Dell Pro 24 Plus P2424HEB 24" Video Conferencing Monitor
PRODUCT DESCRIPTION
Dell Pro 24 Plus Video Conferencing Monitor P2424HEB (210-BKKS) - 3 Years Local Warranty
Built for Video Meetings
The Dell Pro 24 Plus P2424HEB combines a 23.8-inch Full HD IPS screen with a 4MP RGB + IR 2K camera (30 fps, FHD at 60 fps), two digital microphones and two 5 W speakers.
One Cable to Your Laptop
USB-C with DisplayPort 1.2 Alt Mode and up to 90 W power delivery, plus 1GbE RJ45 Ethernet, Auto KVM and DP-out with MST daisy-chaining.
Comfortable All Day
99% sRGB, TÜV-certified ComfortView Plus and flicker-free, and a stand with 150 mm height, tilt, swivel and pivot adjustment.
Fitting out hybrid-work desks or huddle spaces? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
Dell P2424HEB Datasheet — Technical Specifications
General
| Product Name | Dell Pro 24 Plus Video Conferencing Monitor - P2424HEB |
| Model | P2424HEB |
| Dell SKU | 210-BKKS |
| Local Warranty (Singapore) | 3-year Limited Hardware Warranty with Advanced Exchange Service and Premium Panel Exchange (Dell), supplied by SourceIT with a GST invoice |
| Others | Dell Power Button Sync (DPBS) |
| Included Software | Dell Display Manager |
| Security Lock Slot | Yes, based on Kensington Security Slot™ |
| Temperature Range | Operating: 0°C ~ 40°C (32°F ~ 104°F) |
| Humidity Range | Operating: 10% ~ 80% (non-condensing) |
Display
| Diagonal Viewing Size | 23.8" |
| Panel Type | In-Plane Switching (IPS) technology |
| Viewing Angles | 178° vertical / 178° horizontal |
| Display Screen Coating | Anti-glare treatment of front polarizer (3H) hard-coating |
| Maximum Preset Resolution | FullHD (1920 x 1080) at 60 Hz |
| Aspect Ratio | 16:9 |
| Pixel Pitch | 0.2745 mm x 0.2745 mm |
| Pixel Per Inch (PPI) | 92.56 |
| Brightness | 250 cd/m2 (typ) |
| Contrast Ratio | 1,000:1 (typical) |
| Backlight Technology | LED |
| Response Time | 5 ms gray to gray (fast) / 8 ms gray to gray (normal) |
| Color Gamut | 99% sRGB |
| Color Depth | Up to 16.7 million |
| Low Blue Light | Yes, TÜV-certified ComfortView Plus |
| Flicker-free | Yes, TÜV-certified Flicker-free |
Connectivity
| Interfaces | 1x HDMI (HDCP 1.4) |
| Interfaces | 1x DP 1.2 (HDCP 1.4) |
| Interfaces | 1x DP-out with MST |
| Interfaces | 1x RJ45 Ethernet port, 1GbE |
| Interfaces | 1x 3.5mm combo headphone with microphone jack |
| Interfaces | 1x USB 3.2 Gen1 Type-C (Alt mode with DP 1.2 upstream, up to 90W power delivery) |
| Interfaces | 1x USB 3.2 Gen1 Type-B upstream |
| Interfaces | 2x USB 3.2 Gen1 Type-A downstream |
| Interfaces | 1x USB 3.2 Gen1 Type-C downstream with up to 15W power delivery |
| Interfaces | 1x USB 3.2 Gen1 Type-A downstream with BC1.2 (2A max) |
| Auto KVM | Yes |
| Daisy-chain | Yes, supports Multi-Stream Transport (MST) and Multi-Monitor Sync (MMS) |
Audio & Camera
| Features | 1x 4MP RGB + IR 2K camera at 30 fps (FHD at 60 fps) |
| Features | 2x digital microphone |
| Features | 2x 5W built-in speaker |
Ergonomics
| Adjustability | Height, tilt, swivel, and pivot |
| Height adjustment | Up to 150mm (5.9") |
