D-Link 5G NR Multi-Connect Industrial VPN Dual-SIM Wi-Fi 6 Mobile Router

D-Link 5G NR Multi-Connect Industrial VPN Dual-SIM Wi-Fi 6 Mobile Router (DWM-550-G) - 3 Years Local Warranty

High-Speed 5G NR Connectivity with Wi-Fi 6

The D-Link DWM-550-G delivers ultra-fast 5G SA/NSA connectivity with speeds up to 3.4Gbps, combined with Wi-Fi 6 AX1800 wireless performance, enabling high-bandwidth applications such as video surveillance, industrial IoT, and remote operations with stable and reliable throughput.

Dual-SIM Failover for Always-On Connectivity

Equipped with dual Nano-SIM slots, the router automatically switches between carriers to maintain uninterrupted connectivity, ensuring business continuity even in unstable network conditions or remote environments.

Advanced VPN Security for Enterprise Networks

The DWM-550-G supports multiple VPN protocols including IPSec, OpenVPN, WireGuard, PPTP, L2TP, and GRE, allowing secure encrypted tunnels for data transmission, making it ideal for enterprises, retail deployments, and remote site connectivity.

Industrial-Grade Design for Harsh Environments

Built with a corrosion-resistant zinc-plated steel casing, wide voltage input, and extended temperature tolerance, this router is engineered for demanding industrial conditions such as outdoor installations, transportation systems, and smart city infrastructure.

Flexible Connectivity and Edge Deployment Ready

The router includes 1 configurable Gigabit WAN/LAN port and 3 Gigabit LAN ports, supporting flexible network configurations, while its plug-and-play setup and remote management capabilities make it ideal for large-scale deployments across distributed sites.

Technical Specifications

General
Model: DWM-550-G
Product Type: 5G NR Industrial Mobile Router (M2M/IIoT)
Deployment: Industrial / Enterprise / Outdoor / Edge networking
Cellular Technology: 5G NR + 4G LTE fallback
SIM Type: Dual Nano-SIM (4FF) with failover
Management: Local web UI + cloud (D-Link D-ECS support)

Cellular & Wireless
5G Standard: 5G NR (SA & NSA)
Max 5G Speed: Up to 3.4 Gbps
4G LTE: Supported (fallback connectivity)
Wi-Fi Standard: Wi-Fi 6 (802.11ax)
Wi-Fi Speed: AX1800 (up to 1.8 Gbps)
Bands: Dual-band (2.4 GHz / 5 GHz)

Interfaces
Ethernet Ports:

• 1 × Gigabit WAN/LAN (configurable)
• 3 × Gigabit LAN ports
  SIM Slots: 2 × Nano-SIM (failover redundancy)
  Antenna: External cellular antennas (industrial deployment ready)
  Power Input: DC 12–36 V (wide input range)

VPN & Security
VPN Protocols: IPSec, OpenVPN, WireGuard, PPTP, L2TP, GRE
Firewall: Built-in enterprise-grade firewall
Encryption: Secure tunneling for remote access and site-to-site VPN
Security Use: Protects sensitive data across WAN and mobile networks

Network Features
Multi-Connect: Automatic failover between SIM and WAN
Load Balancing: Supports intelligent traffic routing
QoS: Traffic prioritization for critical applications
Plug-and-Play: Minimal setup required for deployment

Performance & Processing
Backhaul: High-speed 5G uplink for enterprise applications
Wi-Fi Clients: Supports multiple concurrent devices
Latency: Optimized for low-latency industrial communication
Use Case: Real-time data transmission (IoT, surveillance, edge compute)

Industrial Design
Casing: Zinc-plated steel (corrosion-resistant)
Mounting: DIN rail / wall mount compatible (industrial environments)
Durability: Designed for harsh environments
Operating Temperature: Approx. -30°C to +70°C
Humidity Tolerance: Industrial-grade non-condensing environments

Reliability Features
Dual-SIM Redundancy: Automatic carrier failover
Always-On Connectivity: Maintains uptime even with network issues
Wide Voltage Input: Suitable for unstable power environments
Industrial Stability: Designed for continuous 24/7 operation

Management & Monitoring
Remote Management: Cloud-based via D-Link D-ECS
Configuration: Centralized device provisioning and monitoring
Firmware Updates: Remote upgrade support
Diagnostics: Network and device monitoring tools

Key Features
5G NR ultra-fast connectivity up to 3.4 Gbps
Wi-Fi 6 AX1800 for high-density wireless environments
Dual-SIM failover for uninterrupted connectivity
Full VPN suite for secure enterprise networking
Industrial-grade design for harsh deployment conditions
Flexible WAN (5G + Ethernet) multi-connect architecture

Typical Use Cases
Smart city and surveillance systems
Industrial IoT (IIoT) and automation
Retail kiosks and pop-up deployments
Transportation and fleet connectivity
Remote site connectivity (construction, offshore, utilities)

Detailed Specification

5G NR Multi-Connect Industrial VPN Dual-SIM Wi-Fi 6 Mobile Gigabit Router (FREE 3 MONTHS DECS)
WiFi 6 AX1800, 1 x Gigabit WAN/LAN, 3 x Gigabit LAN, 2 x Nano-SIM, 4 x 5G NR/LTE Cellular Antennas, 2 x Wi-Fi Antennas, Power Sources: DC 12 - 36V (Terminal Block | 2-pin),
5G, 4G, 3G (Global or EU Series)
5G SA & NSA up to 3.4Gbps DL (NSA) / 900Mbps UL (SA), 4G LTE 1.6Gbps DL / 200Mbps UL
5G NR: N1/N3/N5/N7/N8/N20/N28/N38/N40/N41/N71/N75/N76/N77/N78
4G FDD: FDD: B1/B3/B5/B7/B8/B20/B28/B32/B71; TDD: B38/B40/B41/B42/B43
WAN Failover, AP, Routing: Static, Dynamic RIPv1/v2, OSPF, BGP
VPN: IPSec/OpenVPN/PPTP/L2TP/GRE/WireGudard, Site/Host to Site/host; Dynamic VPN, DECS Supported
Operation Temperature: -30 to 70 degree C, CE, Made-in-Taiwan
(Power Adapter (M-Type | UK + EU | Included)
