.0 |
| Supported OS (Scanner Driver) | Windows XP / Vista / 7 / 8 / 8.1 / 10 / 11, Server 2003 / 2008 / 2012 / 2016 / 2019 / 2022; Mac OS X 10.6.8 or later |
| Driver Compatibility | TWAIN, SANE, WIA, ICA, ISIS |
| Bundled Software | Epson Scan 2, ISIS Driver (Web Download), Epson Scan OCR Component, Epson Scan PDF Extensions, Document Capture Pro (Windows), Document Capture (Mac) |
| Software Solutions Compatibility | Epson Device Admin |
Package Contents & Ordering Information
Ordering Information
| Model | WorkForce DS-50000 |
| Epson Product Code | B11B204141 |
| Recommended Retail Price (incl. GST) | S$2,578.00 |
Epson Singapore does not publish an itemised in-the-box list for this model. Please ask SourceIT if you need the exact package contents confirmed before ordering.
Datasheet & Downloads
Frequently Asked Questions — WorkForce DS-50000
What warranty does the WorkForce DS-50000 come with?
1 Year Local Warranty from Epson Singapore: 12 months. Every unit sold by SourceIT is a genuine Singapore set with a GST invoice.
Is stock held locally?
SourceIT holds fast-moving Epson models in Singapore. Anything not in local stock is ordered through Epson's local distributor - ask us for the current lead time before committing to a date.
Can SourceIT quote for multiple units or a project?
Yes. Send us your quantity and delivery requirements and we will quote the units together with consumables, options and installation where required, with local warranty and GST invoice.