| Tilt angle | -5° / 21° |
| Swivel angle | Bi-directional 45° / 45° |
| Pivot angle | Bi-directional 90° / 90° |
| VESA Mounting Interface | 100mm x 100mm |
Power
| Power Voltage Required | 100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 2.3 A (typ) |
| Power Consumption (Off mode) | 0.3W |
| Power Consumption (Standby mode) | 0.3W |
| Power Consumption (Networked standby mode) | 0.8W |
| Power Consumption (On mode) | 15.5W |
| Power Consumption (Max) | 195W |
Physical
| Dimensions (HxWxD) - full monitor | 401.62 mm x 538.04 mm x 185.0 mm (15.81" x 21.20" x 7.30") |
| Dimensions (HxWxD) - panel only (for VESA mounting) | 374.55 mm x 538.04 mm x 60.53 mm (14.75" x 21.20" x 2.38") |
| Weight - full monitor | 6.08 kg (13.4 lbs) |
| Weight - panel only (for VESA mounting) | 4.44 kg (9.79 lbs) |
Certifications
| Energy Star Certified | Yes |
| EPEAT Compliant | Gold |
| TCO Certified | TCO 9 and TCO Certified Edge |
| RoHS compliant | Yes |
Compatibility & Software Support
Laptop Connection
Connect a USB-C laptop with DisplayPort Alt Mode for video, data, Ethernet and up to 90 W charging over one cable (USB-C cable included). HDMI and DisplayPort 1.2 inputs are also available.
Conferencing
The built-in camera, microphones and speakers connect to the PC over USB.
Multi-Monitor and Management
DP-out with MST daisy-chain and Multi-Monitor Sync, Auto KVM, Dell Power Button Sync, and Dell Display Manager.
Mounting
VESA 100 x 100 mm for monitor arms and wall brackets.
Package Contents & Dell Pro Plus 24-inch & Portable Monitors Ordering Information
In the Box
Monitor panel, Stand riser, Stand base, Quick setup guide, Safety, Environmental, and Regulatory Information, Power cable, DP-to-DP cable (1.8m), USB 3.2 Gen1 Type C-to-C cable (1.8m), USB 3.2 Gen1 Type A-to-B upstream cable (1.8m).
Dell Pro Plus 24-inch & Portable Monitors
| Model | Key feature |
| P1425 | 14" WUXGA portable, 2 x USB-C, 65W pass-through |
| P2425H | 24" FHD 100 Hz |
| P2425 | 24" WUXGA 16:10, 100 Hz |
| P2425E | 24" WUXGA 16:10 USB-C hub |
| P2425D | 24" QHD |
| P2425DE | 24" QHD USB-C hub |
| P2424HT | 24" FHD touch, USB-C hub |
| P2424HEB (this listing) | 24" FHD, 2K IR camera, 90W USB-C, RJ45 |
| P2426H | 24" FHD 120 Hz |
Datasheet & Downloads
| Datasheet (PDF) | P2424HEB datasheet on delltechnologies.com |
| Manuals & drivers | P2424HEB manuals and documents on Dell Support |
| Dell product page | P2424HEB on dell.com Singapore |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting P2424HEB.
Frequently Asked Questions — Dell P2424HEB
What camera does it have?
A 4MP RGB + IR 2K camera at 30 fps (Full HD at 60 fps), with two digital microphones and 2 x 5 W speakers.
How much power does the USB-C port deliver?
Up to 90 W over the USB-C upstream port (DisplayPort 1.2 Alt Mode).
Does it have Ethernet?
Yes, a 1GbE RJ45 port.
Can I daisy-chain another monitor?
Yes, via DP-out with Multi-Stream Transport (MST).
What warranty do I get?
3-year Limited Hardware Warranty with Advanced Exchange Service and Premium Panel Exchange (Dell), supplied locally by SourceIT with a GST invoice.
